SuperLoader™ 3A Series

Quick Start Guide

®
The Quantum
SuperLoader™ 3A Series autoloader is an automated
storage and retrieval device with an integrated A-Series tape drive and up
to two tape magazines holding up to eight cartridges each. It has a built-in
FTP server and Web interface.
For more information, see the SuperLoader 3A Series User's Guide
(PN 81-81643) and the A-Series FTP File Server User's Guide (PN 81-81800) on
the documentation CD provided with your autoloader.
This quick start guide uses the following conventions:
Note:
Notes emphasize important information related to the main
topic.
Cautions indicate potential hazards to equipment and are
Caution:
included to prevent damage to equipment.
Warning:
Warnings indicate potential hazards to personal safety and
are included to prevent injury.
This document explains how to unpack the SuperLoader 3A Series
autoloader and install it in a standard 19-inch rack.

Choosing a Location

The autoloader is designed to fit in a standard 19-inch rack using either the
long or short brackets (depending on the depth of the rack). The autoloader
uses standard rack mounting hardware.
Note:
It is recommended that you review this entire document prior to
beginning the installation.
SuperLoader 3A Series
Choosing a Location.......................... 1
Taking ESD Precautions ................. 3
Unpacking the Autoloader................ 4
Checking Accessories ..................... 5
and Power Cables......................... 13
After the Installation....................... 14
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperLoader 3A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Quantum SuperLoader 3A Series

Summary of Contents for Quantum SuperLoader 3A Series

  • Page 1: Table Of Contents

    It has a built-in FTP server and Web interface. For more information, see the SuperLoader 3A Series User’s Guide (PN 81-81643) and the A-Series FTP File Server User’s Guide (PN 81-81800) on the documentation CD provided with your autoloader.

  • Page 2: Preparing For The Installation

    SuperLoader™ 3A Series Quick Start Guide Choose a location that meets the following criteria: Criteria Rack requirements Room temperature Power source Weight Air Quality Humidity Clearance Preparing for the Installation Before you begin the installation procedure in this section, make the following preparations as described in this section: •...

  • Page 3: Taking Esd Precautions

    Warning: Failure to take these safety steps may result in personal injury or equipment damage. Preparing for the Installation SuperLoader 3A Series...

  • Page 4: Unpacking The Autoloader

    Unpacking the Autoloader Before you begin, clear a desk or table so that you can unpack the autoloader. The SuperLoader 3A Series Quick Start Guide has all the necessary information to unpack and inspect your autoloader correctly. You also need to select an open 2U computer rack location near the server that will host the autoloader.

  • Page 5: Checking Accessories

    The following accessories are shipped with the SuperLoader 3A Series autoloader: Checking Accessories • • • • • • • You will also need the following parts that were shipped with your rack: • • Figure 1 Rack Mount Hardware...

  • Page 6: Rack Mounting The Autoloader

    SuperLoader™ 3A Series Quick Start Guide Rack Mounting the Autoloader This section provides the steps for attaching the autoloader directly to the stationary rails of a rack. Refer to Table 1 Rack Hole Types Figure Note: The rails within the rack have a hole pattern that repeats throughout the rail. 1 Install two clip nuts, 1.75 in.
  • Page 7 (72-A226-A) when the distance from the front mounting rail to the rear mounting rail is less than 30.25 in. (76.84 cm). Otherwise, use the short autoloader brackets (72-A225-A). Rack Mounting the Autoloader SuperLoader 3A Series Clip nut 1.75 in (44.45 mm)
  • Page 8 SuperLoader™ 3A Series Quick Start Guide Figure 3 Attaching Autoloader Brackets 3 Using rack screws, attach a support bracket to the clip nuts on each rear rail (see Autoloader Screws (10-32 x 1/4 only) Autoloader bracket figure Note: Be sure to attach the support brackets correctly; the side of the bracket with only two holes should be secured to the rail.
  • Page 9 (see figure Caution: Do not release the front end of the autoloader until it can be secured to the rack. Rack Mounting the Autoloader SuperLoader 3A Series Rack screws...
  • Page 10 SuperLoader™ 3A Series Quick Start Guide Figure 5 Sliding Autoloader into Rack 5 While the other installer holds the front end of the autoloader, secure the front end of Figure 6 Front Alignment Tab (one per side) 6 Install four screws (two per side) to secure the support brackets to the autoloader Autoloader bracket Support bracket the autoloader to the rack using four rack screws (two per tab) as shown in...
  • Page 11 • Four screws securing the autoloader tabs to the front rails. • Four screws securing the support brackets to the rear rails. • Four screws securing the autoloader brackets to the support brackets. Rack Mounting the Autoloader SuperLoader 3A Series...

  • Page 12: Autoloader Panel Overviews

    SuperLoader™ 3A Series Quick Start Guide Autoloader Panel Overviews The front panel allows you to configure the autoloader, enter commands, and obtain status information. Figure 8 Front Panel Overview The Ethernet ports on the back panel allow you to connect to the A-Series tape drive FTP file server and to the autoloader remote management interface.

  • Page 13: Contents

    Note: When the SuperLoader 3A Series is powered up, it undergoes a media inventory. Each tape cartridge in the autoloader is inserted into the A-Series tape drive and inventoried. Depending upon the number of cartridges in each magazine and the amount of content or data on each cartridge, the media cartridge inventory may take up to forty minutes.

  • Page 14: After The Installation

    For detailed information on the setup, operation, and administration of your system (including accessing and using the FTP file server), see the SuperLoader 3A Series User’s Guide (PN 81-81643) and the A-Series FTP File Server User’s Guide (PN 81-81800) on the documentation CD provided with your autoloader.
