- Page 1 PLD184V OWNER'S MANUAL Mobile Video System Anti Theft Flip Down Detachable Panel VFD Moving Display Car DVD/VCD/CD/MP3 Player AM/FM Digital Pll Tuning Radio Auxiliary Input Function Parental Control Remote Control www.pyleaudio.com...
-
Page 2: Table Of Contents
CONTENTS Safety Information... Disc Notes ... Installation ... Electric Connection ... Remote Control ... Basic Operation ... MP3/WMA/JPEG Disc Play ... AUX Operation ... On-Screen Display Function ... Multi-Audio Language Function ... Multi-Subtitle Language Function ... Multi-Angle Function ... Title Menu Function ... Setup ... -
Page 3: Safety Information
SAFETY INFORMATION CAUTION: THIS DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE . HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DVD PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT... -
Page 4: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc V I D E O (Single-sided disc only) Video CD 12 cm disc 12 cm disc 12 cm disc CD-RW Discs which cannot be played with this player DVD-ROM DVD-R/DVD-RAM CD-G Handling and Cleaning... -
Page 5: Installation
INSTALLATION NOTES: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation. - Page 6 INSTALLATION HEX NUT SPRING WASHER PLAIN WASHER TAPPING SCREW KEY PLATE 1.WHILE INSTALLING THE FRONT PANEL, PLEASE MOUNT THE LEFT SIDE FIRST, AND MAKE THE DIRECTION HOLE ON THE FRONT PANEL AIM AT THE LEFT GUIDE ON THE UNIT 2.THAN PUSH THE RIGHT SIDE TO 3.PUSH IT TO INSTALL THE FRONT PANEL COMPLETELY .
- Page 7 INSTALLATION CAUTION: DO NOT INSTALL THE DETACHABLE PANEL BEFORE CONNECTING THE WIRE. 1. The unit is designed for negative terminal of the battery which is connected to the vehicle metal. Please confirm it before installation. 2. If the car interior is extremely hot, as after being parked in the sun, do not use the player until the car has been driven for a while to cool off the interior.
-
Page 8: Electric Connection
ELECTRIC CONNECTION ANTENNA CONNECTOR IGNITION SWITCH(B+) CHOKE MEMORY YELLOW BACK-UP(B+) BLACK GROUND(B-) FUSE AUTO BLUE ANTENNA FRONT Lch SPK. WHITE/BLACK REAR Lch SPK. GREEN/BLACK MAIN UNIT REAR RCA OUTPUT CABLE (optional) FRONT RCA OUTPUT CABLE (FOR RCA LINE OUT VERSION ONLY) GREY WHITE GREY/BLACK... -
Page 9: Remote Control
REMOTE CONTROL BAND 1. Clk Display And Set The Clock. 2. Mode Select Playback Mode. 3. Stop Stops Playback. 4. Setup Accesses The Setup Menu. Select The Sound Mode. 5. Mo/st Selects a subtitle language. 6. Subtitle In radio mode, depress it for Lo/dx stronger signal. -
Page 10: Basic Operation
BASIC OPERATION 1.OPEN BUTTON Press it to flip down the front panel then you can insert the cd disc into the CD compartment. And you can find the (EJECT)button .Press it to eject the disc. 2-3.VOL+/VOL- & SEL BUTTON Press it to change audio mode through volume, bass, treble, balance, and fader modes. - Page 11 BASIC OPERATION 4.BAND BUTTON In RADIO mode, press the BAND button repeatedly to select bands in following order: (For 2 Bands) 5.EQ BUTTON Swing the knob in the direction of the EQ to turn to equalization function and to select desired audio mode. There are four kinds of mode as below: JAZZ CLAS...
- Page 12 BASIC OPERATION 13.MUTE BUTTON Swing the knob in the direction of the EQ to eliminate the sound immediately. Swing it again to release this mode and recover previous volume level. 14.CLK BUTTON Press it to change the display to clock display.
- Page 13 BASIC OPERATION Audio CD List 1...TRACK1 2...TRACK1 3...TRACK1 4...TRACK1 00:03:36 4/18 (1).Current track(file)(highlighted bar) (2).Elapsed playing time of the current track (3).Current track (file) number/total number of tracks(files) in the current folder (4).Selected playback mode Press REPEAT repeatedly to select the desired repeat mode.
-
Page 14: On-Screen Display Function
BASIC OPERATION ON-SCREEN DISPLAY FUNCTION This unit features GUI (Graphic User Interface) Menu Icons showing disc information(title/chapter/track number, elapsed playing time, audio/subtitle language, angle, and sound) and player information(repeat play, play mode, marker, etc,). Some icons only show the indicated information. Other icons allow the settings to be changed. -
Page 15: Multi-Audio Language Function
BASIC OPERATION MULTI-AUDIO LANGUAGE FUNCTION For DVD: Press AUDIO during playback. Each time the button is pressed, number of the audio soundtrack language changes on sequential order. if the disc has multi-audio language . ENGLISH ENGLISH Ex: When the disc has 3 options VCD/CD: Press AUDIO during playback. -
Page 16: Setup
SETUP LANGUAGE SETUP LANGUAGE Menu Language Disc Audio Disc Subtitle Disc Menu PREV. MOVE 1.Menu Language Setup Select the preferred MENU language by using the cursor buttons. LANGUAGE Menu Language Disc Audio Disc Subtitle Disc Menu PREV. MOVE 2.Disc Audio Language Select the preferred AUDIO sound- track by using the cursor buttons. -
Page 17: Display Setup
SETUP DISPLAY SETUP DISPLAY TV Aspect Display Mode TV Output MOVE PREV. 1.TV ASPECT SETUP This is to select the appropriate Display Mode(Letter box or Pan scan Wide screen) according to the connected TV set. 4:3LB(Letter Box) Select this when the aspect ratio of your monitor is 4:3.While viewing a wide screen picture, the black bars appear on the top and the bottom of... -
Page 18: Dolby Digital Setup
SETUP DISPLAY SETUP DISPLAY TV Aspect Display Mode TV Output MOVE PREV. 3.TV OUTPUT SETUP This player can play discs recorded in either PAL or NTSC format.Select NTSC format, when you connected to NTSC TV.Select PAL format, when you connected to PAL TV.Select AUTO format, the player TV output format will according to the DVD disc format.. -
Page 19: Audio Setup
SETUP AUDIO SETUP AUDIO Dolby Digital Digital Output MOVE PREV. 4.Digital Output Select the DRC between ON and OFF. LOCK SETUP LOCK Rating Password Country Code MOVE PREV. 1.Rating Setup Select suitable parental guidance by the cursor buttons and conformed by pressing ENTER button. -
Page 20: Defaults Table
SETUP OTHERS SETUP OTHERS Load Default Screen Saver MOVE PREV. 1.LOAD DEFAULT Select it to become factory initial setting. OTHERS Load Default Screen Saver PREV. MOVE 2.SCREEN SAVER SETUP Select the Screen Saver output ON/OFF. Language Select Display SELECT Audio Lock Setup Others SELECT... -
Page 21: Specifications
TROUBLE SHOOTING SYMPTOM The car ignition switch is NO POWER not on The fuse is blown Presence of disc inside the player. Inserting the disc in reverse direction DISC CANNOT The disc is extremely dirty BE LOADED or defective OR EJECTED Temperature inside the car is too high Volume is in minimum...
