Pyramid Car Video System User Manual

Panel Panel
A.Turn on the door light A.Turn on the door light
C.Active the menu C.Active the menu
E.LCD On/Off E.LCD On/Off

Remote control

1
3
2
5
4
7
6
9
8
MONITOR
Contents and specitications can be subjected to change without prior notice.
No.1 Quality
A.door light switch
B.vol +
C.menu
D.vol -
E.power on/off
F.earphone switch
B.Positive adjustment B.Positive adjustment
D.Negative adjustment D.Negative adjustment
F.Earphone jack F.Earphone jack
1.Power On/Off
2.Brightness -
3.Brightness +
4.Colour -
5.Colour +
6.Contrast -
7.Contrast +
8.Volume -
9.Volume +

Specifications

Screen Size:
System:
Power source/Consumption:
Video Input:
Operating Temperature:
Storage Temperature:
Display Method:
Resolution(HXV):
Back light:
Cautions
Never connect the car adaptor to cigarette lighters for such as trucks
or buses which use 24VDC power.
Do not expose the monitor to high humidity,dust,steam, oily smoke,
direct sunlight etc..
For your safety, turn power OFF when not in use and unplug the
adaptor.
Never attempt your own maintenance. Consult your TV dealer or
the company.
Avoid dropping and strong impact.
For your safety, the driver should not watch the TV or operate the
controls while driving.
Accessories
1 monitor
1 instruction manual
W AR N I N G :
D O N O T W AT CH T .V. W H I L E V E H I C L E I N M O T I O N
I T C A N B E H A Z A R D O U S
7.2inch
NTSC
DC12V+/-10%,<700mA
Composition Video signal
0 ~+45
-10 ~+80
Color LCD
640 840
Cold Cathode Filament Tube
1 Remote controller
Serial number:
