INSTALLATION MANUAL
IMPORTANT NOTE:
Read this manual carefully before installing or operating
your wired remote control. Make sure to save this manual
for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SOPHIA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CH SOPHIA

  • Page 1 SOPHIA M UL TI -ZONE INVERTER WIRED CONTROL FOR AIR CONDITIONER INSTALLATION MANUAL IMPORTANT NOTE: Read this manual carefully before installing or operating your wired remote control. Make sure to save this manual for future reference.
  • Page 2 T able of Contents Wall-Mounted Remote Control Wiring.......1 Wall-Mounted Remote Control Installation ......6...
  • Page 3 Wall-Mounted Remote Control Wiring WARNING The wiring should adapt to the wire control current. • Otherwise, electric leakage or overheating may occur and result in fire. The specified cables must be used in the wiring. No • external force should be applied to the terminal. Otherwise, the wire may be damaged and heating may occur and result in fire.
  • Page 4: Wiring Diagram

    An overview of the wall-mounted remote control wire outlet Top side wire outlet Right side Left side wire outlet wire outlet Bottom side wire outlet Fig. 1 1. Wiring diagram Refer to the following diagram to wire the wall-mounted remote control to the indoor unit. Wired joint, 5p Infrared pipe 5-Core shield cable...
  • Page 5 2. Installation Diagram Connect the wire from the display panel of the indoor unit to a connecting cable. Then connect the other side of the connecting cable to the remote control. The connective wires group 5-core wire Front grille Fig. 3 NOTE: Be sure to reserve a length of the connecting wire for periodic maintenance.
  • Page 6 NOTE: DO NOT allow water to enter the remote control. Use the trap and putty to seal the wires. Putty Trap Putty Putty Trap Trap Fig. 4 a. For exposed mounting, cut holes on four of the sides according to Fig. 5. b.
  • Page 7 Cut three holes Cut one hole for wire outlet for wire outlet Fig. 5 Embedded switch box wiring Wiring through the wall Wall hole and wiring hole Wiring hole Diameter of wall hole: Φ 2cm Fig. 6...
  • Page 8 Wall-Mounted Remote Control Installation W ARNING DO NOT operate the unit with wet hands, as this could lead to electrical shock. Remote Control Dimensions 120 mm 21 mm 13.1 mm (4.7 in) (0.8 in) (0.5 in) 19.5 m m 19.5 mm (0.7 in) 51.1 mm (2 in)
  • Page 9: Preparation Before Installation

    Preparation before Installation 1. Be sure you have the following parts: Table 1 Name Quantity Remarks Remote control M4x20 (for mounting on the wall) Screws For mounting on the wall Anchors Screws M4x25 (for mounting on switch box) For fixing on the switch box Plastic screw bars The connective Optional...
  • Page 10: Installation Method

    Installation Method 1. Remove the top panel of the remote control: Insert a screwdriver into the two slots at the bottom of the remote control to pop off the top panel. Slots Fig. 8 NOTE: The printed circuit board (PCB) is mounted in the upper part of the remote control.
  • Page 11 Back plate Screws (M4×20) Fig. 9 b. For flush mounting, fasten the back plate to the switch box with 2 screws (M4×25) and fasten the back plate to the wall with 1 screw (M4×20). Switch box Back plate Screw (M4×20) Screws (M4×25) Fig.
  • Page 12 3. Set the time and date: The remote control has a small, built-in battery that allows the time and date to be set. This allows the remote control to keep time even during a power outage. When the unit displays an incorrect time and date, the batteries need to be replaced.
  • Page 13 QSXI-005AEN The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
