- Page 1 PLCD65WXMU OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • CD Player/MP3 Player/WMA Player • Automatic Memory Storing • Full Detachable Panel • Preset Equalization • Electronic Shockproof (ESP) Function • USB Interface • Auxiliary Input Function • Remote Control www.pyleaudio.com...
-
Page 2: Table Of Contents
CONTENTS Installation ...3 Take out screw before installation...3 DIN Front-Mount (Method A) ...3 Installing the unit...3 Removing the unit...4 DIN Rear-Mount (Method B) ...5 Using the detachable front panel ...6 Wiring Connection ...7 Operation ...8 Location of keys...8 Switching on/off the unit ...9 Faceplate release ...9 Sound adjustment...9 Loudness ...9... -
Page 3: Installation
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. -
Page 4: Removing The Unit
INSTALLATION Sleeve L Key Outer Trim Ring Front Panel R Key 6. Mount the sleeve by inserting the sleeve into the opening of the dashboard and bend open the tabs located around the sleeve with a screwdriver. Not all tabs will be able to make contact, so examine which ones will be most effective. -
Page 5: Din Rear-Mount (Method B)
INSTALLATION DIN REAR-MOUNT (Method B) If your vehicle is a Nissan, Toyota, follow these mounting instructions. Use the screw holes marked T (Toyota), N (Nissan) located on both sides of the unit to fasten the unit to the factory radio mounting brackets supplied with your vehicle. -
Page 6: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL REMOVING THE FRONT PANEL 1. Press the release button ( front panel and pull off the front panel. Release Button Front Panel 2. Keep front panel into the case. Protective Case Front Panel INSTALLING THE FRONT PANEL To install the front panel, insert the panel into the housing and make sure the panel is properly installed. -
Page 7: Wiring Connection
WIRING CONNECTION ANTENNA CONNECTOR FUSE IGNITION SWITCH (ACC+) FUSE MEMORY YELLOW BACK-UP (B+) BLACK GROUND (B–) POWER BLUE ANTENNA WHITE FRONT Lch SPEAKER WHITE/BLACK GREEN REAR Lch SPEAKER GREEN/BLACK MAIN UNIT AUX IN CABLE RCA CABLE GREY GREY/BLACK VIOLET VIOLET/BLACK (BLACK) Rch RED Lch WHITE... -
Page 8: Operation
OPERATION LOCATION OF KEYS 17 7 18 15 11 9 14 23... -
Page 9: Switching On/Off The Unit
OPERATION SWITCHING ON/OFF THE UNIT Switch on the unit by pressing any button (except button (7) and When system is on, press POWER button (9) to turn off the unit. FACEPLATE RELEASE Press button (7) to detach the removable faceplate. SOUND ADJUSTMENT Press PUSH SEL button (10) shortly to select the desired adjustment mode. -
Page 10: Selecting Station
OPERATION • SELECTING STATION Press TUNE/TRACK TUNE/TRACK button (16) shortly to activate automatic seek function. Press for several seconds until “MANUAL” appears on the display, the manual tuning mode is selected. If both buttons have not been pressed for several seconds, they will return to seek tuning mode and “AUTO”... -
Page 11: Mp3 Operation
OPERATION MP3 OPERATION • SWITCHING TO CD (MP3) MODE If there is no MP3 disc inserted in the driver: Gently insert the MP3 disc with the printed side uppermost into the disc slot (5) until you feel some resistance. The MP3 disc is drawn into the driver automatically. -
Page 12: Display Information
OPERATION • Searching From Root Directory Press AS/PS (D-AUD) button for three times. The unit searches file or directory from root by TUNE/TRACK UP/DOWN buttons. (D-DIR icon turns on if the name is directory). Display will list all available directories and songs. Select the desired directory/songs by using TUNE/TRACK UP/DOWN buttons and BND/LOU (ENT) button to... -
Page 13: Record Operation
OPERATION in the device, the operation is the same with the MP3 operation described above. Note: • The main unit can only support the standard USB-memory disc which is approved by Microsoft. • USB MP3 player is not a standard which means different brand name or different models have their own standard. -
Page 14: Remote Control
REMOTE CONTROL HANDSET FUNCTION KEYS & CONTROL DSP (0) BND (LOU/ENT) MOD (7) (8) = Tune/Skip Down Button; Select Channel Down in XM Mode TUNE/SEEK TUNE/SEEK (9) = Tune/Skip Up Button; Select Channel Up in XM Mode (Y, 10. AS/PS (D-AUD) 11. -
Page 15: Specification
SPECIFICATION GENERAL Power Supply Requirements Chassis Dimensions Tone Controls - Bass (at 100 Hz) - Treble (at 10 KHz) Maximum Output Power Current Drain CD PLAYER Signal to Noise Ratio Channel Separation Frequency Response RADIO Frequency Coverage Sensitivity (S/N = 30 dB) Stereo Separation Frequency Coverage Sensitivity (S/N = 20 dB) -
Page 16: Trouble Shooting
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power. The car ignition switch is not on. The fuse is blown. Disc cannot be Presence of CD disc inside loaded or ejected.
