MTS Sensors MH Series User Manual

Magnetostrictive linear-position sensors mh-series analog / pwm tester

Advertisement

Quick Links

Temposonics
Magnetostrictive
Linear-Position Sensors
MH-Series Analog / PWM Tester
User's Guide
MH-Series Analog / PWM Tester
The MH-Series Analog/PWM Tester supports analog, 4 - 20 mA and 0 - 10 Vdc,
scaled Pulse Width Modulated (PWM), and PWM time of flight (tOF) sensor
outputs. The MH-Series tester is a battery powered device that is be used in test
bench and field applications to verify that the MTS Sensor is functioning properly
and is producing the appropriate signal outputs.
FEATURES:
„ Easy connection to MTS' M12 integrated connector system
„ Easy to use push-button controls
„ Supports voltage (0-10 Vdc) and current (4-20 mA) outputs
„ Supports scaled PWM and time-of-flight PWM outputs
„ Compact construction for use in field applications
„ Provides both +5 Vdc and +12Vdc sensor power supply
„ Sealed lead acid battery that provides up to 8 hours of operation per
charge
„ Battery level monitoring
„ Automatic detection of PWM sensor frequency
„ Carrying case
All specifications are subject to change. Contact MTS for specifications and engineering
drawings that are critical to your application. Drawings contained in this document are for
reference only. Go to www.mtssensors.com for the latest support documentation.
®
551132 B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MH Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MTS Sensors MH Series

  • Page 1 Temposonics ® Magnetostrictive Linear-Position Sensors 551132 B MH-Series Analog / PWM Tester User’s Guide MH-Series Analog / PWM Tester The MH-Series Analog/PWM Tester supports analog, 4 - 20 mA and 0 - 10 Vdc, scaled Pulse Width Modulated (PWM), and PWM time of flight (tOF) sensor outputs.
