Page 2 Quantum Corporation is prohibited by law and constitutes a punishable violation of the law. TRADEMARK STATEMENT DLT, SDLT, DLTtape III, DLTtape IV and Super DLTtape I are all trademarks of Quantum Corporation. Other trademarks may be mentioned herein which belong to other companies.
Page 3: Table Of Contents
Preface Chapter 1 Introduction External Features ... 1 Operation Indicators... 2 How the TC2201 Works ... 3 Processing SCSI Information... 3 LAN-free Backup and Restore ... 5 TC2201 Features ... 6 iSCSI Features ... 6 SCSI Bus Features... 6 Management Features ... 6 TC2201 Benefits ...
Page 4 Physical Specifications...8 Physical Dimensions...8 Operating Environment ...8 Non-operating Environment ...9 Power ...9 Chapter 2 TC2201 Web Interface Accessing TC2201 Web Interface ...11 Home Page ...12 System Page...13 Serial Port Settings ...14 iSCSI Settings ...15 iSNS Settings ...17 User Settings ...19 Real Time Clock Configuration...20...
Page 5 RJ-45 Ethernet Pin Assignments ... 63 Appendix B Inband SCSI-3 Commands General Commands ... 66 Report LUNs Command... 66 Inquiry Command ... 67 Vendor Unique Commands ... 70 Appendix C Using the Command Line Interface Power Up Messages... 72 Quantum TC2201 User’s Guide Contents...
Page 6 Procedure A: EMC Legato NetWorker ...129 Procedure B: Veritas NetBackup ...130 Procedure C: Veritas Backup Exec...131 Procedure D: CA Brightstor ARCserve...132 Procedure E: Bakbone NetVault...132 Procedure F: HP Data Protector ...133 Procedure G: CommVault Galaxy ...135 Quantum TC2201 User’s Guide...
Page 7 Contents Glossary Quantum TC2201 User’s Guide...
Page 8 Contents Quantum TC2201 User’s Guide viii...
Page 9 Figure 12 Figure 13 Figure 14 Figure 15 Figure 16 Figure 17 Quantum TC2201 User’s Guide Front Panel ... 2 TC2201 LEDs ... 2 Information Processing... 4 Flow of data and responses ... 5 LAN-free Backup... 5 Home Page ... 11 Password Dialog...
Page 10 Figure 41 Figure 42 Figure 43 Figure 44 Figure 45 Figure 46 Quantum TC2201 User’s Guide Ethernet Overrides Settings Page...26 SCSI Bus Page...27 SCSI bus Configuration Page ...28 SCSI Overrides Settings Page...29 SCSI target Overrides Settings Page ...30 Buffered Tape Writes Page...31 Discovery Page...33...
Page 11 Figure 49 Figure 50 Figure 51 Figure 52 Figure 53 Quantum TC2201 User’s Guide Clear all Entries from Current Map... 97 Registry Editor ... 130 Veritas Backup Exec... 131 Netvault Device Management... 133 HP Data Protector (Advanced Options) ... 135 CommVault Galaxy ...
Page 12 Figures Quantum TC2201 User’s Guide...
Page 13 Format of Report LUNs Command ... 66 Report LUNs Parameter List ... 67 Format of LUN Inquiry Command ... 67 Format of EVPD Page 0x80 ... 68 TC2201 LUN Inquiry Data ... 68 Vendor Unique Commands... 70 Main menu ... 73 Configuration menu... 74 User Settings Configuration Menu ...
Page 14 Table 42 Table 43 Table 44 Table 45 Table 46 Quantum TC2201 User’s Guide Parallel SCSI Configuration Menu ...84 SCSI Initiator Menu ...86 SCSI Target Overrides Menu ...87 Parallel SCSI Buffered Tape Write Configuration Menu...88 Device Mapping Main Menu ...90 Select Current Map ...91...
Page 15 Table 53 Table 54 Table 55 Table 56 Table 57 Quantum TC2201 User’s Guide Sysem Utility Menu... 113 Sysem Status/Statistics Menu ... 114 Parallel SCSI Protocol Status Menu ... 114 SCSI Device Display Menu ... 115 SCSI Resource Display... 116 Event Log Menu ...
Page 16 Tables Quantum TC2201 User’s Guide...
Page 17 This document is written for operators of the TC2201 router. Audience This document explains how to use the TC2201 router. Purpose This document is organized as follows: Document Organization • Chapter 1, • Chapter 2, TC2201 Web management interface. •...
Page 18 • Left side of the library — Refers to the left side as you face the component being described. Documents related to the PX502, PX506, and PX510 tape libraries are Related shown below: Documents Quantum TC2201 Series Documentation Document No. 81-81538 Quantum TC2201 User’s Guide Notes emphasize important information related to the main topic.
Page 19 Englewood, CO 80112 (800) 854-7179 or (303) 397-2740 Quantum company contacts are listed below. Contacts Quantum Corporate Headquarters To order documentation on the Quantum PX500 Series libraries or other products contact: Quantum Corporation P.O. Box 57100 Irvine, CA 92619-7100 (949) 856-7800...
Page 20 Preface Customer Support The Quantum Customer Support Department provides a 24-hour help desk that can be reached at: North/South America: Asia/Pacific Rim: Europe/Middle East/Africa: Send faxes for the Customer Support Department to: North/South America: Asia/Pacific Rim: Europe/Middle East/Africa: Send e-mail for the Customer Support Department to:...
Page 21: Chapter 1 Introduction
• Direct Access Devices – RAID controllers, Disk drives, JBODs • Sequential Access Devices – Tape drives • Changer Devices – Tape and Magneto-Optical libraries Figure 1 shows the front panel of the Quantum TC2201 iSCSI router. Chapter 1 Introduction...
Page 22: Operation Indicators
Ethernet and Serial ports provide connections for configuration and management of the unit. The LEDs (operation indicators) provide basic status information. The TC2201 is equipped with LED indicators for monitoring overall unit status (see figure iSCSI link status...
Page 23: How The Tc2201 Works
Ethernet link on this management port. When lit green, the left indicator signifies Ethernet port activity on this management port. The TC2201 is a router that translates the iSCSI protocol to and from the SCSI Protocol—transparently transferring commands, data, and status information—so that devices and hosts can communicate with each other.
Page 24: Figure 3 Information Processing
Figure 3 Information Processing Quantum TC2201 User’s Guide 4 The SCSI controller sends the command to the SCSI device (target). 5 The SCSI target interprets the command and executes it. 6 Data flows between the iSCSI host and SCSI target through payload...
Page 25: Lan-Free Backup And Restore
Figure 5 LAN-free Backup Quantum TC2201 User’s Guide LAN-free backup and restore moves the bulk of data backup and recovery traffic from the LAN and onto a dedicated storage network. The TC2201 supports LAN-free backup/restore environments (see LAN-free Backup and Restore figure...
Page 26: Tc2201 Features
• Error Recovery Level 0 • Multiple iSCSI connections per session • VLAN Quality of Service (QoS) support The TC2201 provides the following SCSI bus features: • Auto-negotiation for Narrow, Wide, Fast, and up to Ultra160 • Concurrent commands, tagged command queuing and disconnect/ reconnect •...
Page 27: Tc2201 Benefits
Storage Quantum TC2201 User’s Guide The Quantum TC2201 is designed to connect SCSI devices into an iSCSI network. The Quantum TC2201 is neatly packaged in a 1U form factor with two 1 Gb/s iSCSI ports and two LVD/SE SCSI buses. SCSI buses automatically negotiate for Fast, Narrow, Wide, and up to Ultra160 SCSI.
Page 28: Industry Leading Inter Operability
Quantum TC2201 User’s Guide Quantum has a proven history of industry leading inter operability, which we incorporate into all our products. Quantum and its partners have tested thousands of different configurations, discovering and resolving many troublesome inter operability ability problems.
Page 29: Non-Operating Environment
Non-operating Environment Power Quantum TC2201 User’s Guide The non-operating environment of the TC2201 is: • -40 to +65°C • 10 to 90% Relative Humidity (non-condensing) The power requirements for the TC2201 are: • 100 - 240 VAC, Auto Sensing • 50/60 Hz, 1.0 Amps •...
Page 30: Chapter 2 Tc2201 Web Interface
TC2201 Web Interface This chapter describes the TC2201 web interface. The current configuration and operating status of the TC2201 can be accessed from any standard Web browser, after the user logs in with the appropriate username and password. Information is presented in HTML format in accordance with the W3C specification for HTML 3.2.
Page 31: Accessing Tc2201 Web Interface
TC2201 bridge Main menu Status information Quantum TC2201 User’s Guide Most settings may be changed and saved to the TC2201. Unless otherwise indicated, configuration changes Note: take effect when the unit next powers on or reboots. To access the TC2201 web interface: 1 On the host computer, open the internet browser software.
Page 32: Home Page
Netscape’s browser on non-Solaris platforms, or Netscape version 6.2.3 for Solaris platforms. If using Internet Explorer, use revision 6.0 or later. The first page that displays when you access the TC2201 web pages is the TC2201 page (see figure...
Page 33: System Page
Network Configuration menu Main Router status information menu displays a list of the TC2201 web pages. To view a page, Main click its corresponding link. The management frame displays the page you selected. page is used to view and configure serial, network, trap, System clock, and power supply components.
Page 34: Serial Port Settings
Figure 9 System Page • • • • • • Serial Port Settings Quantum TC2201 User’s Guide page allows you to configure: System Serial Port Settings (see appendix C the command line interface through the serial port settings) iSCSI Settings...
Page 35: Iscsi Settings
Figure 10 Serial Port Settings Page iSCSI Settings Quantum TC2201 User’s Guide 2 Select the desired baud rate for the serial port and click finished. page allows you to configure iSCSI settings for the iSCSI Settings TC2201. To access the...
Page 36: Figure 11 Iscsi Settings Page
Figure 11 iSCSI Settings Page Quantum TC2201 User’s Guide 2 To make any changes, modify the entries as described below and then select the Submit button. iSCSI Target Settings • can be toggled between Enabled and Disabled. The Authentication default setting is Disabled. When set to Enabled, CHAP authentication for iSCSI is enabled.
Page 37: Isns Settings
Once all changes are made, select the changes to the TC2201. Changes will become activated after the next time the TC2201 reboots. This page allows for configuration the iSNS settings for the TC2201. To access the iSNS Settings 1 Click...
Page 38: Figure 12 Isns Settings Page
State Change Notifications. To use iSNS, enable the TC2201 as a client and then enter a DNS name or IP address for up to three iSNS servers. To make changes or to...
Page 39: User Settings
The default settings are ‘root’ for the user name and ‘password’ for the password. The security settings entered here affect all user interfaces of Note: the TC2201 after reboot of the TC2201. page: menu. System figure 13): for the TC2201.
Page 40: Real Time Clock Configuration
In the event that either or both the user name and password Note: are forgotten, it is possible to reset the user name and password to their default values by resetting the TC2201 to factory defaults from the Command Line Interface using the serial port (see...
Page 41: Factory Settings Reset
Note: configuration menu so that event logging is accurate. This page allows the TC2201 to be reset to the factory default settings. The TC2201 must be rebooted before the reset settings will take effect. Resetting to factory defaults from the QVM interface will not Note: affect ethernet connectivity.
Page 42: Ethernet Page
When this option is selected, a confirmation message will appear to verify the selection. If a response of current TC2201 activities will be disrupted while the unit resets the current configuration to the factory defaults and saves those options to FLASH memory as the current configuration.
Page 43: Hostname
Figure 16 Ethernet Settings Page Host Name Quantum TC2201 User’s Guide The Ethernet menu allows you to configure the following options: • Host Name • Ethernet Port page allows you to assign or edit a host name for the Host Name TC2201.
Page 44: Ethernet Port
Both the Ethernet management port and the two iSCSI ports can be configured for appropriate Ethernet network settings. • is the IP address of the TC2201. The default setting for the IP address Ethernet port is 1.1.1.1. The default setting for iSCSI Port 0 is 169.254.1.1.
Page 45 Protocol (DHCP). When enabled, the TC2201 will retrieve a dynamic IP address from a DHCP server located on the Ethernet network that the TC2201 is connected to. The default setting is Enabled. If DHCP is changed from Disabled to Enabled, it is necessary to reboot the TC2201 before an IP address will be requested from the DHCP server.
Page 46: Figure 18 Ethernet Overrides Settings Page
Media Access Control (MAC) Current MAC address address configured for the TC2201. The MAC address is a hardware address that uniquely identifies each physical node on an Ethernet network. While the MAC address can be changed, it is highly recommended not to change this address.
Page 47: Scsi Bus Page
SCSI Bus Page Figure 19 SCSI Bus Page Quantum TC2201 User’s Guide This SCSI Bus page allows for viewing the current SCSI attributes and settings for buffered tape writes. To access the page: SCSI Bus 1 Click from the SCSI Bus...
Page 48: Figure 20 Scsi Bus Configuration Page
2 seconds to ensure all SCSI devices complete their individual power-ups. However, the user should be aware this delay is added to the time it takes for the TC2201 to reboot and for QVM to be active again. The default setting is 2 seconds. •...
Page 49: Figure 21 Scsi Overrides Settings Page
To finalize any changes for the override settings, select the Override settings should not be changed except by or under Note: the direction of an authorized Quantum technician • can be assigned an Initiator ID, which is the ID Alternate Initiator ID for a second SCSI device that can request operations from other SCSI devices, or targets.
Page 50: Buffered Tape Writes
Quantum TC2201 User’s Guide To finalize any changes for the override settings, select the Override settings should not be changed except by or under Note: the direction of an authorized Quantum technician • enables/disables the option for negotiation on a Wide Negotiation wide SCSI bus.
Page 51: Figure 23 Buffered Tape Writes Page
Figure 23 Buffered Tape Writes Page Quantum TC2201 User’s Guide 1 Click Buffered Tape Writes Buffered Tape Writes can be enabled or disabled. The default setting is Buffered Tape Writes enabled. Buffered Tape Writes is an option designed to enhance system performance.
Page 52: Discovery Page
Discovery Page Quantum TC2201 User’s Guide • Maximum Writes Outstanding writes that can be buffered. Any additional writes beyond the maximum level allowed will be sent to the storage device without using buffering, but these writes may also be subsequently buffered when completion notices for earlier writes are received.
Page 53: Iscsi Mapping Page
Figure 24 Discovery Page iSCSI Mapping Page Quantum TC2201 User’s Guide From the menu, select the SCSI bus to view/discover devices Discovery specific to that bus. The button activates discovery for all the ports and buses, or for just the selected port or bus. When the discovery process is activated, it is performed according to the settings configured in the iSCSI and SCSI configuration pages.
Page 54: Figure 25 Iscsi Mapping Page
Figure 25 iSCSI Mapping Page Quantum TC2201 User’s Guide 1 Click from the iSCSI Mapping page displays (see iSCSI Mapping After the iSCSI port has been selected, mapping information for that port is displayed including the name of the port, the currently selected host and map.
Page 55 Quantum TC2201 User’s Guide • Select the Activate Mapping Changes the current map without rebooting the TC2201. These changes are made effective immediately after being submitted. Before activating any port mapping changes, it is strongly Caution: recommended that the user verify there are not any command or data operations occurring in conjunction with devices affected by the mapping changes.
Page 56: Figure 26 Select Host Page
Host settings are saved to memory when the Note: selected but are not activated until either the button is selected or the TC2201 is rebooted. Changes The following shows the select current map page when the Select Current button is selected (see...
Page 57: Figure 27 Select Current Map Page
Figure 27 Select Current Map Page Quantum TC2201 User’s Guide • To completely clear the current map of all entries, select the button. • To fill the map, select the fill option from the pull-down list and then select the button.
Page 58: Statistics Page
SCSI bus statistics. Statistics To access the page: Statistics 1 Click from the Statistics Main page displays (see Statistics Statistics Page Create Entry button is selected or the TC2201 menu on the page. Home figure 28): button.
Page 59: Utilities Page
Figure 28 Statistics Page Utilities Page Quantum TC2201 User’s Guide Select from the SCSI Statistics button to clear all current statistics for the selected buses and continue logging any new statistics. page allows access to the FTP utility, event log, and various Utilities trace options.
Page 60: Ftp Utility
Figure 29 Utilities Page FTP Utility Quantum TC2201 User’s Guide page consists of the following options: Utilities • FTP Utility • Trace Settings • Current Traces/ Previous Traces Last/Assert Traces • Clear Current Traces • Clear Assert Traces • Event Log Settings •...
Page 61: Trace Settings
Grant this session becomes available for use. To use the FTP Utility, do the following: 1 1. Fill in the User Name, Password, and IP Address of the TC2201. 2 2. Select the button to establish an FTP session with the Connect TC2201.
Page 62: Figure 30 Trace Settings Page
Figure 30 Trace Settings Page Quantum TC2201 User’s Guide 1 Click from the Trace Settings page displays (see Trace Settings Select the button to submit changes for the Submit page. Select the to open the Advanced Trace Settings page, Advanced Button...
Page 63: Figure 31 Advanced Trace Settings Page
Figure 31 Advanced trace settings page Quantum TC2201 User’s Guide For both the Basic and Advanced pages, the default setting for each trace setting is Min (track non-error conditions) but any or all settings can be changed to Errs (track error conditions) or All (track both error and non-...
Page 64: Current Traces/ Previous Traces Last/Assert Traces
These settings are normally used for diagnostic purposes as Note: directed by an authorized Quantum service technician. Using these settings during normal operations can result in performance degradation of the TC2201. Current Traces Previous Traces show the indicated trace information.
Page 65: Figure 33 Previous Traces Page
Figure 33 Previous Traces Page Quantum TC2201 User’s Guide page displays (see Previous Traces To access the Last Assert Trace 1 Click from the Last Assert Trace page displays (see Last Assert Trace figure 33): page: menu. Utilities figure 34):...
Page 66: Clear Current Traces
Figure 34 Last Assert Trace Page Clear Current Traces Quantum TC2201 User’s Guide Trace buffers can be cleared by selecting either the option or the Clear Assert Traces page allows you to clear the current trace buffer. Clear Current Traces...
Page 67: Clear Assert Traces
When this option is selected, a confirmation message will appear to verify the selection. If a response of the unit will clear the current trace buffer. Current TC2201 activities will not be disrupted by this operation. Select the your choice.
Page 68: Event Log Settings
When this option is selected, a confirmation message will appear to verify the selection. If a response of the unit will clear the assert trace buffer. Current TC2201 activities will not be disrupted by this operation. Select the your choice.
Page 69: Event Log
Figure 37 Event Log Settings Page Event Log Quantum TC2201 User’s Guide To make any changes, modify the entries as described below and then select the button. Submit Select from the Event Log settings shown. Each option enables/disables its respective filtering option. Event logging captures over 2000 events and then starts overwriting the log when full.
Page 70: Clear Event Log
Figure 38 Event Log Page Clear Event Log Quantum TC2201 User’s Guide page allows you to clear the event log. Clear Event Log To access the Clear Event Log 1 Click Clear Event Log page displays (see Clear Event Log...
Page 71: Scsi Command Tracking
Quantum TC2201 User’s Guide When this option is selected, a confirmation message will appear to verify the selection. If a response of the unit will clear the event log. Current TC2201 activities will not be disrupted by this operation. Select the choice.
Page 72: Figure 40 Scsi Command Tracking Page
SCSI Command Tracking can be toggled to ON or OFF. When toggled ON and Submitted, all SCSI commands received or transmitted to or from the TC2201 are then logged in the SCSI Commands section shown on this screen. When set to OFF (and Submitted), no SCSI commands are logged.
Page 73: Features
Features Figure 41 Features Page Quantum TC2201 User’s Guide page is where advanced software licensed features can be Features enabled. To access the page: Features 1 Click from the Features Main page displays (see Features To enable an advanced software licensed feature, enter a key number in the field and select the button.
Page 74: Report
Report Figure 42 Report Page Quantum TC2201 User’s Guide page presents a consolidated view of all system information. Report To access the page: Report 1 Click from the Report Main page displays (see Report From your web browser, it is also possible to save a copy of the page.
Page 75: Reboot
When this option is selected, a confirmation message will appear to verify the selection. If a response of current TC2201 activities will be disrupted while the unit restarts itself. The last submitted configuration changes will also take effect after the TC2201 powers on again.
Page 76: Chapter 3 Troubleshooting
Quantum TC2201 User’s Guide Troubleshooting Various problems can arise when configuring and using the TC2201. This section is provided to help guide the user through some of the basic methods of identifying faults in the setup and configuration of the unit.
Page 77: Figure 44 Tc2201 Leds
When this indicator is amber, this indicator shows that the TC2201 detects a fault condition. Faults can occur as a result of Power On Self Test (POST) failure or operational failures.
Page 78: Basic Verification
• Device ID—Each device on a SCSI bus must have a unique ID. Also check the configured ID’s for the TC2201 to verify these are not in use by other devices on the same SCSI bus. • Cabling—Check SCSI cables to verify they are functional. SCSI rules for total length, distance between devices, and stub length must be adhered to.
Page 79: Verify Iscsi Connection
Quantum TC2201 User’s Guide • SCSI Devices—Verify that the SCSI devices on a particular SCSI Bus can be seen in the by the TC2201. Check the Discovery page to verify visibility of devices. If the TC2201 can not see the devices, verify SCSI configuration, cabling, and termination.
Page 80: Verify Devices
Verify HBA Device Driver Information Customer Support Quantum TC2201 User’s Guide It may be useful to connect the SCSI target devices you are attempting to use to the native SCSI interface to verify that the devices are functional. SCSI target devices can be connected to a host SCSI bus to verify they are functional.
Page 81: Appendix A 3-Pin To Db-9 Serial Pin Assignments
3-Pin to DB-9 Serial Pin The pin assignments given for the 3-pin serial connection are in reference to the serial receptacle on the rear panel of the TC2201. Use an RS-232 null modem cable to connect the TC2201 to the host system.
Page 82: Figure 45 Corresponding Pin Outs Of Db-9 Connector
In conjunction with the pin assignments provided for the 3-pin receptacle on the rear panel of the TC2201, following are the corresponding pin out assignments for a DB-9 serial connector used to connect the other end of the serial cable to a terminal, or a computer running terminal emulation software.
Page 83: Rj-45 Ethernet Pin Assignments
DB-9 modular receptacle pin assignments The pin assignments given for the RJ-45 Ethernet connection are in reference to the Ethernet receptacle on the back panel of the TC2201. The TC2201 Ethernet connection supports the IEEE specifications for 10BASE- T and 100BASE-TX Ethernet standards.
Page 84 Quantum TC2201 User’s Guide Pin 3 Receive In + Pin 4 Connection Pin 5 Connection Pin 6 Receive In - Pin 7 Connection Pin 8 Connection RJ-45 modular receptacle pin assignments 1 2 3 4 5 6 7 8 RJ-45 Ethernet Pin Assignments...
Page 85: Inband Scsi-3 Commands
Quantum TC201 User’s Guide The TC2201 supports a set of SCSI-3 commands that can be received inband over iSCSI. When received by the TC2201, these commands are then executed by the TC2201 itself. When using SCSI-3 commands to access general management features, the commands can be sent to device LUNs that are mapped through the TC2201.
Page 86: Appendix B Inband Scsi-3 Commands General Commands
The TC2201 supports the Report LUNs command. The Report LUNs command will return a list of Logical Unit Numbers (LUNs) that can receive commands. The format of the report LUNs command is shown in Table B-1.
Page 87: Inquiry Command
Table 3 Report LUNs Parameter List Inquiry Command Table 4 Format of LUN Inquiry Command Quantum TC201 User’s Guide Byte The LUN list length is the number of LUNs times 8. Note: All LUNs are reported and will appear in the host’s map.
Page 88: Table 5 Format Of Evpd Page 0X80
Table 6 TC2201 LUN Inquiry Data Quantum TC201 User’s Guide The TC2201 returns the LUN Inquiry Data as defined in Table B-5. EVPD Page 0x80 If the EVPD bit is set and the Page Code is 0x80 the unit serial number page is returned.
Page 89 SftRe Vendor ID Product ID Revision Level The TC2201 will only reply to a SCSI Inquiry when using 8-byte LUN field of 0x00's. The Revision Level comes from the last four characters of the Note: build string, which appears in the headings for most menu screens.
Page 90: Vendor Unique Commands
Write and Verify Verify Move Medium Quantum TC201 User’s Guide The TC2201 supports a set of vendor unique commands. provides an overview of these commands. For more information about these vendor unique commands, please contact your service representative. Device Type...
Page 91: Appendix C Using The Command Line Interface
This chapter describes specific configuration options available from the Command Line Interface (CLI). The TC2201 allows the user to access many configuration settings through the CLI. Among these settings are: • Baud rate of the serial port • Ethernet IP and MAC addresses •...
Page 92: Power Up Messages
Power Up Messages Power Up Messages When you press the TC2201’s power switch to the ‘ON’ position (marked with a ‘ the terminal or terminal emulation program for the serial port (See Port Settings A series of power-up self tests are performed while the TC2201 starts (which can take up to 2 minutes), and messages related to these tests will be visible from the serial port.
Page 93: Table 8 Main Menu
Select 4 to reboot the TC2201. A confirmation message will appear verifying you want to do this. If you enter N for No, you are returned to the System Utilities menu. If you enter Y for Yes, the TC2201 will restart. This option is further described later in this chapter.
Page 94: Perform Configuration
Perform Configuration Perform Configuration The Perform Configuration menu allows the administrator to configure the various options on the TC2201. For most configuration changes to take effect, you must reboot the TC2201. Note: Table 9 Configuration menu X.XX.XXXX 1) User Settings...
Page 95: User Settings Configuration
In the event that either or both the user name and password are forgotten, it is possible to reset the user name and password to their default values by resetting the TC2201 to factory defaults. Note that resetting to factory defaults from the serial port will also reset all other configuration settings to factory defaults, as well as erase all current maps.
Page 96: Ethernet Configuration
This option allows for setting up the Ethernet network settings for the Ethernet management port including DHCP configuration, IP address, subnet Configuration mask, gateway, Ethernet MAC address, DNS settings, and Ethernet MTU size. Quantum TC2201 User’s Guide Baud Rate Configuration Menu X.XX.XXXX XXXXXX 07/26/2005 9600...
Page 97: Table 12 Figure 7-5: Ethernet Configuration Menu
Select 1 to toggle the DHCP setting. This setting enables/disables support for Dynamic Configuration Protocol. When enabled, the TC2201 will retrieve a dynamic IP address from a DHCP server located on the Ethernet network that the TC2201 is connected to.
Page 98 Ethernet port is 1.1.1.1. The default setting for iSCSI Port 0 is 169.254.1.1. The default setting for iSCSI Port 1 is 169.254.1.2. • Select 3 to change the IP subnet mask for the TC2201. The default for this setting is 255.255.255.0. •...
Page 99: Table 13 Change Dns Settings Menu
The Ethernet Management port is permanently set to 1500 and cannot be changed. The default setting for the iSCSI ports is also 1500 but a value of 9000 can be configured for jumbo frame support for iSCSI frames. Quantum TC2201 User’s Guide Change DNS Settings Menu XXXXXX XXXXXXXXXXXXXX...
Page 100: Iscsi Configuration
Host settings can be set in the Microsoft iSCSI Initiator for Windows systems, or from the iSCSI initiator available in Linux or other operating systems. Quantum TC2201 User’s Guide iSCSI Configuration Menu XXXXXX...
Page 101: Table 15 Authentication Chap Records Configuration Menu
X) Return to previous menu • • • • • • • Quantum TC2201 User’s Guide XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 : <none> Following are descriptions for each of the settings: Select 1 to display the current list of devices setup for CHAP authentication, including all CHAP names and initiator/target secrets.
Page 102: Table 16 Isns Server Configuration Menu
• Select 3 to toggle the iSNS client between Enabled and Disabled. The default setting is Disabled. When enabled, the TC2201 will function as an iSNS client and will initiate transactions with iSNS servers using the iSNSP. The iSNS client is a process that is co-resident in the TC2201, and which can register device attribute information with the iSNS server.
Page 103: Table 17 Iscsi Portal Group Configuration Menu
• • Select 5 to setup or change Portal Group configurations. By default, the TC2201 is set to use one Portal Group for both ports, which effectively enables failover capability between the two iSCSI ports. Table 17 iSCSI Portal Group Configuration...
Page 104: Parallel Scsi Configuration
Select 1 to edit the SCSI Initiator menu settings, described later in the chapter. • Select 2 to enable/disable SCSI Discovery. Quantum TC2201 User’s Guide Select 3 to change the default map value for a Portal Group. This option enables selecting between auto-assigned or indexed mapping for the iSCSI port(s).
Page 105 • Select 4 to set the discovery delay time for SCSI devices. This is the time the TC2201 waits after a power-up or reboot before starting to discover SCSI devices. This value should be set to no less than 250ms, according to the SCSI standard for Reset-to-Selection Time.
Page 106: Table 19 Scsi Initiator Menu
This should be a unique ID on the bus. The default setting is 7. The user must enter a integer value in the range of 0-15 prior to saving the configuration to the TC2201. • Select 2 to enable/disable an alternate SCSI Initiator ID.
Page 107: Table 20 Scsi Target Overrides Menu
Following are descriptions for each of the settings: • Wide Negotiation wide SCSI bus. Quantum TC2201 User’s Guide Normally, override settings should not be changed except when directed to do so by an authorized Quantum technician. XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Enabled...
Page 108: Parallel Scsi Buffered Tape Write Configuration Menu
Tape Write Configuration Menu Table 21 Parallel SCSI Buffered Tape Write Configuration Menu Quantum TC2201 User’s Guide enables/disables the option for enables/disables block sizes of 520 bytes each, enables/disables Ultra SCSI 3 support for the Buffered Tape Write Configuration Menu X.XX.XXXX...
Page 109 Quantum TC2201 User’s Guide If an application requires confirmation of individual blocks being written to the medium, such as audit trail tapes or log tapes, Buffered Tape Writes should be disabled.
Page 110: Device Mapping
Changing Ports: When the iSCSI Portal Groups setting is configured to use Both Ports, pressing the menu. When the iSCSI Portal Groups setting is configured to use separate ports, pressing the Quantum TC2201 User’s Guide Device Mapping Main Menu XXXXXX XXXXXXXXXXXXXX...
Page 111: Table 23 Select Current Map
“current” map. The map selected from this list will be the one used by the TC2201 to direct data to the appropriate targets and initiators.
Page 112: Table 24 Add A Map
The screen will ask for confirmation before deleting the map. After the map has been deleted, the default map for the current port becomes the current map. Maps with names ‘Auto Assigned’ may not be removed. Quantum TC2201 User’s Guide Add Current Map XXXXXX XXXXXXXXXXXXXX...
Page 113: Table 25 Delete Current Map
2) Edit Map Entries 3) Clear Map 4) Fill Map X) Return to previous menu Command > Note: Quantum TC2201 User’s Guide Map Edit Menu XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Enter the number of one of the available selections or enter ‘X’ to exit to the Device Mapping Main Menu.
Page 114: Table 27 Edit Map Name
(Devices may not be mapped to their native port). The following is an example of adding an entry for an iSCSI map: Quantum TC2201 User’s Guide Control of the editing process is done with simple single letter commands. ‘N’ and ‘P’ controls allow scrolling up and down the map entries.
Page 115: Table 28 Adding An Iscsi Port Entry
‘Edit Map Entries’ display table. Creating an Entry The user can create an empty map or use an existing map to pre-enter devices that are not yet online. To perform this operation, the user has to Quantum TC2201 User’s Guide Device List XXXXXX XXXXXXXXXXXXXX...
Page 116: Table 30 Deleting An Entry
Are you sure you want to delete Idx 1? (Y=Confirm, X=Cancel) > y Select D to delete multiple LUNs: Quantum TC2201 User’s Guide If the device being added is a SCSI device, the user will also be asked to enter Target ID and LUN ID for the device. Target ID must already be defined in the SCSI Configuration.
Page 117: Figure 47 Clear All Entries From Current Map
‘current’ map. Devices marked as ‘DOWN’ will not be mapped. After this operation completes, the Edit Map Entries screen will appear. Quantum TC2201 User’s Guide When deleting multiple LUNs, the user can list the LUNs to delete in a comma or space delimited format.
Page 118: Table 32 Fill Current Map
Initially all hosts are associated with an Auto Assigned map. The following is an example of an iSCSI host list: Quantum TC2201 User’s Guide Clone Current Map XXXXXX...
Page 119: Table 34 Iscsi Host List
Entering a host number index opens the iSCSI Host Info Display, where the selected host can be associated with the current map. Quantum TC2201 User’s Guide Host List Edit Display XXXXXX XXXXXXXXXXXXXX...
Page 120: Table 35 Iscsi Host List
Select ‘A’ to add a host to the list. The user will be prompted to enter the desired Host Name and iSCSI Initiator Name. Duplicate hosts won’t be added to the list. Quantum TC2201 User’s Guide iSCSI Host Info Display XXXXXX...
Page 121: Table 36 Adding A Iscsi Host
For example, if the domain name were “example.com”, then the reverse domain name would be “com.example”. Quantum TC2201 User’s Guide The Quantum TC2201 does not include iSCSI Initiator software. For additional details, contact the operating system provider. Perform Configuration...
Page 122: Table 37 Deleting A Host
Enter to keep old information. All of the information entered by the user will be validated. The following is an example of editing a host list for an iSCSI Port: Quantum TC2201 User’s Guide...
Page 123: Table 38 Editing Host List For Iscsi Port
Because the entire device list may not fit on one screen, select ‘N’ or ‘P’ to go back and forth between screens displaying more maps. Select ‘X’ to return to the ‘Device Mapping Main Menu’. Quantum TC2201 User’s Guide Host List Edit Display XXXXXX...
Page 124: Trace And Event Settings Configuration
If the Activate Port Mapping Changes option is not selected, the mapping changes will not take effect unless the TC2201 is rebooted. After the TC2201 reboots, the Configuration Menu will...
Page 125: Table 39 Utility Settings
Select 2 to edit the event settings configuration. Trace Configuration This option allows trace levels to be set. These settings should not be modified in normal operation, as performance degradation may result. There are two pages of trace levels. Quantum TC2201 User’s Guide XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22...
Page 126: Table 40 Trace Settings
4 - Critical 5 - Errors The higher the trace level setting, the broader the range of notifications that will be received. The lower the trace level setting, fewer notifications will be received. Quantum TC2201 User’s Guide Trace Settings XXXXXX XXXXXXXXXXXXXX 07/26/2005...
Page 127: Table 41 Trace Settings
U) Update Current Operating Trace Levels X) Return to previous menu Enter the trace level index, <enter> for next page > Quantum TC2201 User’s Guide Be sure to set the clock and date in the Real Time Clock Configuration menu so trace logging is accurate.
Page 128: Table 42 Trace Settings
6) SCSI - Management A) Set All Trace Levels U) Update Current Operating Trace Levels X) Return to previous menu Enter the trace level index, <enter> for next page > Quantum TC2201 User’s Guide Trace Settings XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22...
Page 129: Table 43 Trace Settings
6) iSCSI - SCBI translator A) Set All Trace Levels U) Update Current Operating Trace Levels X) Return to previous menu Enter the trace level index, <enter> for next page > Quantum TC2201 User’s Guide Trace Settings XXXXXX XXXXXXXXXXXXXX 07/26/2005...
Page 130 Enter a level number from the Trace Settings that are shown. Select U to update current operating trace levels. This option forces the currently displayed trace settings to become effective immediately, without requiring a reboot or power cycle. Note: Quantum TC2201 User’s Guide Trace Settings XXXXXX XXXXXXXXXXXXXX 07/26/2005...
Page 131: Table 45 Event Filter Settings
• Select A to toggle reservation/release events logging. The default setting is Enabled. • Select U to send event configuration changes to the TC2201 now. Event logging captures over 2000 events and then starts overwriting the log when full. Note: Quantum TC2201 User’s Guide...
Page 132: Real-Time Clock Configuration
This option restores the most recently saved configuration. This can be Restore Last useful when configuration changes are made, but the user wishes to Saved return to the previously saved configured state. The changes take effect Configuration after the TC2201 has rebooted. Quantum TC2201 User’s Guide XXXXXXXXXXXXXX 12:48:42...
Page 133: Reset And Save Configuration To Factory Defaults
User configured values for the IP address, gateway, and subnet maskare retained after the TC2201 resets. Note that user names and passwords are NOT retained. Settings are not reset to factory defaults until the TC2201 is rebooted. System Utility Menu X.XX.XXXX...
Page 134: System Statistics
• Select 1 from the System Status/Statistics Menu to display Parallel SCSI Protocol Status. Table 49 Parallel SCSI Protocol Status Menu Quantum TC2201 User’s Guide System Status/Statistics Menu X.XX.XXXX XXXXXX 07/26/2005 1) Display Parallel SCSI Protocol Status X) Return to main menu Parallel SCSI Protocol Status Menu X.XX.XXXX...
Page 135: Table 50 Scsi Device Display Menu
• • • • • Select 3 from the Parallel SCSI Protocol Status Menu to display SCSI Resource Status. Quantum TC2201 User’s Guide SCSI Device Display Menu XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Select 1) to issue discovery for all SCSI buses.
Page 136: Event Log
(Please hit any key to continue) When this option is selected from the System Utilities menu, the Event Event Log Log Menu is displayed. Note: Quantum TC2201 User’s Guide SCSI Resource Display XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 2048 2048...
Page 137: View Report
Ethernet settings, SCSI bus settings, discovery information, mapped hosts, active maps, SCSI statistics, trace settings, current traces, previous traces, assert traces, event log settings, event log, and a list of enabled features. Quantum TC2201 User’s Guide Event Log Menu X.XX.XXXX XXXXXX...
Page 138: Scsi Command Tracking
Select 1 to toggle SCSI Command Tracking ON or OFF. When toggled ON, all SCSI commands received or transmitted to or from the TC2201 are logged. When OFF, these commands are not logged. When set to ON, menu options 2 thru 4 are also available from this menu.
Page 139: Display Trace And Assertion History
• Select 5 to clear the assert trace buffer. If cleared, then the trace from last assertion failure Quantum TC2201 User’s Guide To get a copy of any of the trace buffers, see page 123. Trace Dump Menu X.XX.XXXX...
Page 140: Reboot
If a response of Y (yes) is given to the confirmation message, current TC2201 activities will be disrupted while the unit restarts itself. The last saved configuration changes will also take effect after the TC2201 powers on again.
Page 141: Download A New Revision Of The Firmware
1 From the Main menu, select the Download a New Revision of The Firmware option to start the download procedure. 2 When you confirm you want to download, the TC2201 will start the download process. 3 Use the Transfer → Send File option in the terminal emulator utility.
Page 142: Table 57 Download Firmware Menu
When the download process is complete, the system verifies that the firmware image was successfully written to the FLASH memory and then reboots the TC2201. Upon reboot, the TC2201 detects that there is a newly downloaded firmware image and copies that image to the boot sector of the FLASH and then boots with that image.
Page 143: Appendix D Using The Ftp Interface
When backing up, configurations are saved from flash to a binary file. To backup the configuration file: 1 Connect the TC2201 to the ethernet network used by your computer. 2 Start your FTP program using the TC2201’s IP address: ftp <IP address>...
Page 144: Configuration Restore Procedure
Procedure Quantum TC2201 User’s Guide The default IP address is 1.1.1.1. If the TC2201 is to use a static IP address, the default IP Note: address 1.1.1.1 should be changed to an address that is appropriate for the IP network it will reside on. Note that the...
Page 145 5 Specify the configuration’s path and filename (.cfg file) with the put command: put <path:filename.cfg> The file will transfer and the TC2201 will reboot. The TC2201 will then be using the configuration. World Wide Name (WWN) values and Ethernet physical...
Page 146: Get A Copy Of Trace Buffer Or Event Log
Note: computer or network where your FTP program will store the trace file. If the TC2201 is to use a static IP address, the default IP Note: address 1.1.1.1 should be changed to an address that is appropriate for the IP network it will reside on. Note that the...
Page 147: Update Firmware
5 Specify the firmware’s path and filename (. command: <path:filename. > The file will transfer and the TC2201 will reboot. The TC2201 will then be using the new firmware. You may want to confirm the new firmware level by checking Note: the reboot messages on the TC2201 through the serial port.
Page 148: Appendix A How To Change Block Sizes
Quantum TC2201 User’s Guide How to Change Block The following procedures are provided in this document to assist you in changing the block size configured in your backup application: • Procedure A: EMC Legato NetWorker • Procedure B: Veritas NetBackup •...
Page 149: Procedure A: Emc Legato Networker
Procedure A: EMC Legato NetWorker Quantum TC2201 User’s Guide 1 Start the Windows Registry Editor program (as shown in follows: a. Select Start>Run. b. Enter the following value in the Open text box: regedt32 c. Press [Enter]. You can also open this program at the following location: Note: %SystemRoot%\Winnt\System32\regedt32.exe...
Page 150: Procedure B: Veritas Netbackup
Figure 48 Registry Editor Procedure B: Veritas NetBackup Quantum TC2201 User’s Guide The largest bock size support by NetBackup 5.1 for Windows Note: is 128K or 131072 decimal bytes. 1 Create a file called C:\Program Files\Veritas\NetBackup\db\config\SIZE_DATA_BUFFERS. 2 Enter the block size in decimal bytes on a line by itself, such as 131072, which is 1024*128 in decimal bytes.
Page 151: Procedure C: Veritas Backup Exec
Procedure C: Veritas Backup Exec Figure 49 Veritas Backup Exec Quantum TC2201 User’s Guide 1 Within Backup Exec application (as shown in Devices tab. 2 Right click on one of the tape drives detected and select Properties. 3 When the Drive Properties box appears, select the Configuration tab.
Page 152: Procedure D: Ca Brightstor Arcserve
Procedure D: CA Brightstor ARCserve Procedure E: Bakbone NetVault Quantum TC2201 User’s Guide 1 Determine the correct block size. For BrightStor ARCserve Backup 11.0/11.1 for Windows, the block size of tape drive can be found in: HKEY_LOCAL_MACHINE \SOFTWARE \ComputerAssociate\BrightStor ARCserve...
Page 153: Procedure F: Hp Data Protector
Figure 50 Netvault Device Management Procedure F: HP Data Protector Quantum TC2201 User’s Guide In order to increase the maximum block size on a Windows Media Agent client, you must first modify its Registry. After modifying the Registry, restart the computer. Drivers read MaximumSGList at boot time. The...
Page 154 Quantum TC2201 User’s Guide 7 Use the following formula to calculate the value of the MaximumSGList: MaximumSGList = (BlockSize/4096)+1 For example, the MaximumSGList value for a 256k block size is 65, as follows: MaximumSGList = (265k/4k) + 1 = 64 + 1 = 65 If you have, for example, three aic78xx based SCSI channels on your system, change the appropriate ...\Device0, ...\Device1 or ...\Device2...
Page 155: Procedure G: Commvault Galaxy
Figure 51 HP Data Protector (Advanced Options) Procedure G: CommVault Galaxy Quantum TC2201 User’s Guide To increase block size, do the following. 1 Using the CommVault Resource Pack CD, navigate to the folder titled setFlushBlockSize. 2 Copy SetFlushBlockSize executable to the <Galaxy Commserver install directory>\Base directory.
Page 156: Figure 52 Commvault Galaxy
Figure 52 CommVault Galaxy Quantum TC2201 User’s Guide To increase chunk size, do the following. The default chunk size that galaxy uses for granular backups is Note: 2 Gb. The size for database backups is 8. Higher chunk size will give you better throughput. Recommended values are: 8 Gb, 16 Gb or 32 Gb.
Page 157: Figure 53 Commvault Galaxy (Advanced Tab)
Procedure G: CommVault Galaxy 4 Modify the chunk size for different application types and click OK to confirm changes. Figure 53 CommVault Galaxy (Advanced Tab) Quantum TC2201 User’s Guide...
Page 158 A menu item. The auto-addressing option Auto-assigned Mapping creates a mapping table using devices discovered upon powering up or resetting the TC2201, that is not otherwise retained by the TC2201. A unit of signaling speed, expressed as the maximum number of Baud...
Page 159 During power up and self test, the TC2201 Fault LED comes Fault LED on. After self test, if this LED remains on or comes on, the TC2201 has a problem with one of its components. During normal operation, this LED should be off.
Page 160 A menu name. It allows for generic Fibre Channel Indexed Addressing host bus adapters to access SCSI devices attached to the TC2201 using a table which is indexed by sequential LUN values. A device (usually a host system) that requests an operation to be Initiator performed by another device known as a target (usually a peripheral).
Page 161 Taking a iSCSI adapter offline means ending inputs/outputs and suspending all transactions going from the TC2201 to the specified iSCSI device. For the TC2201, online indicates that at least one adapter in the Online TC2201 is active and available for access.
Page 162 See Power On Self Test. Post A group of tests run when the TC2201 is Power on Self Test (POST) powered on. Contains the arithmetic and logic, control, and internal Processor memory units that control the TC2201.
Page 163 A SCSI device can act as an initiator or target. For SCSI-3, each SCSI device supports up to sixteen LUNs. An opening at the back of the TC2201 providing connection SCSI port between the SCSI adapter and the SCSI bus.
Page 164 Glossary A status type in the FC Status Menu showing the View Port Name identification of the port. Quantum TC2201 User’s Guide...
