Radio Shack 43-3902 Owner's Manual

www.radioshack.com
OWNER'S MANUAL —
Please read before using this equipment.
Thank you for purchasing a RadioShack Adjustable
View Caller ID Box. Your Caller ID Box stores and
displays up to 64 multiple (name and number) or 99
single (number-only) Caller ID records. It displays the
caller's telephone number (and name, if available in
your area) and the current date and time, as provided
by your local phone company to Caller ID service
subscribers.
Where Caller ID is offered, one or more of the following
options are generally available:
• caller's number only
• caller's name only
• caller's name and number
The actual number of Caller ID records your Caller ID box
stores depends on the Caller ID information sent by the phone
company. If your phone company sends name-and-number
records, your Caller ID box stores up to 64 records. If your
phone company sends number-only records, your Caller ID
box stores up to 99 records.
! !
IMPORTANT
To use this Caller ID box, you must be in an
area where Caller ID service is available, and
you must subscribe to the service.
Ô
BATTERY NOTES
• Dispose of dead batteries promptly and
properly.
• Do not burn or bury batteries.
• Use only fresh batteries of the required size
and recommended type.
• Do not mix old and new batteries, different
types of batteries (standard, alkaline, or
rechargeable), or rechargeable batteries of
different capacities.
• When you replace the batteries, do not press
any buttons on the Caller ID box after you
remove the old batteries. Doing so could
erase all stored information.
!
IMPORTANT
If an icon appears at the end of a paragraph, go to the box on that page with
the corresponding icon for pertinent information.
SM
!
CALLER ID BOX SETUP
Caller ID is a service provided by your
telephone company. When you subscribe to
this service, between the first and second
rings, the telephone company sends the
caller's telephone number (and name, if
available) and the call's date and time. The
Caller ID box receives and displays this
information for each call and updates the
display with the current date and time. Your
Caller ID box saves up to 99 call records,
then replaces the oldest call record with
each new one.
I
NSTALLING
You need three AAA batteries (not supplied)
to power and protect the Caller ID box's
memory during a power failure. Batteries are
available at your local RadioShack store or
Ô
online at www.radioshack.com.Ô
1. Use a flat-blade screwdriver to lift the
compartment door on the bottom of the
Caller ID box.
2. Place three fresh AAA batteries (not
supplied) into the compartment as
indicated by the polarity symbols
(+ and –) marked inside.
3. Replace the battery cover and snap it
closed.
When $appears or the display dims,
replace the batteries.
!
Adjustable View Caller ID Box
Press to delete Caller ID
records, or confirm
Press to scroll through
programmed information.
Caller ID records and
program the Caller ID box.
B
ATTERIES
!
— Important
Ô
— Note
NEW
Call Light
C ID B C
ALLER OX ONNECTION
Your Caller ID box is ETL listed to UL
standards and meets all applicable FCC
requirements.
Your Caller ID box connects directly to a
modular telephone line jack. If your
telephone wiring does not have a modular
jack, you can update the wiring yourself
using jacks and adapters (available at your
local RadioShack store), or have the
telephone company update the wiring for
you. You must use compatible modular
jacks that are compliant with Part 68 of FCC
Rules and the requirements adopted by the
ACTA. The telephone cord and modular
plug provided is Part 68 compliant for
connecting to the telephone company
network.
The USOC number for both the single-line
and two-line jacks to be installed is RJ11C
(or RJ11W for a wall plate jack).
Connecting to a Single-Line
Phone
1. Disconnect the telephone line cord from
the modular phone jack on the wall and
plug it into the PHONE JACK on the
back of the Caller ID box.
2. Plug the Caller ID box's pre-wired
telephone line cord into the modular
phone jack on the wall.
©
2002 RadioShack Corporation.
All Rights Reserved.
RadioShack and RadioShack.com are trademarks used by
RadioShack Corporation.
43-3902
