Summary of Contents for Radio Shack TAD-1005
-
Page 1: Answering System
43-745.fm Page 1 Friday, August 13, 1999 2:16 PM Cat. No. 43-745 OWNER’S MANUAL Please read before using this equipment. TAD-1005 Multi-User Digital Telephone Answering System... - Page 2 Date/Time Stamp — records the day and time each message was recorded. © 1997 Tandy Corporation. Radio Shack is a registered trademark used by Tandy Corporation. Digitally-Synthesized guides you through operation of the system. Programmable Mailbox Code —...
- Page 3 43-745.fm Page 3 Friday, August 13, 1999 2:16 PM Call Screening — lets you listen as a caller leaves a message so you can decide whether or not to answer the call. Memo Recording — lets you leave messages for yourself or others in your home or office.
-
Page 4: Read This Before Installation
43-745.fm Page 4 Friday, August 13, 1999 2:16 PM READ THIS BEFORE INSTALLATION We have designed your TAD to con- form to federal regulations, and you can connect it to most telephone lines. However, each device that you con- nect to the phone line draws power from the line. -
Page 5: Table Of Contents
43-745.fm Page 5 Friday, August 13, 1999 2:16 PM CONTENTS Installation ... 6 Installing the Backup Battery ... 6 Connecting the AC Adapter ... 7 Connecting to the Telephone Line ... 7 Preparation ... 8 Setting the Day and Time ... 8 Setting the Mailbox Security Codes ... -
Page 6: Installation
We recommend you use an alkaline bat- tery, such as Radio Shack Cat. No. 23- 553. 1. Remove the battery compartment cover on the bottom of the TAD by removing the screw on the cover’s... -
Page 7: Connecting The Ac Adapter
You can convert the wiring your- self, using jacks 9V DC available at your local Radio Shack store. Or, you can let the phone com- pany update the wiring for you. • The phone company will charge you for the installation of neces- sary jacks. -
Page 8: Preparation
43-745.fm Page 8 Friday, August 13, 1999 2:16 PM PREPARATION Complete the procedures in this sec- tion before you set the TAD to answer calls. Note: The keypad is located under the cover on the front of the TAD. Lift the cover to access the keys. -
Page 9: Setting The Mailbox Security Codes
43-745.fm Page 9 Friday, August 13, 1999 2:16 PM SETTING THE MAILBOX SECURITY CODES To access each mailbox, you must en- ter a 2-digit mailbox security code. The security codes for Mailboxes 1, 2, 3, and 4 are preset to 01, 02, 03, and 04, respectively. -
Page 10: Setting The Number Of Rings
43-745.fm Page 10 Friday, August 13, 1999 2:16 PM SETTING THE NUMBER OF RINGS The TAD is preset to sound 4 rings be- fore it answers the first call. Follow these steps to change the number of rings (from 1-9). After recording its first call, the TAD answers after 2 rings. -
Page 11: Checking The Outgoing Announcement
43-745.fm Page 11 Friday, August 13, 1999 2:16 PM For example: “You have reached the Jones residence. We are unable to come to the phone right now, but you may press: 1 to leave a message for John, 2 to leave a message for Mary, 3 leave message... -
Page 12: Recording The Memory Full Announcement
43-745.fm Page 12 Friday, August 13, 1999 2:16 PM Recording the Memory Full Announcement The TAD has a built-in memory full an- nouncement. When the memory be- comes full and the TAD can no longer record messages, the TAD announces “The memory is full.”... -
Page 13: Basic Operation
43-745.fm Page 13 Friday, August 13, 1999 2:16 PM BASIC OPERATION Be sure you complete the procedures in “Installation” and “Preparation” be- fore you begin using the TAD. SETTING THE TAD TO ANSWER CALLS Press appears on the dis- ON/OFF play. -
Page 14: Using The Mailbox Feature
43-745.fm Page 14 Friday, August 13, 1999 2:16 PM • If the TAD answers when the memory is full, it plays the mem- ory full announcement and beeps, waits 7 seconds for any remote operation commands (see “Using Remote Operation Commands”), then hangs up. -
Page 15: Using The Announcement-Only Feature
43-745.fm Page 15 Friday, August 13, 1999 2:16 PM USING THE ANNOUNCEMENT-ONLY FEATURE With the announcement-only feature turned on, you can leave an initial phone answering message and a menu of five additional messages for callers to hear. Callers cannot leave messages, but they can select the an- nouncements they want to hear. -
Page 16: Deleting An Announcement
43-745.fm Page 16 Friday, August 13, 1999 2:16 PM 4. Press to stop playback, or ON/OFF wait until the TAD finishes playing back the announcement. Deleting an Announcement To delete an announcement, press while the announcement is PGM/DEL playing. SCREENING CALLS To screen your calls, let the TAD an- swer all calls for you, and listen to the caller’s message through the TAD’s... -
Page 17: Playing Mailbox Messages
43-745.fm Page 17 Friday, August 13, 1999 2:16 PM To save the messages, see “Saving/ Deleting Messages.” To replay the general messages, sim- ply press again. PLAY To play back a memo (see “Recording a Memo”), press and release To play back a 2-way phone conversa- tion (see “Recording a 2-Way Phone Conversation”), press and release Playing Mailbox Messages... -
Page 18: Recording A Memo
43-745.fm Page 18 Friday, August 13, 1999 2:16 PM To save all memos, press SAVE press MEMO To save all 2-way recordings, press , then press SAVE 2-WAY To delete all incoming messages, press , then press PGM/DEL PLAY To delete all memos, press PGM/DEL then press MEMO... -
Page 19: Remote Operation
43-745.fm Page 19 Friday, August 13, 1999 2:16 PM REMOTE OPERATION While you are away from your home or office, you can use a touch-tone phone or a pulse (rotary) phone with a pocket tone dialer to enter your security code and do any of the following: •... -
Page 20: Using Remote Commands
43-745.fm Page 20 Friday, August 13, 1999 2:16 PM USING REMOTE COMMANDS Note: The TAD automatically resets to answer calls after remote operation, but does not automatically delete mes- sages you played by remote. Follow these steps to operate the TAD from a remote touch-tone phone. -
Page 21: List Of Remote Commands
43-745.fm Page 21 Friday, August 13, 1999 2:16 PM List of Remote Commands Use these keys on a touch-tone phone or pocket tone dialer to operate the TAD when you are away from your home or office. Number Play memo messages. Play messages. -
Page 22: Problem-Solving
We do not expect you to have any problems with your TAD, but if you do, try these suggestions. If the TAD still doesn’t operate as you think it should, take the TAD to your local Radio Shack store for assistance. Problem... - Page 23 43-745.fm Page 23 Friday, August 13, 1999 2:16 PM Problem You entered an incorrect remote security code. The TAD does not respond to remote commands. AC power failure. The OGM is too short to The TAD sounds three allow remote access. short beeps when you The TAD’s memory is full.
-
Page 24: Resetting The Tad
43-745.fm Page 24 Friday, August 13, 1999 2:16 PM RESETTING THE TAD If the TAD hangs up for an unknown reason, you might need to reset it. Important: Resetting the TAD deletes all recorded messages (including any outgoing announcements), date and time settings, number of rings, mes- sage length, and all mailbox and re- mote operation codes. -
Page 25: Care And Maintenance
If your TAD is not performing as it should, take it to your local Radio Shack store for assistance. If the trouble is affecting the phone lines, the phone company might ask you to disconnect your TAD until you have re-... -
Page 26: The Fcc Wants You To Know
43-745.fm Page 26 Friday, August 13, 1999 2:16 PM THE FCC WANTS YOU TO KNOW In the unlikely event that your TAD causes problems on the phone line, the phone company can temporarily disconnect your service. If this hap- pens, the phone company attempts to notify you in advance. - Page 27 43-745.fm Page 27 Friday, August 13, 1999 2:16 PM NOTES...
- Page 28 In the event of a product defect during the warranty period, take the product and the Radio Shack sales receipt as proof of purchase date to any Radio Shack store. Radio Shack will, at its option, un- less otherwise provided by law: (a) correct the defect by product repair without charge for parts and labor;...
Need help?
Do you have a question about the TAD-1005 and is the answer not in the manual?
Questions and answers
Machine blinking CL. Phone rings and answering machine not picking up
When the Radio Shack TAD-1005 is blinking "CL" and not picking up calls, it likely indicates a problem with the unit's setup or connections. Possible causes include:
- The TAD is not set to answer calls. Remedy: Press ON/OFF to enable answering.
- The phone line is not properly connected. Remedy: Check all phone line connections.
- The TAD is not plugged into the wall outlet. Remedy: Make sure the AC adapter is properly connected.
- There is not enough memory to record a message. Remedy: Erase messages.
The "CL" blink may also signal a clock or setup issue, though it is not explicitly defined in the context.
