- Page 1 PLD52MU OWNER'S MANUAL Mobile Video System Motorized Slide Down Panel 2.5 Inch TFT Color Monitor Car DVD/VCD/CD/MP3 Player AM/FM Digital Pll Tuning Radio MPEG4 Player USB Connect Remote Control www.pyleaudio.com...
-
Page 2: Table Of Contents
CONTENTS Safety Information... Disc Notes ... Installation ... Change Angle ... Electric Connection ... Remote Control ... Basic Operation ... MP3/WMA/JPEG Disc Play ... AUX Operation ... TFT Monitor Operation ... Rear View Camera ... USB Operation ... On-Screen Display Function ... Multi-Audio Language Function ... -
Page 3: Safety Information
SAFETY INFORMATION CAUTION: THIS DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE . HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DVD PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT... -
Page 4: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc V I D E O (Single-sided disc only) Video CD 12 cm disc 12 cm disc 12 cm disc CD-RW Discs which cannot be played with this player DVD-ROM DVD-R/DVD-RAM CD-G Handling and Cleaning... -
Page 5: Installation
INSTALLATION NOTES: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation. - Page 6 INSTALLATION HEX NUT SPRING WASHER PLAIN WASHER TAPPING SCREW KEY PLATE If you want to take CHASSIS out of the SLIDE BRACKET HOUSING, first remove the PLASTIC COVER of the both sides away, then insert the two KEY PLATE into left and right side of chassis as above illustration. DASH BOARD METAL MOUNTING STRAP...
-
Page 7: Change Angle
CHAGNE ANGLE CHANGING THE CONTROL PANEL ANGLE When you want to change the angle to play, you can press repeatedly the (angle)button to select the desired angle as follows: Angle 1 Angle 2 Angle 4 Angle 3 Caution: Do not insert your finger behind the control panel... -
Page 8: Electric Connection
ELECTRIC CONNECTION WIRING CONNECTION ANTENNA CONNECTOR IGNITION SWITCH(B+) CHOKE MEMORY YELLOW BACK-UP(B+) BLACK GROUND(B-) FUSE AUTO BLUE ANTENNA FRONT Lch SPK. REAR Lch SPK. MAIN UNIT REAR RCA OUTPUT CABLE (optional) FRONT RCA OUTPUT CABLE (FOR RCA LINE OUT VERSION ONLY) GREY WHITE WHITE/BLACK... -
Page 9: Remote Control
REMOTE CONTROL Press it to change the display to clock display. 1. CLK Press it to change between RADIO ,DISC and AUX IN mode. 2. MODE Press it to stop playback. 3. STOP Display the SETUP menu. 4. SETUP In radio mode, press it to select STEREO or MONO mode (In disc 5. -
Page 10: Preparing The Remote Control
REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1.First push to inside as the direction indicated by the arrow (See Remove the battery holder as the direction indicated by the arrow (See 2.Replace the battery Set a new battery property with (+)side up as illustrated (See 3.Insert the battery holder. -
Page 11: Basic Operation
BASIC OPERATION 1.PWR BUTTON Press it to turn on the unit. Press it again to turn off. 2-3.VOL+/VOL- & SEL BUTTON Press sel button repeatedly to change mode through volume, bass, treble, balance, fader, color, bright, contrast and tint modes. Face up or down swing the SEL knob VOL + /VOL- to adjust the selected mode. - Page 12 BASIC OPERATION 6-7-8-9-10-11.PRESET STATION A.To memorize the current frequency, press any one of the six preset buttons[1-6] on the front panel or on the remote controller hold for more than 2 seconds. B. To recall the preset memory, press one of the preset buttons [1-6]. C.Press 1/TOP(6) button to select the first track/chapter to play.
- Page 13 BASIC OPERATION F. Long Press 4/RDM (9) In the DVD/VCD/CD/MP3 disc playing, press the 4/RDM button on the front panel to play in random (depend on the disc used for VCD). 12.AS/PS BUTTON When shortly pressing the APS button on the front panel or the A/P button on the remote controller, the radio searches for each preset station.
-
Page 14: Mp3/Wma/Jpeg Disc Play
BASIC OPERATION 18.MOD BUTTON Press it repeatedly select AUX IN , RADIO and DISC mode. In USB during playback , you can press STOP button and then press the GOTO button to select the DISC mode. 19.EJECT BUTTON Press the eject button to turn downward the front panel and eject the disc from the disc compartment. -
Page 15: Aux Operation
BASIC OPERATION AUX INPUT JACK When the unit connect external A/V (See number 23), you can press MODE to switch the AUX input mode. TFT MONITOR OPERATION 1. Press the SEL button(3) repeatedly during DVD/VCD mode to display the adjustment items on the screen(24). -
Page 16: Usb Operation
BASIC OPERATION USB Operation A.Plug the USB connect line to the USB socket (see number 25) of the unit properly,(See fig.1) when the USB appliance connect to the USB port of the connect line, the system star playing track of the USB appliance automatically. -
Page 17: Multi-Audio Language Function
BASIC OPERATION e.Press OSD for the fifth time: The message on the screen will be cleared for SVCD and VCD. C.Example for MP3: Each time OSD is pressed, the message displayed on screen changes as follows: SINGLE ELAPSED SINGLE REMAIN MULTI-AUDIO LANGUAGE FUNCTION A.DVD:... -
Page 18: Setup
SETUP GENERAL SETUP --- GENERAL PAGE --- -----General setup page---- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Last Memory Go To General Setup Page 1. Press SETUP button on the remote control . 2.The SETUP menu is displayed. 3.Select the preferred item by using the buttons 4.Press ENTER button. - Page 19 SETUP -----General setup page---- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Last Memory Set Angle Mark ANGLE MARK DISPLAY SETUP If it is set to ON, when the multi-angle DVD disc is playing, mark) will appears on the screen; if is set to OFF, the mark will not appear.
-
Page 20: Speaker Setup
SETUP -----General setup page---- TV Display Angle Mark OSDLang Spdif Output Captions Screen Saver Last Memory Screen Saver 6.SCR SAVER SETUP Select the SCR SAVER output ON/OFF. -----General setup page---- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Last Memory Set Last Memory State 7.LAST MEMORY SETUP... -
Page 21: Preferences Setup
SETUP PREFERENCES SETUP --- PREFERENCES PAGE --- -----Preference Page---- TV Type Audio Subtitle Disc Menu Parental Password Default Set TV standard 1.TV TYPE SETUP This player can play discs recorded in either PAL or NTSC format.Select NTSC format, when you connected to NTSC TV.Select PAL format, when you connected to PAL TV.Select AUTO format, the player TV output format... -
Page 22: Defaults Table
SETUP -----Preference Page---- TV Type Audio Subtitle Disc Menu Parental Password Default Set Parental Control 5.PARENTAL Select suitable parental guidance by the cursor buttons and conformed by pressing ENTER button. -----Preference Page---- TV Type Audio Subtitle Disc Menu Parental Password Default Change Password 6.PASSWORD... -
Page 23: Specifications
SPECIFICATION GENERAL Supply Voltage Current Consumption SIGNAL SYSTEM DISCS PLAYED AUDIO SIGNAL OUTPUT CHARACTERISTICS RADIO FM TUNER SECTION Tuning Range IF Range Usable sensitivity(30dB) AM TUNER SECTION Frequency Range IF Range Usable sensitivity(30dB) TFT MONITOR Monitor Screen Size Number of Pixels Color System NOTE: Specifications and design are subject to modification, without notice, due to... -
Page 24: Trouble Shooting
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. SYMPTOM The car ignition switch is not on No power The fuse is blown Presence of disc inside the player.
