Pyle PLDV6K Installation Manual

PLDV6K
PYLE DRYVER
PYLE DRYVER
(PLDV6K)
PYLE DRYVER
48
1. Using mounting template for speaker, mark the
correct mounting location by a pencil or pen.
2. Cut out the panel by this marking and drill 4
boles for the mounting bolts to pass through.
3. Connect the terminal of speaker to car audio
correctly by using cord provided
Caution: Be careful not to miseonnect polarity
4. Insert grill & speaker Unit in the speaker
mounting hole at the rear panel and fix speaker
with bolts & screws & nuts provided.
PLDV6K
One Pair 6.5" Mid Bass Speaker:
Standard 6.5" Size OEM Iocations
Poly Injection Cone
Non-Fatiguing Butyl Rubber Surround
1" High Temperature ASV Voice Coil
25 Oz Magnet Structure
Rubber Magnet Cover
Power Handling: 120 Watts RMS. 240 Watts MAX
Frequency Response: 50Hz – 6KHz
Impedance: 4 Ohm
One Pair Tweeter:
1" Silk Dome Tweeter
3 Mounting Options: Flush / Swivel / Surface and
Angle Mount
50 W
atts RMS / 100 Watts Peak
Frequency Response: 1.4 – 24KHz
Impedance: 4 Ohm
One Pair Passive Crossover Network
Two-
Way Passive Crossover
12 dB Octave Slope
Accessories:
Includes Custom Grills
Wires and Installation Hardware
(PLDV6K)
PLDV6K CUTOUT
6
