Summary of Contents for Radio Shack ET-532
- Page 1 43-1032.fm Page 1 Tuesday, August 17, 1999 9:41 AM Cat. No. 43-1032 OWNER’S MANUAL Please read before using this equipment. ET-532 10-Channel Cordless Telephone with LCD Display...
- Page 2 © 1995 Tandy Corporation. COM-LOK and Radio Shack are registered trademarks used by Tandy Corporation. Handset Volume Control — lets you control the volume of the sound you hear through the handset.
- Page 3 This telephone has been tested and found to comply with all applicable UL and FCC standards. Your ET-532 operates on standard ra- dio frequencies, as allocated by the FCC. Therefore, it is possible for other radio units operating on similar fre-...
-
Page 4: Read This Before Installation
43-1032.fm Page 4 Tuesday, August 17, 1999 9:41 AM READ THIS BEFORE INSTALLATION We have designed your telephone to conform to federal regulations, and you can connect it to most telephone lines. However, each device that you connect to the phone line draws power from the phone line. -
Page 5: Table Of Contents
43-1032.fm Page 5 Tuesday, August 17, 1999 9:41 AM CONTENTS Installation ... 6 Selecting a Location ... 6 Installing the Phone ... 6 Preparation ... 7 Installing the Battery ... 7 Charging the Battery ... 7 Setting the Dialing Mode ... 8 Operation ... -
Page 6: Installation
If the phone line jack is not a modular jack, you must update the wiring your- self, using jacks and adapters avail- able at your local Radio Shack store. Or, you can let the phone company up- date the wiring for you. -
Page 7: Preparation
43-1032.fm Page 7 Tuesday, August 17, 1999 9:41 AM PREPARATION INSTALLING THE BATTERY Before you use your phone for the first time, you must install and charge the battery. To install the battery, slide off the bat- tery compartment cover on the back of the handset, connect the battery’s plug to the pins inside the compartment, and place the battery inside the com-... -
Page 8: Setting The Dialing Mode
43-1032.fm Page 8 Tuesday, August 17, 1999 9:41 AM • If the CHARGE/TALK indicator does not light when you place the handset on the cradle, be sure the battery is connected to the pins inside the battery compartment and the AC adapter is securely connected to the base. -
Page 9: Operation
43-1032.fm Page 9 Tuesday, August 17, 1999 9:41 AM OPERATION Your ET-532’s LCD display shows telephone numbers as you dial them or when you recall them from memory. It shows the current channel number and lets you know when battery power is growing weak or the phone is out of range of the base. -
Page 10: Reducing Interference
43-1032.fm Page 10 Tuesday, August 17, 1999 9:41 AM • You can make or answer a call on a phone on the same line as the cordless phone, even if the hand- set is away from the base. • appears when the dis- RANGE tance from the handset to the base is out of the phone’s range. -
Page 11: Using Tone Services On A Pulse Line
43-1032.fm Page 11 Tuesday, August 17, 1999 9:41 AM For example, if you have call waiting, press to take an incoming call FLASH without disconnecting the current call. FLASH appears. Press FLASH to return to the first call. Notes: • If you do not have special phone services, pressing FLASH disconnect the current call. -
Page 12: Storing A Number In Memory
43-1032.fm Page 12 Tuesday, August 17, 1999 9:41 AM Notes: • If is set to TONE/PULSE and you want to use tone dialing for a memory number, you must store the tone entry along with the number. • To keep your accounts secure, we recommend you do NOT store your personal access code for services such as bank-by-phone... -
Page 13: Entering A Pause In A Memory Number
43-1032.fm Page 13 Tuesday, August 17, 1999 9:41 AM 5. Pull out the memory index card at the bottom of the base. Write the person’s or company’s name and index number on the sheet in pen- cil (in case you want to change it later). -
Page 14: Chain Dialing
43-1032.fm Page 14 Tuesday, August 17, 1999 9:41 AM 2. When you hear a dial tone, press , then press the number MEMORY buttons for the correct memory location. stored appears on the display, and the phone dials the stored number. Method 2 1. -
Page 15: Troubleshooting
If they do and the problem does not seem to be with your phone service, take your phone to your local Radio Shack store for assistance. Problem: The handset does not work. Solutions: •... - Page 16 43-1032.fm Page 16 Tuesday, August 17, 1999 9:41 AM Problem: Can make calls, but tele- phone does not ring. Solution: • Telephone company may be using unusual ringing methods. Your telephone is designed for stan- dard straight line bridged ringing. •...
-
Page 17: Care And Maintenance
FCC authorization to operate it. If your phone is not performing as it should, take it to your local Radio Shack store for assistance. If the trouble is affecting the phone lines, the phone company might... -
Page 18: Replacing The Battery
3.6 volt, 300 milliamp battery with a connector that fits the connector in the battery compartment. You can order a replacement battery through your local Radio Shack store. Install the new battery as described below, then charge the battery (see “Charging the Battery”). -
Page 19: Lightning
43-1032.fm Page 19 Tuesday, August 17, 1999 9:41 AM Your phone might cause TV or radio interference even when it is operating properly. To determine whether your phone is causing the interference, turn off your phone. If the interference goes away, your phone is causing the interference. - Page 20 RADIO SHACK LIMITED WARRANTY This telephone product is warranted against manufacturing defects in material and workmanship for one (1) year from the date of purchase from Radio Shack company owned stores and authorized Radio Shack franchisees and dealers. Within this period bring your Radio Shack sales slip as proof-of-purchase date to any Radio Shack store.
