Radio Shack 63-1123 Owner's Manual

5KPING"$GNN"9KTGNGUU"&QQT"%JKOG
63-1123
# #
"+/2146#06"
If an icon appears at the end of a paragraph,
go to the box on that page with the
corresponding icon for pertinent information.
Rý ° ° ° °
— Warning — Hint
. . . .
±
— Caution — Note
#
— Important
. . . .
"%#76+10" "%#76+10"
• Use only fresh batteries of the required size • Use only fresh batteries of the required size
and type. Always remove old or weak and type. Always remove old or weak
batteries. They can leak chemicals that batteries. They can leak chemicals that
destroy electronic circuits destroy electronic circuits
• Do not mix old and new batteries, different • Do not mix old and new batteries, different
types of batteries (standard, alkaline, or types of batteries (standard, alkaline, or
rechargeable), or rechargeable batteries of rechargeable), or rechargeable batteries of
different capacities. different capacities.
Receiver
Slide ON/OFF to ON
so that when BELL
is pressed on the
transmitter, a door
chime sounds.
Thank you for purchasing the RadioShack
Single Bell Wireless Door Chime. It works as
a doorbell, remote pager, or alert. You can
add an optional external sensor to have a
chime that alerts you when someone walks
into a room. The door chime's three-position
channel switch prevents other transmitters
or radio devices from sounding the chime.
/1706+0)"6*'"
4'%'+8'4
1 " "( "5
0 # .#6 74(#%'
Pull out the wire stand on the back of the
receiver and set it on a table or other flat
surface.
1 " "9
0 # #..
1. Drill one 3 / -inch diameter hole and
16
insert one of the supplied anchors.
2. Drive the supplied M3.5 screw into the
hole until the screw's head extends
about 1 / inch from the wall.
8
3. Align the keyhole slot on the bottom of
the receiver with the screw in the wall,
then slide it down to secure it.
/1706+0)"6*'"
64#05/+66'4"
1. Remove the transmitter from the holder.
2. Use the holder as a template to mark
two screw holes on the wall.
3. Remove the holder from the mounting
3
surface and drill two / inch diameter
16
holes. Insert one of the supplied
anchors into each hole.
©
2002 RadioShack Corporation.
All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
OWNER'S MANUAL — Please read before using this equipment.
Transmitter
Indicator — Lights when
BELL is pressed.
BELL — Press BELL
to hear the door
chime.
4. Drive a screw through the holder into
each hole.
5. The transmitter can be slid in and out of
the holder. To lock the transmitter, fix it
with a size M2.6 screw at the bottom of
the holder.
+056#..+0)"
$#66'4+'5"#0&"
5'.'%6+0)"%*#00'.5
The door chime requires three AAA batteries
in the transmitter and three C batteries in the
receiver. For best performance and longest
life, we recommend RadioShack alkaline
. . . .
batteries.
+ " "6
0 6*' 4#05/+66'4
1. Slide the transmitter's battery
compartment door in the direction of the
arrow to remove it.
2. Use a small flat-blade screwdriver to
slide the switch inside the battery
compartment to the desired channel for
the transmitter.
