- Page 1 • Vacuum Fluorescent Display • Multi-subtitle and Multi-audio Soundtrack Languages Function • Multi-angle Function • Parental Control OWNER’S MANUAL Mobile Video System PLDVD-150...
-
Page 2: Dolby Digital
FEATURES Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD) This player can play discs recorded in either PAL or NTSC format. • A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders. -
Page 3: Table Of Contents
CONTENTS Safety Information ...4 Disc Notes ...5 Installation ...6 DIN Front-Mount (Method A) ...6 DIN Rear-Mount (Method B) ...7 Using the Detachable Front Panel ...8 Electric Connection ...9 Remote Control...10 Preparing the Remote Control ...11 Loading a DVD/VCD/CD Disc...11 Ejecting a Disc ...11 Basic Operation ...12 On-Screen Display Function...13 Multi-audio Function...13... -
Page 4: Safety Information
SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED. -
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc/8 cm disc (Single-sided disc only) Video CD 12 cm disc/8 cm disc 12 cm disc/8 cm disc Discs which cannot be played with this player • DVD-ROM • DVD-R/DVD-RAM •... -
Page 6: Installation
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. -
Page 7: Din Rear-Mount (Method B)
INSTALLATION Removing the unit 1. Frame 2. Insert fingers into the groove in the front of frame and pull out to remove the frame. (When reattaching the frame, point the side with a groove downwards and attach it.) 3. Lever Insert the levers supplied with the unit into the grooves at both sides of the unit as shown in figure until they click. -
Page 8: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL To Detach the Front Panel 1. Press the open button (OPEN), then the front panel will be folded down. Open 2. Remove the front panel by pulling its middle-hand outward. Front Panel 3. For safekeeping, store the front panel in the supplied protective case immediately after being removed. -
Page 9: Electric Connection
ELECTRIC CONNECTION DVD MAIN UNIT (VIEW FROM REAR) SPDF Digital Output (To link) OUT IN AUDIO-L AUDIO-R VIDEO AUDIO-L AUDIO-R VIDEO TO POWER SUPPLY... -
Page 10: Remote Control
REPEAT OFF Press once to PAUSE a play, press again to resume continuous playback 13. AV Switch between the DVD player and the external AUDIO/VIDEO 14. ENTER Confirm the Track/Chapter selected with the number key or selected with the cursor buttons on TV screen 15. -
Page 11: Preparing The Remote Control
REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1. Open the battery compartment cover. 2. Insert the new batteries. Make sure that the positive and negative terminals of the batteries are oriented indicated. 3. Close the cover Battery: Two AAA size battery. Using the Remote Control Face the remote control towards the player front face IR mark (remote control... -
Page 12: Basic Operation
BASIC OPERATION Stopping Play - Brief press the STOP button to stop the unit playback, when press the PLAY button it can continuous normal playback. - Press STOP button twice, it will stop the playback and go back to initial Track/Chapter. -
Page 13: On-Screen Display Function
BASIC OPERATION On-Screen Display Function Press the DISPLAY button during playback to display the contents of the current disc on the screen. Example: (1) Press DISPLAY for the first time: TITLE 01/03 CHAPTER 002/025 00:02:25 Title Number, Total Title Number, Chapter Number, Total Chapter Number of this Title of the disc currently being played will be shown on the fluorescent display,... -
Page 14: Multi-Angle Function (For Dvd Only)
BASIC OPERATION - Some discs only contain one laguage soundtrack. - When no different language soundtrack are recorded display at screen left top corner. Multi-ANGLE Function (For DVD only) Press ANGLE during playback. Each time the button is pressed, number of the angle changes in sequential order. -
Page 15: Extra Function Control
It is used to switch between the DVD player and external AUDIO/VIDEO. Please connect the external AV line to the AV input terminal of the DVD player. Then press AV button to switch to the external AV. Pressing AV again will return to the AV of the DVD unit. -
Page 16: Setup
SETUP INITIAL SETUP SET UP --- MAIN PAGE GENERAL SETUP SPEAKER SETUP DOLBY DIGITAL SETUP PREFERENCE EXIT SETUP 1. Press SETUP in the stop mode. (Press the stop button twice to ensure the player under STOP mode.) 2. The initial SETUP menu is displayed. 3. - Page 17 SETUP SET UP --- GENERAL SETUP TV DISPLAY TV TYPE MULTI PIC MODE NTSC ANGLE MARK OSD LANG SPDIF CAPTIONS MAIN PAGE TV type setup This player can play discs recorded in either PAL or NTSC format. Select NTSC format, when you connected to NTSC TV.
-
Page 18: Speaker Setup
SETUP SET UP --- GENERAL SETUP TV DISPLAY TV TYPE PIC MODE ANGLE MARK OSD LANG SPDIF CAPTIONS MAIN PAGE SPDIF Select the SPDIF optical output ON/OFF. SET UP --- GENERAL SETUP TV DISPLAY TV TYPE PIC MODE ANGLE MARK OSD LANG SPDIF CAPTIONS... -
Page 19: Preference Page
SETUP SET UP --- DOLBY DIGITAL SETUP OP MODE DUAL MONO STEREO CH1-MONO CH2-MONO MIX-MONO DUAL MONO The Dual mono reproduction only process for Dolby Digital program with 1+1 Audio code mode. • Stereo-reproduce 1+1 program CH1 for left channel, CH2 for right channel. •... - Page 20 SETUP SET UP --- PREFERENCE PAGE LANGUAGE SUBTITLE DISC MENU ENGLISH LOCALE CHINESE PARENTAL FRENCH PASSWORD SPANISH DEFAULTS JAPANESE MAIN PAGE DISC MENU language setup Select the preferred DISC MENU language by using the cursor buttons. SET UP --- PREFERENCE PAGE LANGUAGE SUBTITLE DISC MENU...
- Page 21 SETUP Select reset to become factory initial setting. DEFAULT SETTING SET UP --- PREFERENCE PAGE LANGUAGE SUBTITLE DISC MENU LOCALE PARENTAL PASSWORD DEFAULTS RESET MAIN PAGE GENERAL SETUP SPEAKER SETUP DOLBY DIGITAL SETUP PREFERENCE PAGE TV DISPLAY NORMAL/PS TV TYPE MULTI PIC MODE AUTO...
-
Page 22: Specifications
SPECIFICATIONS Supply Voltage Current Consumption Signal System Discs Played Audio Output Level Audio Signal Output Characteristics Note: Specifications and design are subject to modification, without notice, due to improvements in technology. : 12V DC (11V-16V), test voltage 14.4V, negative ground : Less than 2.0A : Compositive video 1.0Vp-p 75Ω... - Page 24 www.pyleaudio.com 88-V1200-11...
