COPENHAGEN
owner's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COPENHAGEN and is the answer not in the manual?

Questions and answers

Related Manuals for Vifa COPENHAGEN

Summary of Contents for Vifa COPENHAGEN

  • Page 1 COPENHAGEN owner’s manual...

  • Page 3: Introduction

    You’ve chosen well The Vifa Copenhagen. A speaker that looks as good as it sounds. That you can bring almost everywhere. That will help you celebrate life. It’s designed to be intuitive for you to use. This manual just spells out the details - for instance, how to connect wirelessly in a flash.

  • Page 5: Table Of Contents

    Wi-Fi Network using a iOS device........14 Wi-Fi Network using WPS..........16 Playback through Wi-Fi............17 Wired connection - optical, analog or USB......18 Battery charge..............19 Reset and set to factory default.........20 Vifa app................21 Product care...............22 Troubleshooting..............23 Specifications..............24 Register and Trademarks............25 For manuals in other languages, please visit: www.vifa.dk/support...

  • Page 6: Buttons And Indicators On Copenhagen

    BUTTONS AND INDICATORS ON COPENHAGEN Status indicator Volume up Volume down Connect Power socket Power Aux optical and analog input Reset Battery indicator...

  • Page 7: Status Indicator

    Note: Putting Copenhagen into hibernation mode will double your battery time and still allow you to wake it up rapidly. In standby mode Copenhagen will have approx. 7 days of battery time and consume less than 0,5 watt from the power outlet.

  • Page 8: Input Options

    INPUT OPTIONS • Bluetooth Fast and easy and works for virtually every phone, tablet or MAC/PC - supports aptX for Hi-Fi sound. • Wi-Fi Works for phones, tablets, MAC/PC Wi-Fi and networked dlna enabled devices - supports Wi-Fi Direct. • Wired optical or analog For music players or media players without wireless connection.

  • Page 9: Connecting Priority

    3th priority is wired When no Bluetooth, USB or Wi-Fi is used, you can use the wired input. You can however lock Copenhagen to wired input, look for further information on page 20.

  • Page 10: Bluetooth

    2. Select the Vifa device on your Bluetooth enabled device. 3. Let the music play. You can adjust to volume up and down on the front of Copenhagen and on the playback device. Note: Release of the Bluetooth paring can be done either on Copenhagen or the paired device, on Copenhagen just press and hold both the “Volume up”...

  • Page 11: Wi-Fi Direct

    3. Select the network called VIFA_..(No password required) 4. Play music on your device - when the status indicator turns WHITE the connection is established. Note: You can release Copenhagen from Wi-Fi direct mode - just press the connect button shortly.

  • Page 12: Wi-Fi Network Manual Setup

    CONNECTING TO YOUR WI-FI NETWORK Manual Set-up VIFA_AIRPLAY 1. Press and hold the CONNECT button until the status indicator flash WHITE rapidly and then release the CONNECT button – the indicator will now start to pulse until it receives a music signal. 2.
  • Page 13 VIFA AIRPLAY SETUP 5. Now the Copenhagen setup page open up. 6. Choose your network and enter the password if needed. Then type in the name you want displayed for Copenhagen on the network ex. “Copenhagen Living room”. 7. Then press “Apply”.

  • Page 14: Wi-Fi Network Using A Ios Device

    CONNECTING TO YOUR WI-FI NETWORK Using iOS device 1. Make sure your iOS device is connected to your network. 2. Connect your iOS device to Copenhagen using a USB cable. 3. Press and hold the CONNECT button on Copenhagen until the status indicator flashes YELLOW rapidly and then release the CONNECT button.
  • Page 15 4. The iOS device will ask you if it may transfer network settings to the speaker. Press Allow on the iOS device. 5. When the status indicator on Copenhagen turns WHITE, the connection is established.

  • Page 16: Wi-Fi Network Using Wps

    Using WPS Press WPS button on your router. Press and hold the CONNECT button until the status indicator flashes YELLOW rapidly and then release the CONNECT button. 3. When the status indicator on Copenhagen turns WHITE, the connection is established.

  • Page 17: Playback Through Wi-Fi

    You can even remote control iTunes with a free Apple remote app. This way you can control the music stream from iTunes to multiple Vifa Copenhagen with your iPhone, iPod or iPad LIVE STREAMING We recommend that you connect Copenhagen to your home Wi-Fi network when possible.

  • Page 18: Wired Connection - Optical, Analog Or Usb

    MP3 players, media streamer or TV USB / iOS device • On the back of Copenhagen the 3,5 mm mini-jack auxiliary input, will support 2 channel analog signal or optical input with a digital data stream up to 24bit/192kHz. •...

  • Page 19: Battery Charge

    BATTERY CHARGE Power socket Power Battery indicator A full charge will take 3-4 hours. Keep Copenhagen plugged in when near power outlet. The intelligent power manage- ment will keep the battery in perfect condition. When charging you can see the progress.

  • Page 20: Reset And Set To Factory Default

    POWER and the CONNECT button simultaneously until the status indicator starts triple flashing. Release the buttons and Copenhagen will go to factory default – after factory default ALL USER SETTINGS WILL BE LOST. To firmware update Copenhagen, please go to the...

  • Page 21: Vifa App

    To get the most of your Vifa Copenhagen download the free Vifa app. You can find link’s to the app. under “support” on the Vifa WEB This will allow you to: / The Vifa app allows you to: • Adjust the sound to your preferred taste or surroundings •...

  • Page 22: Product Care

    5 - 40°C (40 - 105°F). CLEANING Your Vifa product is covered by beautiful highly durable textile from Kvadrat. Remove non-greasy stains by carefully dabbing with a lint-free cloth or use a lint roller to remove lint from the textile.

  • Page 23: Troubleshooting

    Copenhagen to standby mode by pressing the POWER button for 4 seconds. After this, please unplug the power cord and wait for ap- proximately 5 min. before plugging in Copenhagen to the power again. Here you can find further support on our Vifa products:...

  • Page 24: Specifications

    Lithium Ion battery Force Balanced Woofers Digital pure path amplifiers Driver units Tweeter 2 X 28 mm Vifa driver unit with soft dome and neodymium magnet Midrange 2 X 50 mm Vifa driver unit with aluminium cone and neodymium magnet...

  • Page 25: Register And Trademarks

    RoHS directive – see product label for more regional regulatory approvals. Vifa Copenhagen AirPlay works with iPod touch (4th, 3rd and 5th generation), iPhone (5S, 5C, 5, 4S, 4, 3GS), iPad (4th, 3rd, 2nd and 1st generation), iPad mini, with IOS 4.3.3 and iTunes 10.2.2 (Mac or PC) or later.
  • Page 26 IMPORTANT STATEMENTS: This device complies with Part 15 of the FCC Rules. Its operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme à...
  • Page 27 User manuals for licence-exempt radio apparatus shall contain the following or equivalent notice in a conspicuous location in the user manual or alternatively on the device or both. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device.
