Page 1: User Manual
USER MANUAL QSDL506W Wireless Alarm System Rev 12.21.2009... -
Page 2: Table Of Contents
4.2: Magnetic Window/Door Sensor Alarms ... 2 4.3: Infrared Sensor (with Mounting Bracket)... 2 4.4: Keychain Remote Control ... 3 Section 5: TECHNICAL DATA ... 4 Section 6: LOCATION SUGGESTIONS ... 5 Q-SEE PRODUCT WARRANTY ... 6 CUSTOMER INFORMATION CARD ... 7 QSDL506W USER MANUAL... -
Page 3: Section 1: Usage
Switch the unit to the chime position if you want the unit to chime to alert you if a sensor is triggered. P a g e QSDL506W USER MANUAL... -
Page 4: Magnetic Window/Door Sensor Alarms
Infrared Sensor. It is suggested that you keep the area around your Infrared Sensor clear of obstacles and avoid placing it in direct sunlight. (Picture 3) QSDL506W USER MANUAL Magnetic Window/Door Sensor Alarms P a g e... -
Page 5: Keychain Remote Control
QSDL506W USER MANUAL Keychain Remote Control 4.4: 1. Remove the battery compartment cover on the front remote controls (Picture 4), insert 23A batteries and replace the battery compartment cover. 2. You can now use the remotes to arm or disarm the system. -
Page 6: Section 5: Technical Data
• Input volts: DC4.5V (Lr44x3) • Standby current: <10uA • Transmission current: <8mA • Transmission frequency: 433.5MHZ-434MHZ • Transmission distance: >100m (300 ft) (open area) Keychain Remote Controls: • Power volts: DC12V (23AEx1) • Transmission frequency: 433.5MHZ-434MHZ QSDL506W USER MANUAL P a g e... -
Page 7: Section 6: Location Suggestions
QSDL506W USER MANUAL Section 6: LOCATION SUGGESTIONS Main Unit with Zone List Magnet Sensors Infrared Sensor Magnetic Code Controller P a g e... -
Page 8: Q-See Product Warranty
(3) Damage caused by acts of nature (e.g., earthquake, fire, etc). (4) Equipment damage caused by the maintenance of personnel not authorized by Q-See. (5) Product sold over 12 months ago. -
Page 9: Customer Information Card
Purchase Date Distributor The material in this document is the intellectual property of Q-See. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without our company’s expressed written consent.
