OWNER'S MANUAL —
Please read before using this equipment.
Thank you for purchasing a
RadioShack Remote Control A/B
Switch. Your switch lets you connect
two 75-ohm VHF/UHF/Cable
sources to your television with only
one 75-ohm jack without mixing the
signals. You can connect sources
such as broadcast TV, cable TV, a
VCR, or a video game system, and
switch between the sources without
leaving your seat. The high-isolation
design prevents interference
between the two sources, and the
electronic switching provides
reliable operation because there are
no mechanical parts to wear out.
The hand-held transmitter's
miniature design takes up very little
surface space.
If you have a VCR
Hook up your VCR between the switch and your TV so you
can record programming from Source A and Source B.
RF Signal
•
Cable TV
•
2nd VCR
Source A
•
TV Antenna
•
Satellite
•
Video Game System
•
Other RF Source
A-B Switch
If an icon appears at the end of a paragraph, go to the box on that page with the corresponding icon for
pertinent information.
!
— Important
SM
C
ONNECTING THE
The remote control switch
has two 75-ohm input
terminals and one 75-ohm
output terminal.
Use 75-ohm coaxial cable
for the connections. Your
local RadioShack store
sells the proper cables and
connection accessories.
1. Connect the output
terminals of the two
75-ohm VHF/UHF/
Cable sources to the
switch's
terminals.
2. Then, connect the
switch's
terminal to your TV
monitor's input
terminal.
RF Signal
Source B
VCR
!
!
IMPORTANT
Ô
Remote Controlled A/B Switch
R
C
EMOTE
A IN
and
A IN
B IN
TO TV
B IN
output
TO TV
12V DC 100 mA
Power Jack
If you do not have a VCR
Hook up the switch directly to your TV, or hook up a component
with an RF Tuner between your switch and your TV.
RF Signal
Source A
— Note
S
ONTROL
WITCH
•
Cable TV
•
TV Antenna
•
Satellite
•
Video Game System
•
Other RF Source
A-B Switch
OR
©
2002 RadioShack Corporation.
All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
15-1968
A
RF Signal
Source B
Other Component with
RF Tuner
