Features and Functions:
* Bluetooth car kit, compatible with all Bluetooth phones.
* CVC technology to eliminate noise and restrain echo, enjoy clear speaking.
*
Support line-in &
（Priority：Bluetooth calling ->Bluetooth music ->Line-in ->SD/USB）
* Support last call re-dial functions and voice dialing supported
* Mute function to enjoy private talking.
* Automatically connection.
* Built-in Microphone.
* Clear LCD display, support full frequency transmitting (88.1-107.9MHz)
* Spring handle support all direction circumgyrated.
* EQ mode and circulation mode options.
* Steering wheel remote control, operating easily and conveniently.(optional)
Technical Specifications:
Excellent sound quality with full duplex communication
DSP (Digital Signal Processing) Technology for echo cancellation and background noise
reduction
Bluetooth interface:
Bluetooth frequency range:
Supported BT Profiles:
FM transmitting range:
Operating voltage range:
Charger Output Rating:
Microphone:
Support:
Display:
Audio In/out:
PLFMTR9BT Installation Guide
& User Manual
www.PyleAudio.com
audio-out, USB & MMC, can play music in the phone through Bluetooth.
Version 2.0, Class 2,
2.402 ~ 2.480GHz
HSHF, Headset, A2DP,
88.1~107.9MHz
DC 12V~24V (car lighter socket)
5V DC, 1.5A
Noise Cancelling
SD/MMC, USB
LCD display
3.5mm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pyle PLFMTR9BT
Summary of Contents for Pyle PLFMTR9BT
-
Page 1: Technical Specifications
PLFMTR9BT Installation Guide Features and Functions: * Bluetooth car kit, compatible with all Bluetooth phones. * CVC technology to eliminate noise and restrain echo, enjoy clear speaking. Support line-in & audio-out, USB & MMC, can play music in the phone through Bluetooth. - Page 2 Bluetooth function operations Paring with a Bluetooth enabled cell phone 1. With the PLFMTR9BT ON, long press the PLAY key on the panel or on the remote control, the screen will display “Pairing”, indicating that the unit is ready to be paired.
- Page 3 CH+/CH- BUTTON Adjusting the FM channel - Short press under the playing mode. (Useless when speaking.) Music Folder changing –Long press, change to last folder or next folder under the playing mode. (Useless when speaking.) PRVE/NEXT BUTTON Change the song – Short press and change to last or next song under playing mode. (Useless when speaking.) Change the volume –...
- Page 4 End or reject a call – Under the speaking mode, long press the RED button to end or reject a call. Transfer a call from PLFMTR9BT to your cell phone – Under speaking mode; press once to transfer the call between PLFMTR9BT and your cell phone.
- Page 5 End or reject a call – Under the speaking mode, long press the RED button to end or reject a call. VOICE SWITCH BUTTON Transfer a call from PLFMTR9BT to your cell phone – Under speaking mode; press once to transfer the call between PLFMTR9BT and your cell phone. VOICE DIALING BUTTON Voice activated dialing –...
- Page 6 Interface displayed on the screen under different status: When the PLFMTR9BT is power on, the screen displaying. When connected with the outer audio source displaying. When PLFMTR9BT start pairing with your Bluetooth displaying. When displaying. When connected with Bluetooth enabled phone, without other outer audio sources.
- Page 7 When playing the music from the USB drive, the screen displaying. When playing the music from the SD card, the screen displaying. When connected with the Bluetooth enabled phone and playing the music from the USB drive, the screen displaying. When adjusting the volume, the screen displaying the recent volume.
- Page 8 When adjusting the Circulation mode, the screen displaying the recent circulation mode. When change to another folder, the screen displaying the recent folder number. When inputting the FM channel by number key on the remote control, the screen displaying. When choose the song by the number key on the remote control, the screen displaying.
