43-991A.fm Page 1 Tuesday, December 28, 1999 7:59 AM
Cat. No. 43-991A
OWNER'S MANUAL
Please read before using this equipment.
System 350
79-Memory Caller ID
with Illuminator Backlight

Advertisement

Table of Contents
loading

Related Manuals for Radio Shack System 350

Summary of Contents for Radio Shack System 350

  • Page 1 43-991A.fm Page 1 Tuesday, December 28, 1999 7:59 AM Cat. No. 43-991A OWNER’S MANUAL Please read before using this equipment. System 350 79-Memory Caller ID with Illuminator Backlight...
  • Page 2 43-991A.fm Page 2 Tuesday, December 28, 1999 7:59 AM : To reduce the risk of fire WARNING or shock hazard, do not expose this product to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK.
  • Page 3 Caller ID service subscribers. (The date and time are set with your first incoming Caller ID call.) The System 350 stores and displays up to 79 multiple (name and number) Caller ID records, and includes these features: Easy Installation —...
  • Page 4 43-991A.fm Page 4 Tuesday, December 28, 1999 7:59 AM Record Scrolling — lets you easily look through all call records in Caller ID memory. Trilingual Operation — lets you set the system to display messages in English, French, or Spanish. Large Liquid Crystal Display —...
  • Page 5 43-991A.fm Page 5 Tuesday, December 28, 1999 7:59 AM Important Information: • To use this system, you must be in an area where Caller ID service is available, and you must subscribe to the ser- vice. • Where Caller ID is offered, one or more of the following options are generally available: –...

  • Page 6: Fcc Information

    , or REN. The REN is on the bottom of the system. If you use more than one telephone or other device on the line, add up all of the RENs. If the total is more than five, your tele- phone might not ring.
  • Page 7 Also, the phone company can make changes to its lines, equipment, operations, or procedures that could affect the op- eration of this system. The telephone company notifies you of these changes in advance, so you can take the necessary steps to prevent interruption of your telephone service.

  • Page 8: Table Of Contents

    43-991A.fm Page 8 Tuesday, December 28, 1999 7:59 AM CONTENTS Preparation ........9 Installing Batteries .

  • Page 9: Preparation

    43-991A.fm Page 9 Tuesday, December 28, 1999 7:59 AM PREPARATION Your system’s display is protected by a piece of plastic film dur- ing shipment. Peel off this film before you use the system. INSTALLING BATTERIES You need four AAA batteries (not supplied) to protect the sys- tem’s memory during a power failure.
  • Page 10 2 minutes after removing the old ones, you will lose all the information stored in the system. 1. Make sure the system is unplugged from the telephone line and AC power. 2. If you are replacing the batteries, unplug both modular line cords from the back of the system.

  • Page 11: Connecting The Ac Adapter

    43-991A.fm Page 11 Tuesday, December 28, 1999 7:59 AM When BATT (battery) appears or the display dims, replace the batteries. Cautions: • Always remove old or weak batteries. Batteries can leak chemicals that can damage your system. • Dispose of dead batteries promptly and properly. Do not bury or burn them.

  • Page 12: Connecting The System

    43-991A.fm Page 12 Tuesday, December 28, 1999 7:59 AM CONNECTING THE SYSTEM The System 350 connects to any modular phone jack and your phone. You can also connect it to an answering machine. Connecting to a Single-Line Phone TO PHONE...
  • Page 13 L1/L2 Triplex Adapter 1. Disconnect the telephone line cord from the modular phone jack (on the wall) and plug it into plex adapter. 2. Plug the triplex adapter into the modular phone jack. 3. Plug one end of the supplied line cord into the jack on one of the systems.

  • Page 14: Connecting To An Answering Machine

    3. Plug the cord’s other end into the answering machine’s jack. 4. Set your answering machine to answer after two or more rings. This gives the System 350 time to record the call information that the phone company sends between the first and second rings.

  • Page 15: Attaching The Mounting Bracket

    43-991A.fm Page 15 Tuesday, December 28, 1999 7:59 AM Attaching the Mounting Bracket 1. Align the keyhole slots on the bottom of the system with the hooks on the mounting bracket. 2. Gently push the system down on the bracket to secure it. If you are placing the system on a desk, shelf, or table, pull out the stand on the back of the bracket until it clicks.
  • Page 16 43-991A.fm Page 16 Tuesday, December 28, 1999 7:59 AM 3. Thread a screw through each hole, letting the head extend inch from the wall. 4. Attach the mounting bracket to the system (see “” on Page 15). 5. Route the phone line cords and AC adapter cord through the slots on the back of the bracket.

  • Page 17: Adjusting The Display Contrast

    CONTRAST ADJUST TRAST CHOOSING A LANGUAGE Your System 350 is programmed to display messages in En- glish, but you can change it to display in French or Spanish. Fol- low these steps to change the language. 1. Hold down...

  • Page 18: Operation

    During an incoming call, the red new call indicator flashes, the display lights, and and the total number of calls appear. Note: When the System 350 is in the standby mode, you can change the clock between 12 or 24 hour time by pressing the button.
  • Page 19 43-991A.fm Page 19 Tuesday, December 28, 1999 7:59 AM Each call record includes the time and date of the call, the call number (order in which the call is received), the caller’s tele- phone number, and the caller’s name (if available). REVIEW To scroll through the call records, repeatedly press (or hold down)

  • Page 20: Displayed Call Information

    43-991A.fm Page 20 Tuesday, December 28, 1999 7:59 AM Displayed Call Information The system can display the following information. Display (English, French, Spanish) (Repeat) Appears with a number if REPT you have received a call from the same phone number more than once (up to 9 times).
  • Page 21 Call information was distorted be- SERVICE ERROR fore reaching the system. Normal ERREUR DE LIGNE static on the telephone can cause ERROR EN LINEA this message. If it happens often, contact your phone company. No new call information is stored NO NEW CALLS in the system.

  • Page 22: Deleting Calls

    43-991A.fm Page 22 Tuesday, December 28, 1999 7:59 AM DELETING CALLS Deleting a Single Call 1. Repeatedly press (or hold down) either you see the call record you want to delete. 2. Press . The system deletes that record and ERASE automatically renumbers the remaining call records.

  • Page 23: Vip Call List

    43-991A.fm Page 23 Tuesday, December 28, 1999 7:59 AM VIP CALL LIST Your system lets you save up to 20 call records in its VIP call list so they will not be deleted if you delete all calls from the sys- tem’s memory.

  • Page 24: Message Waiting

    43-991A.fm Page 24 Tuesday, December 28, 1999 7:59 AM To delete all entries from the VIP call list, hold down DELETE ALL? appears. Press Or, to cancel deletion, do not press any button. After about 5 seconds, DELETE ALL? disappears. MESSAGE WAITING If you subscribe to message waiting service with your local tele- phone company, the red new call indicator flashes and the sys-...

  • Page 25: Troubleshooting

    If your system is not working as it should, these suggestions might help you eliminate the problem. Problem Blank screen The System 350 is not receiving power. Make sure the batteries are installed and the AC adapter is plugged in.

  • Page 26: Care And Maintenance

    43-991A.fm Page 26 Tuesday, December 28, 1999 7:59 AM CARE AND MAINTENANCE To enjoy your System 350 79-Memory Caller ID for a long time: • Keep the system dry. If it gets wet, wipe it dry immediately. • Use and store the system only in normal temperature environments.

  • Page 27: Lightning

    43-991A.fm Page 27 Tuesday, December 28, 1999 7:59 AM Also, the telephone company can make changes to its lines, equipment, operations, or procedures that could affect the op- eration of the system. The telephone company notifies you of these changes in advance, so you can take the necessary steps to prevent interruption of your telephone service.
  • Page 28 43-991A.fm Page 28 Tuesday, December 28, 1999 7:59 AM Limited One-Year Warranty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for one (1) year from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers.
