PYLE Audio PT1200 Owner's Manual

Amplifier Specifications PT2000
Input Impedance 20 k-Ohms
Continuous Output Power
Stereo Mode
120W x 2
20 Hz to 20 kHz, 8 Ohms
175W x 2
1 kHz, 4 Ohms
1000W x 2
Maximum Power, 4 Ohms
Bridged Mode
300W x 1
20 Hz to 20 kHz, 8 Ohms
350W x 1
1 kHz, 4 Ohms
2000W x 1
Maximum Power, 4 Ohms
THD 0.1%
at rated output power
Frequency Response 10 Hz to 50 kHz
+/– 3 dB
Input Sensitivity 0.775V
for rated output power
Signal-to-Noise Ratio 90 dB
A-Weighted
Speaker Impedance
4-16 Ohms
A or B only
8-16 Ohms
A plus B
8-16 Ohms
Bridged Mode
Power Requirement 120 VAC, 60 Hz
Power Fuse 7A/250V
Dimensions 5 x 19 x 12
H x W x D, inches 1/8
(130 x 482 x 305)
(mm)
Weight, lbs (kg) 28.19 (12.8)
PT1600 PT1200
20 k-Ohms 20 k-Ohms
100W x 2 70W x 2
140W x 2 100W x 2
800W x 2 600W x 2
250W x 1 150W x 1
280W x 1 200W x 1
1600W x 1 1200W x 1
0.1% 0.1%
10 Hz to 50 kHz 10 Hz to 50 kHz
0.775V 0.775V
90 dB 90 dB
4-16 Ohms 4-16 Ohms
8-16 Ohms 8-16 Ohms
8-16 Ohms 8-16 Ohms
120 VAC, 60 Hz 120 VAC, 60 Hz
6A/250V 5A/250V
4 x 18 x 12 4 x 18 x 10
15/32 7/8 3/16 15/16 3/4
(114 x 480 x 305) (100 x 482 x 273)
24.67 (11.2) 19.82 (9.0)
Limited Warranty
All PYLE PRO products are carefully constructed and tested before
shipment. Units purchased in the USA are warranted to be free of
defects in material and workmanship for two (2) years from the date
of purchase. This warranty is limited to the original retail purchaser
of the amplifier.
Should the unit fail due to factory defects in material or workmanship,
your unit will be repaired or replaced at the sole discretion of PYLE.
To obtain warranty service, you must first call our Consumer Return
Hotline at (718) 236-6948 to obtain a Return Authorization Number.
This R.A. # must appear on the outside of your package and on all
paperwork relating to your return.
When returning the unit to us for warranty service, it must be carefully
packed and shipped, prepaid, to:
R.A.#: _____________
PYLE PRO Service Center
1600 63rd Street
Brooklyn, NY 11204
You must also include the following items with your return:
• A copy of your sales receipt or other proof of purchase
• A brief letter, indicating the problem you are experiencing
with the product
• Include in your letter your return address, daytime phone
number and R.A. number
• Also include a check or money order for $15.00 for return
shipping, handling and insurance, or provide your Visa/MC
number with expiration date.
Our obligation under this warranty is limited to the repair or replacement
of the defective unit when it is returned to us prepaid. This warranty
will be considered void if the unit was tampered with, improperly
serviced or subject to misuse, neglect or accidental damage.
P T 2 0 0 0 A m p l i f i e r
P T 1 6 0 0 A m p l i f i e r
P T 1 2 0 0 A m p l i f i e r
Owner's Manual
