Summary of Contents for Pyle PLCD41MP
- Page 1 PLCD41MP CD/MP3 PLAYER... WNER'S MANUAL A M / F M R E C E I V E R...
- Page 2 Radio wiring Speaker wiring Install the unit Removing the unit Power Volume Eject Mode Loud Clock Release Volume setting Bass setting Treble settting Balance setting Fader setting Play/pause Scan Repeat Band Band tuner Direct access tuning Loading and Replacing the battery Basic operation...
- Page 3 To prevent injur y or fire,take the following precautions: Insert the unit unt l it is firmly locked to the main unit, otherwise it may fall out of place when jolted When extending the ignition, memory back up or ground cable, use diameter of 0.75mm(AWG18) or more automotive grade cable to avoid wire deterioration or damage...
-
Page 4: Speaker Wiring
Follow this easy wiring diagram in order to enable you to install the new or existing RADIO and SPEAKER wring system. Be sure the unit is connected to a 12 volts battery with negative ground. Good ground connections eliminate most electrical noise problem and require tight with the metal vehicle chassis. -
Page 5: Install The Unit
efore installing the receiver permanently, fit it in the approximate place in your car Connect the equipment according to the speakers and electrical connections. When your system is operated properly,(preferably with the car engine running), follow the instructions for permanent installation of your system. -
Page 6: Lcd Display
POWER ON /OFF VOLUME SELECT RELEASE LOUD Power Tur ning ON the power Press the [PWR]button. Press to turn on the unit power,Press the button to turn off the unit. Volume EJECT Increasing volume Rotate the [VOL+]button Decreasing Rotate the [VOL-]button SEEK BAND CLOCK... - Page 7 MODE Selecting radio and play Press the [MODE]key. Each time you press the key, it`ll switch between radio and CD position. (If mode with AUX IN,the function is below: press MD(MODE)to select: 1 If with DISC,press MD that is: AUX IN RADIO DISC AUX IN...
-
Page 8: Speaker Mode
Speaker mode VOLUME TREBLE BASS FADER BALANCE In press mode, VOL is sel function Volume set mode Press SEL button once,display shows VOL , then rotate the volume + button to adjust volume level up.rotate the volume - button to adjust volume level down. - Page 9 Play/pause Pause If with DISC in unit,Press the [ ]to pause music. Play Press the [ ]button again ,then come back to DISC playing. Scan Press [SCN]button Press this button once for TRACK INTRODUCTION. The first 10 seconds of each track on the disc will play. And the track number shows on LCD.
- Page 10 PRESET MEMORY 1-6 Band Selecting band Press BAND button to select among three FM or two AM bands. (FM1-FM2-FM3-AM) If with DISC in unit, press [MODE] switch to radio MODE first. Tuner In radio mode: manual tuning: SEEK- short press button it can select higher frequency station.
-
Page 11: Basic Operation
MODE MUTE MODE BAND POWER BAND/LOUD MUTE STU7 ENTER -,_,+,0 SCAN REPEAT LOUD PAUSE AS/PS AS/PS PAUSE SCAN LOCAL SHUF DISC DN DISC UP MONO RO/SN MONO CHAR.SEL VOL+/CHAR.SEL VWX8 SHIFT SELECT SPACE CHAR.SEL _,-,+,0,PWR Mode select MUTE S,T,U, ,MODE Enter,BAND Char.sel(A,B~8,9,0),+/- A,B,C,1,PAUSE... -
Page 12: Other Function
Press ID3 on remote or Panel enter ID3 selection. one press ID3 enter ID3 file selection mode, F will be indicated on LCD. To read in your desired song name by pressing remote - buttons, then press confirmed the song playing. BAND ENTER EXAMPLE: to read in "... - Page 13 Specifications subject to change without notice. CD PLAYER Signal/Noise radio...70dB Frequency response...20Hz-20KHz(+3dB) Channel separation...>45dB Dual D/A converter...16Bit FM Tuner Tuning range...USA:87.5-108MHz EUROPE:87.5-108.0MHz FM usable sensitivity(S/N=30dB)...<12dB Stereo separation...>45dB AM Tuner Tuning range...USA:520-1620KHz EUROPE:522-1620KHz AM sensitivity...28dB GENERAL Operating power...12 Volts DC,negative %10THD output wiring...Designed for using four Load impedance...compatible 4 to 8 ohm (100KHz step) Fuses...1amp and 10 amp...
- Page 14 What might seem to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems. ?The power does not tur n ON. The fuse has blown. Install half sleeve, can be with or ?NO Sound.
- Page 15 CD/MP3 PLAYER A M / F M R E C E I V E R W I T H E S P F O R C D 4 0 S , M P 3 7 0 - 1 2 0 S C a r A u d i o H i f i...
