Radio Shack 15-2127 Owner's Manual

5/KP/3"7PKXGTUCN"4GOQVG"%QPVTQN"L")QNHDCI"5V[NG
15-2127
#
"+/2146#06"
If an icon appears at the end of a paragraph,
go to the box on that page with the
corresponding icon for pertinent information.
Rý Rý Rý Rý
° ° ° °
— Warning
. . . .
± ± ± ±
— Caution
#
— Important
R
"9#40+0)"
Dispose of batteries promptly and properly.
.
"%#76+10"
• Use only fresh batteries of the required size
and recommended type.
• Do not mix old and new batteries, different
types of batteries (standard, alkaline, or
rechargeable), or rechargeable batteries of
different capacities.
• If you do no plan to use the remote control
for a month or longer, remove the batteries.
• Rechargeable batteries are to be removed
from the remote before being charged.
• Rechargeable batteries are only to be
charged under adult supervision.
• Batteries are to be inserted with the correct
polarity.
• Do not short-circuit the terminals.
• Do not attempt to charge non-rechargeable
batteries.
± ±
"016'"
Installing Batteries
When the remote stops operating properly,
replace the batteries within 10 minutes of
removing the old batteries. Otherwise, the
programmed settings and codes will be lost.
Programming the Remote
If the device does not turn off, repeat steps
3–5, using another code from the Code List for
your device until you find one that works.
Thank you for purchasing the RadioShack 3-in-1 Universal Remote Control – Golfbag Style. It
#
is a state-of-the-art device specially designed to operate the major functions of your television
(TV), video cassette recorder (VCR), and cable converter (CBL). It is compatible with most
popular brand TV, VCR, and CBL devices. The remote is pre-programmed before you
purchase it. Input the correct code for your device and the remote is ready to use.
— Hint
— Note
Battery Compartment
RESET — Resets stored
remote settings.
R
"
+056#..+0)"
$#66'4+'5
.
Your remote requires two AA batteries (not
supplied) for power. For the best
performance and longest life, we
recommend RadioShack alkaline
batteries.
1. Unseal the flap on the remote, then pull
out the battery compartment.
2. Use a Phillips screwdriver to loosen the
screw on the battery compartment
cover, then remove the cover.
3. Place two AA alkaline batteries in the
compartment as indicated by the
polarity symbols (+ and –) marked
inside.
"
OWNER'S MANUAL — Please read before using this equipment.
SET — Initiates
programming mode.
TV/VCR —
Switches the
view between
the TV and VCR.
VOL VOL– Adjusts
the volume.
J J J J
— Play
# # # #
— Rewind
ç ç ç ç
— Record
Rý Rý Rý Rý
. . . .
©
2002 RadioShack Corporation.
All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
PWR — Turns the selected
device on or off.
TV/VCR/CBL — Selects the
desired device type.
ENTER — Press after entering
channel numbers (on some TV
models).
CH CH– Selects a channel.
MUTE — Turns the sound on
or off.
, , , ,
— Fast Forward
' ' ' '
— Stop
f f f f
— Pause
4. Replace the cover and secure it with the
screw.
5. Replace the battery compartment and
seal the flap. ±
241)4#//+0)"6*'"
4'/16'
While programming, make sure to aim the
remote at the device and that the distance
between the remote and device is within 21
feet (7 meters).
1. Refer to the "Code List" on Page 3 and
write down the codes for your device.
2. Manually turn on your TV, VCR, or
cable converter.
3. Press ,
TV VCR
desired device type. The red LED blinks
once.
4. Hold down
twice.
5. Enter the 4-digit code. If the code is
valid, the red LED blinks twice.
6. Aim the remote control at the device
and press
PWR
off. ± ±
± ±
± ± ±
, or to select the
CBL
until the red LED blinks
SET
. The device should turn
