- Page 1 900MHz Cordless Telephone with Call Waiting/Caller ID...
-
Page 2: Important Information
ˆ Important Information This telephone has been tested and found to comply with all applicable UL and FCC standards. WARNING: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. -
Page 3: Important Safety Instructions
you can take the necessary steps to prevent interruption of your telephone service. LIGHTNING Your telephone has built-in protection circuits to reduce the risk of damage from surges in telephone line and power line current. These protection circuits meet or exceed the FCC requirements. - Page 4 may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 16. To reduce the risk of electric shock, do not disassemble this product. Take it to a qualified service technician when service or repair work is required.
-
Page 5: Table Of Contents
ˆ Contents Important Information ... 2 Features ... 6 Installation ... 7 Selecting a Location ... 7 On a Desk Top ... 7 On a Wall Plate ... 7 Connecting and Charging the Battery Pack ... 8 Setting the Dialing Mode ... 9 Setting the Ringer Tone and Volume ... -
Page 6: Features
ˆ Features Thank you for purchasing the RadioShack 900 MHz Cordless Telephone. Your phone uses advanced technology to give you superior audio quality and extended range. The phone’s Caller ID unit records each caller’s telephone number (and name, if available in your area) and the date and time of the call, as provided by your local phone company to Caller ID service subscribers. -
Page 7: Installation
ˆ Installation SELECTING A LOCATION You can place the phone’s base on a desk or table, or mount it on a standard wall plate or directly on a wall. Select a location that is: • near an accessible AC outlet •... -
Page 8: Connecting And Charging The Battery Pack
3. Route the adapter and modular cords through the grooves on the bottom of the base. 4. Plug the short modular cord into the wall plate jack, then align the base’s keyhole slots with the wall plate studs and slide the base down to secure it. -
Page 9: Setting The Dialing Mode
about 5 seconds to reset the security access-protection code. • If the base loses power for about an hour while the handset is away from it, the security access-protection code might be lost. To reset the code, return the handset to the base for about 5 seconds. -
Page 10: Setting The Ringer Tone And Volume
Note: If your phone system requires that you dial an access code (9, for example) before you dial an outside number, do not dial the access code either. If the dial tone stops, you have touch- tone service. If the dial tone continues, you have pulse service. -
Page 11: Selecting The Language
such an area, do not store the area code. Follow these steps to store your area code. 1. Lift the handset and hold down 7kje 7kje 7kje 7kje JWba until the menu appears with selected. 9 9 9 9 2. Press to move the cursor to 9eZ[0 9eZ[0... -
Page 12: Adjusting The Handset's Volume
ADJUSTING THE HANDSET’S VOLUME To adjust the volume of the sound you hear through the handset during a call, press 9 9 9 9 on the handset until you obtain the Lebkc[ Lebkc[ Lebkc[ CWn_ckc Lebkc[ CWn_ckc CWn_ckc CWn_ckc desired volume level. Lebkc[ >_]^ Lebkc[ >_]^... -
Page 13: Memory Dialing
Notes: • Connecting a headset disconnects the handset’s earpiece and microphone. 8 8 8 8 9 9 9 9 • on the handset also controls the headset’s volume. • If you place the handset on the base to recharge it while the headset is connected, be sure the handset seats properly. -
Page 14: Entering A Pause
7. Enter the number and any tone and pause entries (see “Using Tone Services on a Pulse Line” on Page 12 and “Entering a Pause”). Note: Each tone or pause entry uses one digit of memory. 8. Press . The phone beeps and SELECT C[ceho C[ceho... -
Page 15: Chain-Dialing Service Numbers
activates), then press the desired memory location number. Chain-Dialing Service Numbers For quick recall of numbers for special services (such as bank-by-phone), store each group of numbers in its own memory location. Dial the service’s main number first. Then, at the appropriate place in the call, press ˆ... -
Page 16: Caller Id Messages
name (if available), and the third line shows the caller’s phone number. Caller ID Messages Display English Description French D[m0ýN D[m0ýN D[m0ýN D[m0ýNN N N N Shows the number of JejWb0ýNN JejWb0ýNN JejWb0ýNN JejWb0ýNN new Caller ID records (records you have not Dekl Dekl$ $ $ $ 0 0 0 0 ýNN ýNN... -
Page 17: Deleting Caller Id Records
3. Choose a memory location ( – pressing a number or by repeatedly 8 8 8 8 9 9 9 9 pressing , then press If the selected location is empty, the phone beeps to confirm that it stored the number, then the Caller ID record appears. -
Page 18: Troubleshooting
ˆ Troubleshooting We do not expect you to have any problems with your phone, but if you do, these suggestions might help. Problem The phone does not Be sure the base’s phone line cord and AC adapter are correctly and securely work or works poorly. -
Page 19: Care
Problem The handset does not Move the handset closer to the base. ring or receive a page. Lift base’s antenna to a vertical position. Be sure the battery pack in the handset is connected and charged. Move the base away from other electrical devices. You have an incoming Let the phone ring twice before you answer so the system has time to record call, but do not receive... - Page 20 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102 RadioShack Corporation Fort Worth, Texas 76102 12/99 43-1122 UCZZ01346BZ 10A01 Printed in China...
