43-972.fm Page 1 Monday, August 16, 1999 4:19 PM
Cat. No. 43-972
OWNER'S MANUAL
Please read before using this equipment.
System 2000
100 Number Memory
2-Line Caller ID
With 100 Caller ID Memo-
ries

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYSTEM 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Radio Shack SYSTEM 2000

Summary of Contents for Radio Shack SYSTEM 2000

  • Page 1 43-972.fm Page 1 Monday, August 16, 1999 4:19 PM Cat. No. 43-972 OWNER’S MANUAL Please read before using this equipment. System 2000 100 Number Memory 2-Line Caller ID With 100 Caller ID Memo- ries...
  • Page 2 43-972.fm Page 2 Monday, August 16, 1999 4:19 PM Warning: To prevent fire or shock hazard, do not expose this product to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK.
  • Page 3 43-972.fm Page 3 Monday, August 16, 1999 4:19 PM FEATURES Your RadioShack Caller ID System 2000 is the latest in telephone Caller ID technology. If Caller ID service is available in your area and you subscribe to it, the telephone company sends the caller’s telephone number (and name, if available in your area) and the date and time of the call between the first and second rings.
  • Page 4 43-972.fm Page 4 Monday, August 16, 1999 4:19 PM Large Display — makes it easy to see caller information, phone line in- formation, and the current time and date. Clock and Date Display — displays the current time and date as provid- ed to Caller ID service subscribers by your local telephone company.
  • Page 5 43-972.fm Page 5 Monday, August 16, 1999 4:19 PM This module has been tested and found to comply with all applicable UL and FCC standards. Important Information: • To use this module, you must be in an area where Caller ID service is available, and you must subscribe to the service.

  • Page 6: Fcc Information

    43-972.fm Page 6 Monday, August 16, 1999 4:19 PM FCC INFORMATION We have designed your module to conform to federal regulations, and you can connect it to most telephone lines. However, each module (and each device, such as a telephone or answering machine) that you con- nect to the telephone line draws power from the line.
  • Page 7 43-972.fm Page 7 Monday, August 16, 1999 4:19 PM In the unlikely event that your module causes problems on the phone line, the phone company can temporarily disconnect your service. If this hap- pens, the phone company attempts to notify you in advance. If advance no- tice is not practical, the phone company notifies you as soon as possible and advises you of your right to file a complaint with the FCC.
  • Page 8 43-972.fm Page 8 Monday, August 16, 1999 4:19 PM Consult your local RadioShack store if the problem continues. If your module is not performing as it should, check its connection to your phones and the phone lines. If you are unable to locate the prob- lem, take your module to your local RadioShack store for assistance.

  • Page 9: Table Of Contents

    43-972.fm Page 9 Monday, August 16, 1999 4:19 PM CONTENTS Preparation... 11 Connecting the Supplied AC Adapter... 11 Installing/Replacing the Battery... 12 Setting the Display Language... 16 Adjusting the Display Contrast ... 17 Connecting to the Phones/Phone Lines ... 18 Two-Line Phone/Two-Line Phone Line Jack ...
  • Page 10 43-972.fm Page 10 Monday, August 16, 1999 4:19 PM Care and Maintenance... 33 Lightning ... 34...

  • Page 11: Preparation

    43-972.fm Page 11 Monday, August 16, 1999 4:19 PM PREPARATION CONNECTING THE SUPPLIED AC ADAPTER The supplied AC adapter provides power for the module. Please note that although the module displays a time and date when you connect power, the displayed time and date are incorrect until the phone compa- ny sends the correct time and date during the first call.

  • Page 12: Installing/Replacing The Battery

    43-972.fm Page 12 Monday, August 16, 1999 4:19 PM Follow these steps to connect the AC adapter. 1. Plug the AC adapter’s barrel plug into the module’s 2. Plug the AC adapter into a standard AC outlet. INSTALLING/REPLACING THE BATTERY The module uses a 9-volt battery to protect its memory if the power fails.
  • Page 13 43-972.fm Page 13 Monday, August 16, 1999 4:19 PM Notes: • If AC power fails or if the AC adapter is disconnected, the module automatically tests the battery each time it receives a new call. When appears on the display or the display dims (even after you restore power), replace the battery.
  • Page 14 43-972.fm Page 14 Monday, August 16, 1999 4:19 PM 2. Use a coin or other flat object to turn the screw on the bottom of the module to , then slide off the battery compartment cover. OPEN 3. Remove and discard the old battery. Important: Do not press any buttons after you remove the battery.
  • Page 15 43-972.fm Page 15 Monday, August 16, 1999 4:19 PM Caution: Always remove an old or weak battery. Batteries can leak chemicals that can damage electronic circuits. 4. Before the display dims, slide the fresh battery into the compart- ment as indicated by the polarity symbols (+ and –) marked inside. Caution: Do not force the battery into the compartment.

  • Page 16: Setting The Display Language

    43-972.fm Page 16 Monday, August 16, 1999 4:19 PM SETTING THE DISPLAY LANGUAGE When you connect power to the module the first time, the module begins its start-up sequence. The message re- ceived indicator on the front of the mod- ule lights, and a test screen and the total memory capacity appear on the DELETE...

  • Page 17: Adjusting The Display Contrast

    43-972.fm Page 17 Monday, August 16, 1999 4:19 PM ADJUSTING THE DISPLAY CONTRAST Follow these steps to adjust the display’s contrast for the best visibility. 1. Press and hold down DELETE 2. While holding down DELETE to decrease the contrast or REVIEW Caution: While reviewing call records, if you hold down longer than 6 seconds without pressing a...

  • Page 18: Connecting To The Phones/Phone Lines

    43-972.fm Page 18 Monday, August 16, 1999 4:19 PM CONNECTING TO THE PHONES/PHONE LINES The module connects to your phone(s) and the phone line(s) using four modular phone line connectors. You can connect your module between a two-line phone (or one or two one-line phones) and a two-line modular phone line jack (or two one-line jacks).

  • Page 19: Two-Line Phone/Two-Line Phone Line Jack

    43-972.fm Page 19 Monday, August 16, 1999 4:19 PM Connecting to a Two-Line Phone and a Two-Line Phone Line Jack 9VDC Connecting to a Two-Line Phone and Two One-Line Jacks 9VDC...

  • Page 20: One-Line Phone/Two-Line Phone Line Jack

    43-972.fm Page 20 Monday, August 16, 1999 4:19 PM Connecting to a One-Line Phone and a Two-Line Phone Line Jack 9VDC Connecting to Two One-Line Phones and a Two-Line Phone Line Jack 9VDC...

  • Page 21: Two One-Line Phones/Two One-Line Jacks

    43-972.fm Page 21 Monday, August 16, 1999 4:19 PM Connecting to Two One-Line Phones and Two One- Line Jacks 9VDC CONNECTING TO AN ANSWERING MACHINE You can connect an answering machine to your module, phone, and phone line. After you connect the answering machine, set it to answer calls after at least two rings.

  • Page 22: Connecting For Both Lines Or Line 1 Only

    43-972.fm Page 22 Monday, August 16, 1999 4:19 PM Connecting for Both Lines or Line 1 Only 9VDC Connecting for Line 2 Only 9VDC...

  • Page 23: Mounting The Module

    43-972.fm Page 23 Monday, August 16, 1999 4:19 PM MOUNTING THE MODULE You can place the module directly on a desk, shelf, or table. Or, you can mount the module on a wall. To mount the module on the wall, you need two screws (not supplied) with heads larger than the holes on the back of the supplied mounting bracket.
  • Page 24 43-972.fm Page 24 Monday, August 16, 1999 4:19 PM 3. Route the phone line cords and AC adapter cord through the upper and lower slots on the mounting bracket. 4. Align the slots on the back of the module with the hooks on the mounting bracket, then gently push the module down on the mounting bracket to secure it.

  • Page 25: Operation

    43-972.fm Page 25 Monday, August 16, 1999 4:19 PM OPERATION RECEIVING AND STORING CALLS When you receive a call, the Caller ID information sent by the phone company, including the caller’s telephone number (and name, if avail- able) and the call’s date and time, automatically appears on the display between the first and second rings.

  • Page 26: Reviewing Calls

    43-972.fm Page 26 Monday, August 16, 1999 4:19 PM The module displays the current date and time (as sent by the tele- phone company with call information). REVIEWING CALLS • To select the line you want to review, press LINE SELECT LINE 1 LINE 2 appears on...
  • Page 27 43-972.fm Page 27 Monday, August 16, 1999 4:19 PM Notes: • If there are no calls stored in the module, on the display when you press a • -END OF LIST- appears on the display when you reach the last stored call record while pressing the •...

  • Page 28: Displayed Call Information

    43-972.fm Page 28 Monday, August 16, 1999 4:19 PM DISPLAYED CALL INFORMATION The module might display any of the following information. Indicator Appears instead of the phone number if the UNAVAILABLE caller is calling from outside a Caller ID ser- vice area.

  • Page 29: Line Error

    43-972.fm Page 29 Monday, August 16, 1999 4:19 PM Indicator Appears if there is an error in the Caller ID LINE ERROR transmission. Note: Minor electrical disturbances can af- fect the caller ID information. Occasional er- rors are normal. If the module frequently displays service provider or local RadioShack store for assistance.
  • Page 30 43-972.fm Page 30 Monday, August 16, 1999 4:19 PM Indicator Appears if the module received one or more (number of NEW L1= calls on a line since the last time you re- new calls) (num- viewed call records. The message received ber of new calls) indicator flashes rapidly.

  • Page 31: Deleting Calls

    43-972.fm Page 31 Monday, August 16, 1999 4:19 PM DELETING CALLS When the module’s memory is full, it automatically deletes the oldest call information when a new call arrives. You can also manually delete one or more calls on a line, and delete all calls on one or both lines. Deleting a Single Call 1.

  • Page 32: Deleting All Calls

    43-972.fm Page 32 Monday, August 16, 1999 4:19 PM Deleting All Calls Follow these steps to delete all calls on one line. 1. Repeatedly press LINE SELECT on the display. 2. Press REVIEW REVIEW 3. Quickly press and release DELETE about 5 seconds, the module deletes all calls on the line you selected and displays -NO CALLS-...

  • Page 33: Care And Maintenance

    43-972.fm Page 33 Monday, August 16, 1999 4:19 PM CARE AND MAINTENANCE Your RadioShack Caller ID System 2000 is an example of superior de- sign and craftsmanship. The following suggestions will help you care for the module so you can enjoy it for years.
  • Page 34 43-972.fm Page 34 Monday, August 16, 1999 4:19 PM Modifying or tampering with your module’s internal components can cause a malfunction and might invalidate the module’s warranty. If your module is not operating as it should, take it to your local RadioShack store for assistance.
  • Page 35 43-972.fm Page 35 Monday, August 16, 1999 4:19 PM NOTES...
  • Page 36 43-972.fm Page 36 Monday, August 16, 1999 4:19 PM RadioShack Limited Warranty This telephone product is warranted against manufacturing defects in material and work- manship for one (1) year from the date of purchase from RadioShack company owned stores and authorized RadioShack franchisees and dealers. Within this period bring your RadioShack sales slip as proof-of-purchase date to any RadioShack store.
