Summary of Contents for PYLE Audio PLA-2150
- Page 1 PLA- 2 1 9 PLA-2 1 5 0 PLA-2 2 5 0 PLA-2350 PLA-2 4 5 0 PLA-2550 PLA-2650 PLA-2750 PLA-2850 Two Channel High Per formance Power Amplifier PLA- 4 1 9 P L A - 4 1 5 0 PLA-4250 PLA-4350 Four Channel High Per formance Power Amplifier...
- Page 2 When you check the list of features offered by the PLA-219, PLA-419, PLA-2150, PLA-2250, PLA-2350, PLA-2450, PLA-2550, PLA-2650, PLA-2750, PLA- 2850, PLA-4150, PLA-4250, PLA-4350, PLA-4300D you’ll know you made the right choice with a Pyle...
- Page 3 PLA-2150/PLA-2250/PLA-2350 PLA-2450/PLA-2550/PLA-2650 PLA-2750/PLA-2850 PLA-4150/PLA-4250/PLA-4350 15-16 electrical connections PLA-219/PLA-419/PLA-2150/PLA-2250 PLA-2350/PLA-2450/PLA-2550 PLA-2650/PLA-2750/PLA-2850 PLA-4150/PLA-4250/PLA-4350 stereo input connections PLA-219/PLA-2150/PLA-2250/PLA-2350 PLA-2450/PLA-2550/PLA-2650 PLA-2750/PLA-2850 mono input connections PLA-2150/PLA-2250/PLA-2350 PLA-2450/PLA-2550/PLA-2650 PLA-2750/PLA-2850 table of contents general features PLA-219 7-8 PLA-4150/PLA-4250/PLA-4350 PLA-419 9-10 11-14 PLA-4150/PLA-4250/PLA-4350 high level mono input connections...
-
Page 4: General Features
· THD: <0.04% · Thermal Protection · Overload Protection · Short Circuit Protection · Anti-Thump Turn-On PLA-2150 High Performance 600 Watt 2 Channel Bridgeable MOSFET Amplifier · 300 Watts x 2 Output · 600 Watts x 1 Bridged Output · Variable Hi/Lo Electronic Crossover Network ·... - Page 5 PLA-2250 PLA-2350 High Performance 1000 Watt 2 Channel High Performance 1200 Watt 2 Channel Bridgeable MOSFET Amplifier Bridgeable MOSFET Amplifier · 500 Watts x 2 Output · 600 Watts x 2 Output · 1000W x 1 Bridged Output · 1200W x 1 Bridged Output ·...
- Page 6 PLA-2550 High Performance 1600 Watt 2 Channel Bridgeable MOSFET Amplifier · 800 Watts x 2 Output · 1600 Watts x 1 Bridged Output · Variable Hi/Lo Electronic Crossover Network · Variable Bass Boost (0 - +18 dB @ 60Hz) · Variable Input Level (Gain) Control ·...
- Page 7 PLA-2850 High Performance 4000 Watt 2 Channel Bridgeable MOSFET Amplifier · 2000 Watts x 2 Output · 4000 Watts x 1 Bridged Output · Variable Hi/Lo Electronic Crossover Network · Variable Bass Boost (0 - +18 dB @ 60Hz) · Variable Input Level (Gain) Control ·...
- Page 8 PLA-4350 High Performance 2000 Watt 4 Channel 4000W Mono Block MOSFET Amplifier Bridgeable MOSFET Amplifier · 500 Watts x 4 Output · Mono Block Subwoofer Amplifier · 1000W x 2 Bridged Output (500W x 2+1000W x 1) · 1 Ohm Stable ·...
-
Page 9: Features And Controls
PLA-219 high level inputs low level inputs input level control speaker connections features and controls 2 ch amp PLA-219 power LED power terminals power fuse... -
Page 10: Features And Specifications
features and specifications input level control use this control to match the outputs of your head unit to the amplifier. Starting with your head unit set at about the 2 o’clock position, increase the amp level control until distortion begins to occur, and reduce slightly from this point. - Page 11 PLA-419 high level inputs low level inputs input level control speaker connections features and controls 4 ch amp PLA-419 power LED high level inputs low level inputs input level control power terminals power fuse...
- Page 12 features and specifications input level control use this control to match the outputs of your head unit to the amplifier. Starting with your head unit set at about the 2 o’clock position, increase the amp level control until distortion begins to occur, and reduce slightly from this point.
- Page 13 2 ch amp PLA-2150 • PLA-2250 PLA-2350 • PLA-2450 high level inputs low level inputs input level control power terminals power fuse...
- Page 14 Remote Bass Boost Plug in the Remote Bass Boost Control wire in here.(PLA-2150 without) bass boost level control this control permits adjustment of the bass level up to an increase of approximately 18 dB.
- Page 15 power LED PLA-2550 protection LED PLA-2650 PLA-2750 Remote Bass Boost PLA-2850 high pass frequency control low pass frequency control bass boost level crossover mode selector speaker connections features and controls 2 ch amp PLA-2550 • PLA-2650 PLA-2750 • PLA-2850 high level inputs low level inputs input level control power terminals...
- Page 16 features and specifications crossover mode selectors when used with normal, full range systems, set these switches to “FULL.” If you wish to use the internal crossovers to power a driver of specific frequency range, use the “LOWPASS” or “HIGHPASS” settings. input level controls use these controls to match the outputs of your head unit to the amplifier.
- Page 17 PLA-4150 PLA-4250 ch 3/4 input level control PLA-4350 ch 3/4 high level inputs ch 3/4 low level inputs ch 3/4 crossover mode selector switch ch 3/4 bass boost level control ch 3/4 low pass frequency control ch 3/4 high pass frequency control power LED protection LED speaker connections...
- Page 18 dual crossover mode selectors when used with normal, full range systems, set these switches to “FULL.” If you wish to use the internal crossovers to power a driver of specific frequency range, use the “LOWPASS” or “HIGHPASS” settings. dual input level controls use these controls to match the outputs of your head unit to the amplifier.
- Page 19 features and controls Class-D MONO BLOCK AMPLIFIER PLA-4300D power LED protection LED PLA-4300D line level outputs remote bass boost line level inputs input level control low pass frequency control sub sonic control phase shift switch speaker connections power fuse power terminals...
- Page 20 Class-D design Low-frequency information for subwoofer only.High efficient power power supplies Stiffly regulated PWM power supplies. MOSFET switches maintain rated power over a wide range of battery voltages. crossover low pass filter Adjustable from 20Hz to 250Hz with a slope of 24dB per octave.This allows for the adjustment of the upper point of the frequency bandwidth and the respective subwoofer.
-
Page 21: Electrical Connections
2 ch amp PLA-219 • PLA-2150 • PLA-2250 • PLA-2350 PLA-2450 • PLA-2550 • PLA-2650 • PLA-2750 PLA-2850 • PLA-4300D PLA-219 PLA-2150 PLA-2250 PLA-2350 PLA-2450 PLA-2550 PLA-2650 PLA-2750 12V battery PLA-2850 head unit PLA-4300D to remote turn-on +12V... - Page 22 electrical connections 4 ch amp PLA-419 • PLA-4150 PLA-4250 • PLA-4350 PLA-419 PLA-4150 PLA-4250 PLA-4350 12V battery head unit to remote turn-on +12V...
-
Page 23: Stereo Input Connections
low level inputs using PLA-2 1 9 high level inputs using from speaker terminals stereo input connections L/R Audio Outputs head unit wiring harness 2 ch amp PLA-219 head unit PLEASE NOTE! If using high level inputs, do not use the low level RCA inputs at the same time! - Page 24 PLA-2650 PLA-2750 high level inputs using PLA-2850 from speaker terminals stereo input connections 2 ch amp • PLA-2150 • PLA-2250 • PLA-2350 PLA-2450 • PLA-2550 • PLA-2650 L/R Audio Outputs head unit PLA-2750 • PLA-2850 head unit PLEASE NOTE! If using high level...
- Page 25 PLA-2850 using To a second amplifier wiring harness from speaker terminals mono input connections 2 ch amp • PLA-2150 • PLA-2250 • PLA-2350 PLA-2450 • PLA-2550 • PLA-2650 Y Adaptors head unit PLA-2750 • PLA-2850 head unit PLEASE NOTE! If using high level...
- Page 26 2/4 channel input connections 4 ch amp PLA-419 low level inputs 4 CH input connections using PLA-4 1 9 head unit L/R FRONT Audio Outputs L/R REAR Audio Outputs low level inputs 2 CH input connections using Y adaptors...
-
Page 27: High Level Input Connections
high level input connections 4 CH floating ground connections PLA-4 1 9 REAR ORANGE BLACK BLACK ORANGE PLEASE NOTE! If using high level inputs, do not use the low level RCA inputs at the same time! FRONT ORANGE BLACK BLACK ORANGE from speaker terminals 4 ch amp PLA-419... - Page 28 4 CH Stereo input connections using PLA-4 1 5 0 PLA-4250 PLA-4350 L/R REAR Audio Outputs 2 CH Stereo input connections using Stereo input connections 4 ch amp PLA-4150 • PLA-4250 • PLA-4350 low level inputs Audio Outputs low level inputs Y adaptors head unit L/R FRONT...
- Page 29 high level Stereo input connections 4 CH floating ground connections PLA-4 1 5 0 PLA-4250 PLA-4350 REAR ORANGE BLACK BLACK ORANGE PLEASE NOTE! If using high level inputs, do not use the low level RCA inputs at the same time! 4 ch amp PLA-4150 •...
- Page 30 4 CH mono input connections using PLA-4 1 5 0 PLA-4250 PLA-4350 2 CH mono input connections using mono input connections 4 ch amp PLA-4150 • PLA-4250 • PLA-4350 low level inputs RIGHT FRONT Audio Outputs LEFT REAR Audio Outputs RIGHT REAR Audio Outputs low level inputs head unit...
- Page 31 high level mono input connections 4 CH floating ground connections PLA-4150 PLA-4250 PLA-4350 ORANGE BLACK BLACK ORANGE PLEASE NOTE! If using high level inputs, do not use the low level RCA inputs at the same time! 4 ch amp PLA-4150 • PLA-4250 • PLA-4350 ORANGE BLACK BLACK...
-
Page 32: System Wiring
system wiring Class-D MONO BLOCK AMPLIFIER PLA-4300D PLA-4300D TO SATELLITE AMPLIFIER L/R Audio head unit LINE INPUT Outputs S P E A K E R O U T P U T C O N N E C T I O N MI NI M U M SP E AKE R I MP E D AN C E... -
Page 33: Speaker Connections
2 ch amp PLA-219 • PLA-2150 • PLA-2250 • PLA-2350 PLA-2450 • PLA-2550 • PLA-2650 • PLA-2750 PLA-2850 Stereo Output Mode PLA-219 PLA-2150 PLA-2250 PLA-2350 PLA-2450 PLA-2550 Bridged Mono Output Mode (PLA-219 WITHOUT) PLA-2650 PLA-2750 LEFT speaker RIGHT speaker... - Page 34 4 CH Output Mode PLA-4 1 9 PLA-4150 PLA-4250 PLA-4350 Bridged Dual Mono Output Mode (PLA-419 WITHOUT) speaker connections 4 ch amp PLA-419 • PLA-4150 FRONT speakers REAR speakers speakers PLA-4250 • PLA-4350 MINIMUM SPEAKER IMPEDANCE 4 OHMS!
- Page 35 speaker connections 4 ch amp PLA-4150 • PLA-4250 • PLA-4350 PLA-4150 pb-836GX PLA-4250 pb-1036GX 2 CH Bridged Output Mode with Subwoofer Output PLA-4350 MINIMUM SPEAKER IMPEDANCE 4 OHMS! SPEAKERS SUBWOOFER...
-
Page 36: Mounting And Installation
mounting Your new Pyle GearX Series amplifier comes complete with all required mounting hardware. When determining a suitable location in your vehicle for the amp, please remember that it is a high-power electronic device capable of generating high heat. For this reason, always choose a location in your vehicle which has low vibration, adequate ventilation, a minimum of dust, and no moisture. Be sure to mount the amp in such a manner as to allow reasonable airflow over the cooling fins. -
Page 37: Troubleshooting
protection circuitry The built-in protection circuitry in the Pyle GearX amplifiers will disable the amplifier if it senses Series an input overload, a speaker short circuit, or extreme temperature conditions. When the protection circuit is activated by any of these conditions, the Protection LED will be illuminated. - Page 38 precautions notes Do not operate the amplifier when it is unmounted. Attach all audio system components securely within the automobile to prevent damage, especially in an accident. Do not mount this amplifier so that the wire connections are unprotected, or in a pinched condition, or likely to be damaged by nearby objects.
-
Page 39: Limited Warranty Policy
All Pyle products are carefully constructed and thoroughly tested before shipment. Products purchased in the USA are warranted to be free of defects in material and workmanship for two (2) years from the date of purchase. This warranty is limited to the original retail purchase. Should the product fail due to factory defects in material or workmanship, your unit will be repaired or replaced at the sole discretion of Pyle.
