- Page 1 OWNER’S MANUAL DIGITAL AUDIO OUT MULTI-SUBTITLE LANGUAGES FUNCTION ELECTRONIC SHOCKPROOF (ESP) FUNCTION A/V INPUT FM MODULATOR REMOTE CONTROL...
-
Page 2: Table Of Contents
CONTENTS Page Contents Safety Information Installation Electric Connection Operation Using The Remote Control General Operation CD/MP3 Operation DVD/VCD Operation Data Disc Play Operation Memory Card Play Operation USB Device Operation AV In Operation FM Modulator Operation Additional Information Setup System Setup Language Setup Audio Setup Digital Setup... -
Page 3: Safety Information
Safety Information CAUTION: This mobile DVD player is a class 1 laser product. However this mobile DVD player uses a visible/invisible laser beam which could cause hazardous radiation exposure if directed. Be sure to operate the mobile DVD player correctly as instructed. -
Page 4: Installation
Label side Do not bend Wipe the disc from center toward the outside edge Preparing New Discs with Rough Spots A new disc may have rough edges on its inside and outside edges. If a disc with rough edges is used, the proper setting will not be performed and the player will not play the disc. - Page 5 The unit is designed for home-use and car-use. When installed on the car, please follow the installation instruction below. Notes: 1. First remove the two screws that lock the DVD mechanism, then attach the brackets on both sides of unit with screws (m4X5), last install the unit with screws (m5X25).
-
Page 6: Electric Connection
IR Sensor If you need to mount the DVD player in a location which is inaccessible, or where the line-of- sight between the remote control and the face of the player is interrupted, connect the remote sensor as shown in the diagram above. -
Page 7: Operation
OPERATION LOCATION AND FUNCTION OF KEYS Front panel Remote Control User’s Manual - page 6... - Page 8 POWER Press it to turn the unit on/off. Pause playback a disc, press it again to resume playback. 3 MODE Change between DVD, TV and AV mode. Press the button to skip back one track. Press the button to skip to the next track. 6.
-
Page 9: Using The Remote Control
USING THE REMOTE CONTROL Preparing and Using The Remote Control * Before using the remote control, please take the transparent insulator strip off the bottom of remote control. * Point the remote control at the remote sensor (11) from no more than 6 feet away. -
Page 10: General Operation
GENERAL OPERATION Initial System Start-Up Be sure to press the RESET When using the unit for the first time, after all connections are completed correctly. 1. Turn off the unit power. 2. Press RESET with a ballpoint pen or similar pointed object. Turning Power On and Off Press button (1) or insert a disc to... -
Page 11: Cd/Mp3 Operation
CD/MP3 Operation Playback Insert a disc with the label side facing up. The disc will be drawn into the player automatically. The information for the current disc will be shown on the screen . For CD: 3 For MP3 Press ◄... -
Page 12: Dvd/Vcd Operation
Note: REP 1: Only a track (file) is played repeatedly. REP DIR: Only tracks (files) in a folder are repeatedly playing. REP ALL: An entire disc is played repeatedly. REP OFF: The mode returns to normal playback. - Paragraph Repeat Play: A-B repeat allows a selected passage to be repeat continuously. - Page 13 Fast-Forward / Fast-Reverse 1. Fast-forward Press button (28) during playback. Each time the button is pressed, the speed of fast-forward increases as follows: Æ Æ FORWARD 2X In fast-forward mode, press to return to normal playback. 2. Fast-Reverse Press button (29) during playback. Each time the button is pressed, the speed of fast-reverse increases as follows:...
- Page 14 2. Waiting for a moment for the player locate the track. Playback starts from the selected chapter or track. This function is only available for discs on which chapter numbers are recorded. Playing In Random Order Press button (33) to switch the random mode on/off.
- Page 15 Press the SUB-T button (23) during playback. The following information will be shown on the screen. Each time you press the button, the subtitle cycles between the different languages recorded on the disc. Notes: - Not all discs will allow changing the subtitle during playback.
-
Page 16: Data Disc Play Operation
DVD players and discs all have “REGION CODES”. If the region code number on the DVD disc does not correspond to the region number of this DVD player, the unit cannot play the disc. - When I insert a DVD disc, there is a... -
Page 17: Memory Card Play Operation
This unit has the ability of transmit the audio to radio device. The default tran- smitting frequency is 88.7MHz,you can listen to audio of DVD player by radio device To achieve the optimal transmitting effect of FM modulator, please adjust volume to maximum level Besides, you can select 87.9MHz to transmit... -
Page 18: Additional Information
Additional Information About Parental Control DVD discs have a parental level assigned to the disc. The range of parental controls is from 1 to 8. In general, this range corresponds to established movie rating systems. Movie rating systems may vary depending on the country you live in. -
Page 19: Setup
Setup In DVD mode, when the disc is playing or in stop mode, press SETUP enter setup menu. 1. When the cursor is in the upper part of the menu, use buttons to move between the different pages. 2. Press button to move the cursor to the setup page below. -
Page 20: Language Setup
Parental Controls and Password. FM MODULATOR You can select 88.7MH or 87.9 MHz to transmit the audio of DVD player. Language Setup When you open the language setup menu, you will see the language setup... -
Page 21: Audio Setup
SUBTITLE LANG: ENGLISH/GERMAN/SPANISH/FRENCH/PORTU GUESE/ITALIAN/RUSSIAN/POLISH MENU LANG: ENGLISH/GERMAN/SPANISH/FRENCH/PORTU GUESE/ITALIAN/RUSSIAN/POLISH Audio Setup When you open the AUDIO menu, you will see the following screen: AUDIO SETUP AUDIO OUT EXIT SETUP 1) AUDIO OUT: Change among SPDIF/OFF, SPDIF/RAW and SPDIF/PCM. 2) KEY: Change among b, -4, -2, 0, +2, +4, #. -
Page 22: Trouble Shooting
Trouble Shooting If it appears that your DVD unit is faulty, please first consult this checklist. It may be that something simple has been overlooked. Under no circumstances should you try to repair the player yourself, as this will invalidate the warranty. Only qualified service personnel can remove the cover or service this player.
