- Page 1 PLMDR7 OWNER’S MANUAL Mobile Video System • Digital Audio Out-Coaxial • DVD Player • Multi Color TFT Monitor • Multi-subtitle Languages Function • Multi-audio Languages Function • Multi-angle Function • Parental Control • Remote Control www.pyleaudio.com...
-
Page 2: Use This Product Safely
FEATURES Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD) This player can play discs recorded in either PAL or NTSC format. • A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders. -
Page 3: Table Of Contents
CONTENTS Safety Information ...4 Disc Notes ...5 The Player...6 Installation ...7 Electric Connection...8 Remote Control ...9 Location and Function of Keys ...9 Preparing the Remote Control ...11 Loading/Ejecting a disc...11 Loading a disc ...11 Ejecting a disc ...11 Operation ... 12 Basic Play...12 Menu Function...14 On-Screen Display Function...15... -
Page 4: Safety Information
SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED. -
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc (Single-sided disc only) Video CD 12 cm disc 12 cm disc 12 cm disc Discs which cannot be played with this player • DVD-ROM • DVD-R/DVD-RAM • CDV • CD-G Handling and Cleaning •... -
Page 6: The Player
THE PLAYER POWER /STOP EJECT( SETUP PLAY/PAUSE ( NEXT( PREV( cursor buttons (VOL+) / (VOL-) 7 inch TFT Color Monitor 10. Remote Sensor 11. Speakers 12. Disc tray 13. Data reading indicator 14. Button for compulsively ejecting 15. DC 12V IN ) MODE 16. -
Page 7: Installation
INSTALLATION You can pull out the stand on the back of the DVD unit to place the unit on the desired position. Stand... -
Page 8: Electric Connection
ELECTRIC CONNECTION DIGITAL AV OUT AUDIO AV IN DC 12V IN AC/DC ADAPTOR (OPTIONAL) YELLOW (OPTIONAL) WHITE (OPTIONAL) YELLOW WHITE (OPTIONAL) CIGARETTE LIGHTER VIDEO IN AUDIO IN AUDIO IN DIGITAL AUDIO VIDEO OUT AUDIO OUT AUDIO OUT... -
Page 9: Remote Control
REMOTE CONTROL LOCATION AND FUNCTION OF KEYS... - Page 10 REMOTE CONTROL 1. POWER OFF When the unit is on, press the button to turn the unit off. 2. MUTE Press to mute the sound. 3. SUB-T Changing of the SUBTITLE language on multi-subtitle language DVD disc. 4. ANGLE Changing of the view angle on multi-angle DVD disc. 5.
-
Page 11: Preparing The Remote Control
REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1. Open the battery compartment cover. 2. Insert the new batteries. Make sure that the positive and negative terminals of the batteries are oriented indicated. 3. Close the cover Battery: one button cell lithium battery. -
Page 12: Operation
OPERATION BASIC PLAY Stopping Play - Briefly press the (Stop) button to stop the unit playback, when the (Play) button is pressed, normal playback will continue - Press (Stop) button twice to stop the playback and go back to initial Track/Chapter. - Page 13 OPERATION A-B repeat allows a passage to be repeated continuously. Press A-B button at the start of the required passage, then press A-B button again at the end of the passage. To revert to normal playing, press A-B button again. Each time the button pressed, the screen will display as follows: A TO B SET A...
-
Page 14: Reset Function
OPERATION When the power is on, press button on the front panel for several seconds will turn off the unit. Shortly pressing (POWER) button on the front panel is STOP function, and the function is the same with remote control. RESET FUNCTION Reset button and must be activated with either a ballpoint pen or thin metal object. -
Page 15: On-Screen Display Function
OPERATION On-Screen Display Function Press the DISPLAY button during playback to display the contents of the current disc on the screen. Example: DVD: (1) Press DISPLAY for the first time: TITLE 01/03 CHAPTER 002/025 00:02:25 Title Number, Total Title Number, Chapter Number, Total Chapter Number of this Title of the disc currently being played will be shown on the screen, along with... -
Page 16: Multi-Audio Language Function
OPERATION (4) Press DISPLAY for the fourth time: TOTAL REMAIN 00:40:35 TRACK : 01/14 (5) Press DISPLAY for the fifth time: The message on the screen will be cleared. MP3 (When set to NO MENU in SMART NAV item): (1) Press DISPLAY for the first time: CHAPTER ELASPED 00:00:25 TRACK : 01/123 (2) Press DISPLAY for the second time:. -
Page 17: Mp3 Disc Play
OPERATION MP3 Disc Play MP3 disc is playing as the format of FOLDER. For example: SMART NAVI ROOT ROOT CD01 MP3 001 PLUMT CD02 MP3 002 RZID CD03 MP3 003 ASCIS CD04 MP3 004 DCYI CD05 MP3 005 BFZ DISC PLAY MODE In stop mode, use remote control to select the item or folder... -
Page 18: Setup
SETUP INITIAL SETUP SETUP MENU --- MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCES EXIT SETUP 1. Press SETUP on the remote control in the stop mode. (Press the twice to ensure that the player is in STOP mode.) 2. - Page 19 SETUP --- GENERAL PAGE --- TV DISPLAY PIC MODE AUTO ANGLE MARK HI-RES OSD LANG N-FLICKER CAPTIONS SCR SAVER MAIN PAGE PIC mode setup Select AUTO, the player PIC mode will depend on DVD disc. Select HI-RES format for best image resolution.
-
Page 20: Speaker Setup
SETUP --- GENERAL PAGE --- TV DISPLAY PIC MODE ANGLE MARK OSD LANG CAPTIONS SCR SAVER MAIN PAGE SCR SAVER setup Select the SCR SAVER ON/OFF. SPEAKER SETUP --- SPEAKER SETUP PAGE --- DOWNMIX LT/RT STEREO MAIN PAGE This is to activate the audio output from DOLBY AC3 5.1 DOWNMIX to 2 channel mode. -
Page 21: Preferences Setup
SETUP --- AUDIO SETUP --- AUDIO OUT OP MODE DYNAMIC LPCM OUTPUT MAIN PAGE Dynamic Range Control Select DYNAMIC and adjust the dynamic range of a Dobly Digital encoded program. There are 8 steps between full compression and off compression. --- AUDIO SETUP --- AUDIO OUT OP MODE... - Page 22 SETUP --- PREFERENCES PAGE --- TV TYPE ENGLISH AUDIO FRENCH SUBTITLE SPANISH DISC MENU CHINESE PARENTAL JAPANESE PASSWORD GERMAN DEFAULTS ITALIAN SMART NAV MAIN PAGE SUBTITLE language setup Select the preferred SUBTITLE language by using the cursor buttons. --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE...
-
Page 23: Smart Nav
SETUP --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS RESET SMART NAV MAIN PAGE DEFAULTS Select RESET to revert to factory initial settings. --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS NO MENU SMART NAV... -
Page 24: Trouble Shooting
TROUBLE SHOOTING If it appears that your DVD unit is faulty, first consult this checklist. It may be that something simple has been overlooked. Under no circumstances should you try to repair the player yourself, as this will invalidate the warranty. Only qualified service personnel can remove the cover or service this player. -
Page 25: Specifications
SPECIFICATIONS Supply Voltage Current Consumption Signal System Discs Played Audio Output Level Audio Signal Output Characteristics Note: Specifications and design are subject to modification, without notice, due to improvements in technology. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.
