SPECIFICATION
AMPLIFIER
Power Output:
Receiving mode:
Frequency Range:
S/N Radio:
Power Supply:
Output Impedance:
Operating Range:
TRANSMITTER
Frequency Range:
Dynamic Range:
Frequency Response:
Working Temperature:
Power Supply:
Battery time
WWW.PYLEAUDIO.COM
100W
VHF
160~270MHz
60dB
AC 120V/60Hz
DC 12-15V
600
30M
160~270MHz
80dB
100-10KHz
-10
-45
9V battery
8~10 hours
WIRELESS RECHARGEABLE
PORTABLE AMPLIFIER
USER'S MANUAL
PWMA110
Advertisement
Table of Contents
Related Manuals for PYLE Audio PWMA110
Summary of Contents for PYLE Audio PWMA110
- Page 1 S/N Radio: 60dB Power Supply: AC 120V/60Hz DC 12-15V Output Impedance: Operating Range: TRANSMITTER Frequency Range: 160~270MHz Dynamic Range: 80dB Frequency Response: 100-10KHz Working Temperature: Power Supply: 9V battery Battery time 8~10 hours WWW.PYLEAUDIO.COM PWMA110 WIRELESS RECHARGEABLE PORTABLE AMPLIFIER USER'S MANUAL...
- Page 2 FEATURES * Built-in 12V 1.2A Rechargeable Battery * Built-in One Channel VHF Wireless Receiver * With One Handheld MIC * With One 6.35mm Wired MIC input Jack and 6.35mm CD input Jack * Separate Wired MIC, Wireless MIC and CD input Volume Controls * With 6.35mm REC out Jack * With Treble, Bass and Echo Controls...
- Page 3 PARTS DESCRIPTION Rear 15. Rechargeable battery 19. Stand mounting hole compartment 20. Battery compartment 16. Compartment for AC cord 21. DC input jack 17. AC Input jack 22. Charge LED indicator 18. Fuse 23. Rating label AC IN: 120V/60Hz AC Fuse: 1A/250V RISK OF ELECTRIC OUTPUT POWER(MAX) 100W RECHARGE...
- Page 4 OPERATION INSTRUCTION REMARKS 1. When feedback occurs, please turn down the Treble, Echo controls. If feedback still exists, turn down the volume control slightly to improve the feedback situation. 2. The wired microphone and wireless microphone can be used at the same time. 3.
