- Page 1 Retro Style Vinyl Turntable With USB-to-PC Recording Entertainment Center MODEL PVNTT5U Operating Instructions Manual...
-
Page 2: Important Safety Instructions
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. IMPORTANT SAFETY INSTRUCTIONS Read these instructions. -
Page 3: Preparation For Use
PREPARATION FOR USE UNPACKING AND SET UP Carefully remove the unit from the display carton and remove all packing material from the unit. Unwind the AC power plug and extend it to its full length. Place the unit on a stable, level surface, convenient to an AC outlet, out of direct sunlight, and away from sources of excess heat, dust, moisture, humidity, or strong magnetic fields. -
Page 4: Protect Your Furniture
IMPORTANT: Raising And Lowering The Lid To open the lid, raise it as far as it will go until the lid support bracket ‘locks’ in the open position. To close the lid, lift it upward slightly until the lid support bracket ‘unlocks’... -
Page 5: Front Panel
FRONT PANEL Phonograph Lid. 2) Turntable. TONE ARM. PC-USB SLOT. PH-AUX SWITCH. AUX IN SOCKET(L/R) LINE OUT SOCKET(L/R) 8) AC POWER LINE PLUG PC-USB AUX IN LINE OUT PH-AUX 4 5 6... -
Page 6: Aux In Operation
PHONOGRAPH 1) Turntable. 2) 45 RPM Adapter. 3) Automatically shut off. 4) Cue Lever. 5) Speed Selector (33 &45 &78 RPM). 6) Tone Arm Lock. 7) Tone Arm with Stylus. AUX IN OPERATION 1) Set the PH-AUX switch to AUX position. Rotate the volume control to desert level. - Page 7 Tone Arm Lock that secured the tone arm to the tone arm rest. Set the turntable Speed Selector to the appropriate speed, 33, 45, or 78 RPM. If you are playing 45 RPM singles , place the 45 RPM adapter on the centre spindle.
- Page 8 AUX IN/PHONO RECORDING 、 Set the PH-AUX switch to PH or AUX in position, playback the tacks on the AUX or PHONO. 、 2 Install Audacity on your computer using the included disc. 、 3 Set the computer before record: 1) Set the volume control YES and then adjust the volume to max..
- Page 9 Audacity and USB Connection It supports Window 95 / with the EMS memory more than 128MB and Audacity takes space of 5MB. INSTRUCTION FOR PC RECORDING 1. Software installation 1.1) Insert the CD disk into drive of PC,and read it; 1.2) Open the software, double press the file Audacity exe then press next to go forward 1.3) Choose I accept the agreement, and press”NEXT”to go forward;...
- Page 10 “ ” 1.4) Press next to go forward; 1.5)Choose the desitination location, and press to go forward;...
- Page 11 “ ” 1.6) Press next to go forward; “ ” 1.7) Waitting for installation finished, and press finish to end the installation; 1.8)Choose the language as user’s need;...
- Page 12 2. Recording: 2.1) Open the software; “ ” “ ” 2.2) Choose Edit menu,then choose Preferences ; 2.3.Audacity Preferences...
- Page 13 NOTE: you need to check your computer audio properties,the “ sound recording should be selected sss usb Audio Device” as below. 2.4. Adjust the output and input volume. Output Volume Input Volume 2.5.Select the record button • to record the disc, the left and right tracks will show on the interface;...
- Page 14 2.5.1 Press this button •,start recording. 2.5.2 Click the 2.5.3 Click the 2.5.4 Click the 2.5.5 Click the 2.5.6 Click the 3. Export the Music Files for WAV,MP3,Format. • Once you have finished recording, you should save your music to the computer.
- Page 15 3.3) After opened, it will come to the following menu, click"YES" to go to "Llame-enc. dll", and find the file"s Iocation. 3.4)After you find the"lame-enc.dl"file,open it and dick "Y" to finish the installation.
- Page 16 S T E P 4 Gently turn the turntable until a ‘pop’ sound is heard, which indicates the repositioning of the rubber band. Replace the C-clip to secure the turntable.
