Summary of Contents for Pyle view PLVSHR77

  • Page 1 7" WIDE SCREEN 16:9 TFT-LCD MONITOR PLVSHR77...

  • Page 2: Table Of Contents

    1. Table of Contents------------------------------------- 1 2. Warning ----------------------------------------------- 1 3. Installation -------------------------------------------- 2 4. Features ----------------------------------------------- 3 4.1 Features ------------------------------------------- 3 4.2 Remote Control Bar ------------------------------ 3 4.3 Function keys at front panel --------------------- 4 5. Installation for Monitor ------------------------------ 5 6.

  • Page 3: Installation

    3. INSTALLATION 1. Rotate the locking knob on the neck of the mounting stand clockwise. 2. Slide the engagement head on the mounting stand into the slide bracket slot on the rear of the monitor housing. 3. Rotate the locking knob counterclockwise until it is hand-tight and the monitor is securely fastened to the neck of the mounting stand.

  • Page 4: Features

    4. Function: 4.1 Features 10 RED 11 YELLOW 12 RED 13 BLACK 1. Headphone Jack 2. Power 3. UP key 4. IR Sensor 5. Down key 6. Menu 7. AV-IN Jack 4.2 Remote Control Bar TV/AV MUTE POWER TV/CATV POWER MUTE 1 2 3 4 5 6 7 8...

  • Page 5: Function Keys At Front Panel

    4.3 FUNCTION KEYS AT FRONT PANEL 1. MENU FUNCTIONS CONTRAST: Press BRIGHTNESS: Press COLOR: Press SHARPNESS: Press SOURCE IN: Selection button VOLUME: Press MODE: 16:9 / 4:3 LEFT / RIGHT: Left/Right Revolving RECALL: The Display will Return to The Original by Factory. EXIT: Exit Menu Mode.

  • Page 6: Installation For Monitor

    5. Installation for Monitor Note It is recommended that the fitting is carried out at a specialist workshop.
  • Page 7 Release Key...

  • Page 8: Accessories

    6. ACCESSORIES (1) Monitor Stand x 1 (2) System Cable x 1 (3) Operation Manual x1 (4) Release Key x1 (5) Remote Controller x 1 (6) Warranty Card x 1 7. Specifications 1. Supply voltage 2. Power consumption: 3. Operating temperature: 4.
