Summary of Contents for Pyle Pro PDCD205
-
Page 2: Table Of Contents
TABLE OF CONTENTS NOTE ON USE...2 FOR SAFE AND EFFICIENT OPERATION...2 DESCRIPTION OF THE FUNCTIONS...3 FUNCTION OF THE MAIN UNIT...3 FUNCTION OF THE CONTROL UNIT...4 CONNECTIONS...6 BASIC OPERATION...7 TRACK SKIP...8 OPERATION OF THE PLAY PAUSE & CUE...8 SEARCHING AND SPEED CONTROL...9 MATCHING THE BEATS PER MINUTE...10 BEAT MATCHING USING PITCH BEND...10 BEFORE SWITCHING OFF THE POWER...11... -
Page 3: Note On Use
NOTE ON USE For Safe and Efficient Operation ·Select the installation location of your unit carefully. Avoid placing it in direct sunlight. Also avoid locations subject to vibration and excessive dust, heat, cold or moisture. Keep away from sources of hum such as transformers or motors ·Do not use this compact disc player where there are extremes in temperature(below 41°... -
Page 4: Description Of The Functions
Connect the supplied power cord into an AC wall outlet with the proper AC voltage. 5.LINE OUT(Output Jacks) The audio from each CD player is output from these jacks. Connect to the line input of the mixer 6.CONNECTOR PORTS The 9-pin termination permit the connection of the main unit to the control unit. -
Page 5: Function Of The Control Unit
Function of the Control Unit 1. UNIT 1-Control Operation Panel This operation panel remotely controls the main unit 1. 2. Unit 2-Control Operation Panel This operation panel remotely controls the main unit 2 3. OPEN/CLOSE(Disc Tray OPEN/CLOSE Tray) Press to load or eject the disc. Each press will open or close the disc tray. NOTE: Tray will not open unless PAUSE button has been pushed first. - Page 6 cue point, play then pause the disc (LED on PLAY/PAUSE blinks). Press CUE button to memorize that point(CUE LED glows). Play the disc. Pressing the CUE button will then return play to cue point. Holding down on the CUE button changes the CUE function to preview. Releasing the CUE button returns you to the preset cue point.
-
Page 7: Connections
Connections Typical connections with a mixer is illustrated below. Please use it for reference. ·Connect the connection cords to the line inputs of your mixer. ·The connection cords and the remote control connection cable are supplied with the main unit. ·Be sure to use the remote control connection cable which has been supplied. -
Page 8: Basic Operation
BASIC OPERATION Loading and Ejecting the Disc Open the tray To the desired track When the disc tray is closed, press the OPEN/CLOSE button to open the disc tray(This may be done on either the player or the remote control side.) Place a disc in the disc tray Press the OPEN/CLOSE button to close the disc tray. -
Page 9: Track Skip
To go back through the tracks Tracks change as follows This is for a disc containing 4 tracks When this button is pressed once ,the CD player will skip backward to the beginning of the track. Pressing twice will skip backward to the previous track. -
Page 10: Searching And Speed Control
SEARCHING ·Scanning is used to accurately locate the point where you wish to start. ·Dial the jog while in Pause mode to search forward or backward. Once the jog is dialed, the disc output stutters. ·Dial the jog to move the disc frame by frame. ·Dial the jog clockwise to search forward, dial counter-clockwise to search backward. -
Page 11: Matching The Beats Per Minute
CD player is slow compared to the tempo of the other player, move the slider to the + side and match the tempo. When faster ,move to the – side. The following example is for matching the pitch of UNIT 2 to the pitch of the music being played on UNIT 1. -
Page 12: Troubleshooting Guide
The disc is too dirty. No sound Improper output cable connections. Improper amplifier operation Sound skips The CD player is subject to vibration or physical shock Loose cable connections Switch off the power after the disc holder has been closed with the OPEN/CLOSE button.
