Service & Maintenance manual
Salwico CS4000
Appendix A: Fault codes & Fuses
Fault code
NO ANSWER
Lost communication. The
128 system has recognized a
unit but lost contact with it
due to some interference.
129 SENSOR FAULT
DIRTY SENSOR
130
131 TOO FEW FOUND
TOO MANY FOUND
132
133 IN1 CABLE BREAK
134 IN2 CABLE BREAK
135 EXT 24V FAIL
Appendix A: Fault codes & Fuses

Fault list

Listed below are all fault codes, their causes and how an
operator with some knowledge of the system can solve the
problem.
Cause
Wrong type of loop
unit
Two loop units have
the same address
Hardware fault
A fuse is blown (a
secondary fault
appears)
Cable break in a
detector or system loop
(a secondary fault
appears)
The detector has a
faulty sensor element.
The smoke detector is
exposed to wind
The detector has a dirty
sensor element
Fewer loop units found
than configured
Loop units not
correctly installed
Missing answer from a
unit
More loop units found
than configured
There is a cable break
on input 1
There is a cable break
on input 2
External 24V power
source missing.
37
Remedy
Exchange to the correct loop unit
Check the units
Exchange the unit
Exchange the fuse
Mend the cable
Exchange unit
Take care of wind problem
Try to clean the detector with a
vacuum cleaner or by blowing high-
pressure air on it. If this does not
help, exchange the detector.
Ion smoke detector: Exchange the
detector
Check the specification and re-
define the system
Connect the unit correctly
Check address (possible double
address). Otherwise exchange the
unit.
Check the specification and re-
define the system
Mend the cable break
Mend the cable break
The local power supply is defect.
