Lcd baby monitor wireless camera

Advertisement

QSW8209
LCD Baby Monitor
Wireless Camera
Visit Us on the Web at
http://www.q-see.com
Rev 092507

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QSW8209 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Q-See QSW8209

  • Page 1 QSW8209 LCD Baby Monitor Wireless Camera Visit Us on the Web at http://www.q-see.com Rev 092507...
  • Page 2: Table Of Contents

    Packing List Diagram Structure Installation Specifications FCC and EU Contents Contents Contents Contents...
  • Page 3: Packing List

    1. Packing List 1) 2.4GHz Wireless Camera ╳ 2) 2.4GHz Wireless Receiver ╳ 3) AV cable ╳ 4) Power Adapter for camera ╳ 5) Power Adapter for receiver ╳ Note: AA Batteries are not included 2. Diagram...
  • Page 4: Structure

    3. Structure 3-1. Layout of Camera 3-2. Layout of Receiver...
  • Page 5: Installation

    4. Installation 4-1. Setting up the Camera 1. Setup the camera in the desired location 2. Connect the camera to the adapter and then slide the power switch to the ON position Note: --This camera can also use dry batteries as a power source by loading 4 AA batteries into the battery compartment on the back of the camera with their polarities in the correct position.
  • Page 6 camera is not going to be used for a long period of time, please unplug the adapter and remove the batteries. * The camera can run off of batteries for up to 5 hours (IR OFF) 3. Rotate the rounded head of the camera to the desired angle for surveillance. 4-1-1.
  • Page 7 2. Press the channel button on the receiver to select the same channel as the camera. When the channels match the picture will be displayed on the screen. 4-1-3. Camera alarm setup 1. The camera provides Motion Detection and Sound Detection. For each mode you can select 3 sensitivity levels: Low, Middle, High.
  • Page 8 you press the Eliminate Alarm Button. Within 1 minute the motion alarm starts the next alarm circle. Sound Alarm Setup: This alarm will detect sound. If you slide the alarm setting switch to the Sound position, and select the Sensitivity level, the system enters sound alarm mode. When sound is detected, the alarm sounds until you press the Eliminate Alarm Button.
  • Page 9 Note: --This receiver can also use dry batteries as a power source by loading 4 AA batteries into the battery compartment at the back of the camera with their polarities in the correct position. --The AC adapter will work instead of batteries after it is plugged in. If the camera is not going to be used for a long period of time, please unplug the adapter and remove the batteries.
  • Page 10 3. Set the channel of the receiver to the same channel as the camera by pressing the channel button continuously, the pictures will display on the screen when the channels match. Note : : : : For clearer pictures you can connect the receiver to a monitor/TV with the included AV cable (yellow for video and red for audio).
  • Page 11: Specifications

    Slide “Volume Switch” to adjust the volume of the receiver. 2. Channel selection Press “CH button” to select the desired channel. 3. Channel Looping Hold the “CH button” for three seconds to enter the loop mode. All the available channels will be displayed one by one (default interval is 5 seconds). 4.
  • Page 13: Fcc Information

    * Actual transmission range may vary according to weather, Location, interference and building construction. * All the specifications are subject to minor change without prior notice. 6. FCC information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 14 EU Environmental Protection Electrical waste products (discharged batteries) should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. TRADEMARKS All brand names and products are registered trademarks of their respective Companies.
  • Page 15: Legal Disclaimer

    You have to take utmost care while handling this product in order to ensure its reliability & durability. Digital Peripheral Solutions Inc. 8015 E Crystal Drive. Anaheim, CA 92807, 1-877-998-3440. Q-See Tech Support in U.S.A. Mon-Fri: 9 am 5 pm PST. TEL:1-877-998-3440 E-mail: ts@dpsi-usa.com Website: www.q-see.com...
