Summary of Contents for Libelium Meshlium
-
Page 2: Table Of Contents
Index © Libelium Comunicaciones Distribuidas S.L. INDEX 1. Introduction ............................3 2. Meshlium general and safety information ..................3 3. Meshlium’s Hardware Setup ....................... 4 4. Turning on Meshlium .......................... 5 5. Accessing Meshlium ..........................6 5.1. Manager System ...................................6 6. -
Page 3: Introduction
1. Do not open the Meshlium enclosure in any case. This will automatically make the warranty void. 2. Do not handle the numbered metallic seals in the screws of Meshlium: their integrity is the proof that the Meshlium enclosure has not been opened. If they have been handled, opened or broken, the warranty is void. -
Page 4: Meshlium's Hardware Setup
4. Take the supplied PoE power adapter and plug it into the corresponding PoE connector. 5. Plug the other end of the adapter into the 220V socket and your Meshlium is now ready to operate. Figure : How to connect Meshlium to 220V... -
Page 5: Turning On Meshlium
2 long beeps when the system has been completely closed and Meshlium can be powered off. Note: The “beep!” sound is not really loud so you will have to take attention and be close to the Meshlium box in order to hear them clearly. -
Page 6: Accessing Meshlium
5.1. Manager System Meshlium comes with all the radios ready to be used. Just “plug & mesh!”. All the Meshlium nodes come with the WiFi AP ready so that users can connect using their WiFi devices. Connect the Ethernet cable to your network hub, restart Meshlium and it will automatically get an IP address from your network using DHCP *. - Page 7 Figure : Login Form Manager System Figure : ManagerSystem You are now inside the Manager System, the tool for controlling all the features of Meshlium in an easy way. You can just browse the tabs to explore the possibilities of Meshlium.
-
Page 8: Certifications Information
8472A-MESHLIUMV1 6.1. USA and Canada certification Modification statement Libelium has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. Interference statement This device complies with Part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
