15-1924.fm Page 1 Monday, July 19, 1999 12:50 PM
Cat. No. 15-1924
OWNER'S MANUAL
7-in-1 Remote Control
with Lighted Keypad
Plug 'n Power
Compatible
Please read before using this equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7-in-1 Remote Control with Lighted Keypad and is the answer not in the manual?

Questions and answers

Related Manuals for Radio Shack 7-in-1 Remote Control with Lighted Keypad

Summary of Contents for Radio Shack 7-in-1 Remote Control with Lighted Keypad

  • Page 1 15-1924.fm Page 1 Monday, July 19, 1999 12:50 PM Cat. No. 15-1924 OWNER’S MANUAL 7-in-1 Remote Control with Lighted Keypad Plug ’n Power Compatible Please read before using this equipment.
  • Page 2 15-1924.fm Page 2 Monday, July 19, 1999 12:50 PM FEATURES Your RadioShack 7-in-1 Remote Control can re- place up to seven infrared remote controls. You can use it to control your TV, VCR, cable box, sat- ellite receiver, and even lights and appliances with Plug ’n Power modules (not included).
  • Page 3 15-1924.fm Page 3 Monday, July 19, 1999 12:50 PM Convenient Keypad Design — each key is posi- tioned for easy operation. Toll Free Support — you can get expert help for your 7-in-1 Remote Control by calling 1-800-989- 4706. Note: You need four AAA batteries (not supplied) to power your 7-in-1 Remote Control.

  • Page 4: Table Of Contents

    15-1924.fm Page 4 Monday, July 19, 1999 12:50 PM CONTENTS How the 7-in-1 Works ... 5 Preparation ... 7 Installing Batteries ... 7 Lighting the Keys ... 8 Device Types ... 8 Setting Up Your 7-in-1 ... 9 Using Two or More Similar Devices .. 10 Operation ...

  • Page 5: How The 7-In-1 Works

    15-1924.fm Page 5 Monday, July 19, 1999 12:50 PM HOW THE 7-IN-1 WORKS Your RadioShack 7-in-1 Remote Control was de- signed to control the most commonly used func- tions on your TV, VCR, cable converter, CD player, satellite receiver, audio equipment, and Plug ’n Power devices.
  • Page 6 15-1924.fm Page 6 Monday, July 19, 1999 12:50 PM Function GUIDE Displays the main menu on direct-to-home satellite sys- tems. REC, PAUSE, Control VCR functions and PLAY, REW, are used to select options and STOP navigate in your Surround Sound system, satellite sys- tem, or other similar device.

  • Page 7: Preparation

    15-1924.fm Page 7 Monday, July 19, 1999 12:50 PM PREPARATION INSTALLING BATTERIES You need four AAA batteries to power your re- mote control. We recommend alkaline batteries, such as RadioShack Cat. No. 23-558. Cautions: • Use only fresh batteries of the required size and recommended type.

  • Page 8: Lighting The Keys

    15-1924.fm Page 8 Monday, July 19, 1999 12:50 PM LIGHTING THE KEYS Press to light the keys on the remote for about 5 seconds. If you press a key when the keys are lit, the keys stay lit for about 5 more seconds. To turn off the light before it automatically turns off, press again.

  • Page 9: Setting Up Your 7-In-1

    15-1924.fm Page 9 Monday, July 19, 1999 12:50 PM SETTING UP YOUR 7-IN-1 1. Refer to “Manufacturers’ Codes” on Page 23 and write down the codes for your original remote controls. Notes: • Some manufacturers have several possi- ble codes listed. Try each until you find the right one.

  • Page 10: Using Two Or More Similar Devices

    15-1924.fm Page 10 Monday, July 19, 1999 12:50 PM 5. Point the 7-in-1 Remote Control at your device and press POWER (All Lts On) for some cable boxes). Your CHANNEL + (On) device should turn off (or on, if it was off). If the remote does not operate your device, try the other codes listed in “Manufacturers’...

  • Page 11: Operation

    15-1924.fm Page 11 Monday, July 19, 1999 12:50 PM OPERATION 1. Press the device key for the device you want to control, then point the 7-in-1 at the device and press POWER (All Lts On) for some cable converters) to turn the + (On) device on.

  • Page 12: Using The 7-In-1'S Timer

    15-1924.fm Page 12 Monday, July 19, 1999 12:50 PM In this case, you must press the desired device key before you use the remote con- trol’s CHANNEL + (On) CHANNEL – (Off) keys. • If you selected AUX1 punch-through , or not programmed AUX1 VCR, or CBL device.

  • Page 13: Entering A Plug 'N Power House Code

    15-1924.fm Page 13 Monday, July 19, 1999 12:50 PM Entering a Plug ’ n Power House Code Your IR Command Console or Plug ’n Power Wireless Remote Control System uses a master code called a house code (see your IR Command Console’s or Plug ‘n Power Wireless Remote Control System’s Owner’s Manual for more infor- mation).
  • Page 14 15-1924.fm Page 14 Monday, July 19, 1999 12:50 PM 5. Hold down on the 7-in-1 until the red SET UP light above turns on. 6. Press Plug ’n Power, then enter the 7-in-1. The red light turns off. 7. Press Plug ’n Power on the 7-in-1. 8.

  • Page 15: Controlling Lights And Appliances Using A Control Center Module

    15-1924.fm Page 15 Monday, July 19, 1999 12:50 PM Controlling Lights and Appliances Using a Control Center Module Follow these steps to control Plug ’n Power mod- ules with your 7-in-1 using your Plug ’n Power Wireless Remote Control System’s control center module.

  • Page 16: Setting A Plug 'N Power Timer

    15-1924.fm Page 16 Monday, July 19, 1999 12:50 PM 9. To brighten or dim lights connected to lamp and appliance modules, press the digit key for the module you want to control. Then hold down VOLUME + (Brt) on the 7-in-1. Release the key when (Dim) the desired level of brightness is reached.

  • Page 17: Teaching Commands To The 7-In-1

    15-1924.fm Page 17 Monday, July 19, 1999 12:50 PM Note: If the code you entered is invalid, the red light flashes for about 3 seconds. 5. Use the 7-in-1’s number keys to enter the time you want to set. For example, if you want to enter 15 minutes, press When the red light blinks once, the 7-in-1 has accepted the code.

  • Page 18: Teaching A Command

    15-1924.fm Page 18 Monday, July 19, 1999 12:50 PM • You can store a command into any of the 7- in-1’s keys except SET UP Power, AUX1 , and SHIFT TIMER • You can store a command in one of the 7-in- 1’s keys where you have to press the key to activate the command.

  • Page 19: Clearing All Commands

    15-1924.fm Page 19 Monday, July 19, 1999 12:50 PM from a VCR’s original remote control, press on the 7-in-1. PLAY If the key you want to program is already used for another command, press before pressing the key. For example, to store the command SHIFT-PLAY, press then on the 7-in-1.

  • Page 20: If You Have Problems

    15-1924.fm Page 20 Monday, July 19, 1999 12:50 PM IF YOU HAVE PROBLEMS MANUAL CODE SEARCH If the 7-in-1 Remote Control does not operate your remote-controlled devices when you first set it up, you might have to manually find the correct code for your devices.

  • Page 21: Determining The 3-Digit Code

    15-1924.fm Page 21 Monday, July 19, 1999 12:50 PM • Because the 7-in-1’s library has so many codes, this procedure can take several minutes. • If your device turns off during the search, but does not operate after you lock in the code, begin the search again, pausing longer between key presses.

  • Page 22: Troubleshooting

    15-1924.fm Page 22 Monday, July 19, 1999 12:50 PM TROUBLESHOOTING If the 7-in-1 Remote Control stops working after you have successfully tested the control for each device, or if you are unable to get the remote con- trol to work at all, check these things: •...

  • Page 23: Manufacturers' Codes

    15-1924.fm Page 23 Monday, July 19, 1999 12:50 PM MANUFACTURERS’ CODES The following list tells you which 3-digit codes to enter to set up the 7-in-1 Remote Control. Notes: • The 7-in-1 Remote Control might not have every command of your original remote con- trols.
  • Page 24 15-1924.fm Page 24 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) CABLE CONVERTERS (Continued) Century Citizen Colour Voice 025, 026 Comtronics 027, 028 Contec Eastern Garrard GC Electronics Gemini 031, 032 General Instrument Hamlin 033, 034, 035 Hitachi Hytex Jasco Jerrold 014, 016, 017, 018, 020, 031, 037, 062,...

  • Page 25: Cassette Player

    15-1924.fm Page 25 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) CABLE CONVERTERS (Continued) Scientific Atlanta 019, 049, 050, 051, 066, 067 Signal 027, 031 Signature St. Marx Sprucer Standard Components Starcom 014, 020, 031 Stargate 027, 031 Starquest Star Trak Tandy Teleview Texscan...
  • Page 26 15-1924.fm Page 26 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) CD PLAYERS (Continued) Audio Alchemy Audio Technica California Audio Labs 069 Capetronic Carrera Carver 019, 020, 021 Casio Curtis Mathes Denon 023, 024 Emerson 014, 025, 026 Fisher 020, 027, 028, 029, 030, 071 Genexxa 025, 026, 031, 072...
  • Page 27 15-1924.fm Page 27 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) CD PLAYERS (Continued) Onkyo 048, 049, 075 Optimus 017, 020, 021, 031, 037, 050, 051, 053 Panasonic 069, 086, 093 Philips 019, 084 Pioneer 031, 054, 055, 072 Proton Quasar 014, 020, 025, 056, RCA Digital Video...

  • Page 28: Direct-To-Home Satellite Receivers

    15-1924.fm Page 28 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) CD PLAYERS (Continued) Symphonic TEAC 029, 042, 052, 062, 063, 064 Technics 069, 086, 089 Theta Digital Toshiba Vector Research 017, 032 Victor Yamaha 018, 065, 066, 077 DIRECT-TO-HOME SATELLITE RECEIVERS Echosphere Echostar Dish Network...

  • Page 29: Televisions

    15-1924.fm Page 29 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) SATELLITE RECEIVERS (Continued) Chaparral 013, 014, 033 Cheyenne Drake 015, 016, 038, 039, DX Antenna 021, 035 Echostar 041, 042, 043 Fujitsu 044, 045 General Instruments 017, 018, 019, 046 Janeil Jerrold Kenwood...
  • Page 30 15-1924.fm Page 30 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TELEVISIONS (Continued) 017, 018, 020, 022, 027, 188, 208 Audiovox Belcor Bell & Howell 014, 062, 096 Bradford Brokwood Candle 017, 021, 022, 187 Capehart Celebrity Centurion Cetronic Citizen 017, 021, 022, 029, 051, 055, 084, 118, 184, 187, 190...
  • Page 31 15-1924.fm Page 31 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TELEVISIONS (Continued) Emerson (continued) 047, 048, 049, 050, 051, 052, 053, 054, 055, 056, 057, 058, 059, 062, 136, 137, 176, 184, 190, 192, Envision 017, 022 Fisher 026, 062, 064, 193 Fujitso Funai 051, 055, 059...
  • Page 32 15-1924.fm Page 32 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TELEVISIONS (Continued) Kawasho 015, 017, 022 KaypanI Kenwood 017, 022 Kloss Novabeam 081, 082, 187 027, 051, 055, 083, 184, 190 Lodgenet Loewe Logik Luxman 017, 022 013, 022, 062, 075, 084, 194 Megatron 022, 072...
  • Page 33 15-1924.fm Page 33 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TELEVISIONS (Continued) Multivision 022, 084, 198 016, 017, 018, 022, 098, 102, 108, 213 Nikei Nikko 022, 029 Onking Onwa 051, 055 Optimus Optonica 108, 186 Orion Panasonic 016, 067, 075, 183 Philco 016, 017, 018, 021, 022, 075, 081,082,...
  • Page 34 15-1924.fm Page 34 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TELEVISIONS (Continued) RadioShack/Realistic (continued) 013, 016, 017, 018, 020, 022, 109, 111, 112, 113, 114, 115, 116, 142, 192, 194, 200, 201 Rhapsody Runco Sampo 017, 022, 184, 185, Samsung 017, 018, 022, 024, 028, 084, 117, 118,...
  • Page 35 15-1924.fm Page 35 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TELEVISIONS (Continued) Sonic Sony 015, 019 Soundesign 017, 021, 022, 051, 055, 059 Squareview 017, 051, 055 Starlite Supremacy Supreme Sylvania 017, 021, 022, 075, 081, 082, 087, 088, 089, 090, 101, 174, Symphonic 046, 051, 202...

  • Page 36: Tv/Vcr Combinations

    15-1924.fm Page 36 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) TV/VCR COMBINATIONS RadioShack 183 (TV functions) 122 (VCR func- tions) VCRs Admiral Adventura Aiko Aiwa 015, 039 Akai 016, 017, 018, 019, 020, 021, 042, 124, American High Asha Audio Dynamics 022, 023 Audiovox...
  • Page 37 15-1924.fm Page 37 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) VCRs (Continued) Dynatech 015, 039 Electrohome 027, 042 Electrophonic Emerson 015, 019, 025, 027, 028, 037, 038, 039, 042, 043, 044, 045, 046, 047, 048, 049, 050, 051, 052, 053, 054, 055, 056, 057, 058, 060, 073, 078, 118, 129, 130...
  • Page 38 15-1924.fm Page 38 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) VCRs (Continued) Logik Magnavox 035, 073, 075, 076, 117, 121, 137 Magnin Marantz 022, 023, 024, 029, 031, 073, 075, 077, Marta Matsushita Memorex 014, 015, 024, 026, 027, 036, 039, 056, 073, 117, 125 042, 078 MGN Technology...
  • Page 39 15-1924.fm Page 39 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) VCRs (Continued) Optimus (continued) 027 (continued) Optonica 088, 147 Panasonic 035, 073, 122, 138, 139, 140 Pentax 029, 068, 069, 120, Pentex Research Philco 035, 073, 075, 076 Philips 073, 075, 088, 137 Pilot Pioneer...
  • Page 40 15-1924.fm Page 40 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) VCRs (Continued) RadioShack/Realistic 015 (continued) (continued) 013, 024, 026, 042, 063, 088, 122, 125 Radix Randex Ricoh Need help? Call 1-800-989-4706 RadioShack Cat. No. 16-411 16-508 16-510 16-519 16-622 16-703 16-704 16-408...
  • Page 41 15-1924.fm Page 41 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) VCRs (Continued) Runco Samsung 018, 026, 028, 046, 066, 125 Sankyo 014, 117 Sansui 023, 105, 124, 136 Sanyo 024, 026, 036 Scott 025, 028, 038, 045, 051, 078, 106, 129 Sears 024, 027, 036, 061, 062, 063, 064, 068,...
  • Page 42 15-1924.fm Page 42 Monday, July 19, 1999 12:50 PM Manufacturer Code(s) VCRs (Continued) Videosonic XR-1000 073, 039, 074 Yamaha 022, 023, 024, 031, Zenith 017, 111, 117, 132, Need help? Call 1-800-989-4706 RadioShack Cat. No.

  • Page 43: Care And Maintenance

    15-1924.fm Page 43 Monday, July 19, 1999 12:50 PM CARE AND MAINTENANCE Your RadioShack 7-in-1 Remote Control is an ex- ample of superior design and craftsmanship. The following suggestions will help you care for your 7-in-1 so you can enjoy it for years. Keep the 7-in-1 dry.

  • Page 44: Specifications

    15-1924.fm Page 44 Monday, July 19, 1999 12:50 PM SPECIFICATIONS Power ... 4 AAA Batteries Control Range: IR ... 20 Feet (6.096 M) RF ... 100 Feet (30.48 M) Dimensions (HWD) ... 8 ¥ 2 (21.6 ¥ 6.26 ¥ 2.65 cm) Weight (Without Batteries) ...
  • Page 45 15-1924.fm Page 45 Monday, July 19, 1999 12:50 PM NOTES Need help? Call 1-800-989-4706...
  • Page 46 15-1924.fm Page 46 Monday, July 19, 1999 12:50 PM Need help? Call 1-800-989-4706...
  • Page 47 15-1924.fm Page 47 Monday, July 19, 1999 12:50 PM Need help? Call 1-800-989-4706...
  • Page 48 15-1924.fm Page 48 Monday, July 19, 1999 12:50 PM Limited Ninety-Day Warranty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for ninety (90) days from the date of purchase from RadioShack company- owned stores and authorized RadioShack franchisees and deal- ers.
