Pyle PLCDUSMP74 Owner's Manual

Pyle PLCDUSMP74 Owner's Manual

Car audio system am/fm tuner cd/mp3 player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
PLCDUSMP74
OWNER S MANUAL
C
A
R
A
U
D
I
O
S
Y
S
T
E
M
A M / F M T U N E R C
D / M P 3 P L A Y E R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLCDUSMP74 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pyle PLCDUSMP74

Summary of Contents for Pyle PLCDUSMP74

  • Page 1 PLCDUSMP74 OWNER S MANUAL A M / F M T U N E R C D / M P 3 P L A Y E R...
  • Page 2 Radio wiring Speaker wiring Install the unit Removing the unit Power Volume Eject Release Mode Loud Clock Volume setting Bass setting Treble settting Balance setting Fader setting Seek Play/Pause Scan Repeat Shuffle USB PLAYER AUX IN Band Tune Loading and Replacing the battery Basic operation...
  • Page 3 To prevent injur y or fire,take the following precautions: Insert the unit until it is firmly locked to the main unit, otherwise it may fall out of place when jolted When extending the ignition, memory back up or ground cable, use diameter of 0.75mm(AWG18) or more automotive grade cable to avoid wire deterioration or damage...

  • Page 4: Left Front

    Follow this easy wiring diagram in order to enable you to install the new or existing RADIO and SPEAKER wring system. Be sure the unit is connected to a 12 volts battery with negative ground. Good ground connections eliminate most electrical noise problem and require tight with the metal vehicle chassis.remove plastic, paint or dust for good electrical contact.

  • Page 5: Install The Unit

    efore installing the receiver permanently, fit it in the approximate place in your car Connect the equipment according to the speakers and electrical connections. When your system is operated properly,(preferably with the car engine running), follow the instructions for permanent installation of your system.
  • Page 6 EJECT EJECT SEEK CLOCK SCAN SHUFFLE REPEAT AUX IN CLOCK LOUD Power Tur ning ON the power Press the [PWR]button. Press [power] button to turn on/off the unit. Volume/Push sel SEL/VOL Increasing volume Rotate the [VOL+]button Decreasing PUSH BAND Rotate the [VOL-]button MODE POWER LOUD...
  • Page 7 MODE When CD disc in unit ,press [MODE],it will switch between: BAND AUX IN No CD disc in ,press [MODE],it will switch between: BAND AUX IN BAND LOUD LOUD press the [LOUD]button to add bass output, and press it again to cancel it.

  • Page 8: Speaker Mode

    Speaker mode VOLUME BASS TREBLE FADER BALANCE In press mode, VOL is sel function Volume set mode Press SEL button once,display shows VOL , then rotate the volume + button to adjust volume level up.Rotate the volume - button to adjust volume PUSH level down.
  • Page 9 If CD in unit, press[ ] to select tracks, and long press to fast advance and back. Play/pause Pause If with DISC in unit,Press the [ ]to pause music. Play Press the [ ]button again ,then come back to DISC playing. Scan Press [SCN]button Press this button once for TRACK INTRODUCTION.

  • Page 10: Usb Player

    EJECT SEEK CLOCK SCAN REPEAT SHUFFLE AUX IN AUX IN USB player Plug USB, then press [MODE]to transfer to USB play. select: Under USB play,press can select tracks, REPEAT: Press [REPEAT] button first to repeat the playing track continuously. Press second to repeat the whole disc. Press third back to normal playing.
  • Page 11 SEEK+ SEEK- EJECT SEEK CLOCK SCAN REPEAT SHUFFLE AUX IN MONO Band Selecting band Press BAND button to select among three FM or two AM bands. (FM1-FM2-FM3-AM1-AM2) BAND Tune In radio mode: manual tuning: short press button it can select higher frequency station. PUSH BAND Short press...

  • Page 12: Basic Operation

    MUTE POWER PLAY/PAUSE 10/0 CD/ MP3&USB Loading and replacing the batter y Use one lithium battery(CR2025) insert the batteries with the +and - poles aligned properly. Following the illustration inside the case. Pull out Store unused batteries out of the reach of children. Contact a doctor immediately if the battery is accidentally swallowed.

  • Page 13: Other Function

    Volume Increasing volume Turn the [+]knob clockwise. Increasing volume Turn the [-]knob counter clockwise Play/pause Play Press the [ ]button Pause Press again the [ ] button Other function Please refer to panel. Remote operation the same of mainframe. Exter nal view Exter nal view ...
  • Page 14 Specifications subject to change without notice. CD PLAYER Signal/Noise radio...70dB Frequency response...20Hz-20KHz(+3dB) Channel separation...>45dB Dual D/A converter...16Bit FM Tuner Tuning range...USA:87.5-107.9MHz EUROPE:87.5-108.0MHz FM usable sensitivity(S/N=30dB)...<12dB Stereo separation...>45dB AM Tuner Tuning range...USA:530-1710KHz EUROPE:522-1620KHz AM sensitivity...28dB GENERAL Operating power...12 Volts DC,negative %10THD output wiring...Designed for using four Load impedance...compatible 4 to 8 ohm (100KHz step) Fuses...1amp and 10 amp...
  • Page 15 What might seem to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems. ?The power does not tur n ON. The fuse has blown. After checking for short circuits in the wires,replace the fuse with one with the same rating.
