Summary of Contents for Pyle PLCD15MR
- Page 1 PLCD15MR OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • Digital Compact Disc Player • Automatically Memory Storing • Full Detachable Panel • Program CD Tracks • CD Changer Control • Auxiliary Input Function...
-
Page 2: Table Of Contents
CONTENTS Installation ...3 DIN Front-Mount...3 Installing the unit...3 Removing the unit...4 Using the Detachable Front Panel ...5 Wiring Connection ...6 4 x 40 system ...6 Operation ...7 General Operation ...7 Radio Operation ...9 CD Operation ...10 CD Changer Operation ...11 Specification...12 Trouble Shooting ...13... -
Page 3: Installation
INSTALLATION Notes: • The unit can be installed on the vehicle or the ships. • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. -
Page 4: Removing The Unit
INSTALLATION (Fig. 2) 1. Dashboard 2. Nut (5mm) 3. Spring washer 4. Screw (5x25mm) 5. Screw 6. Strap Be sure to use the strap to secure the back of the unit in place. The strap can be bent by hand to the desired angle. 7. -
Page 5: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL To Detach the Front Panel 1. Press the OPEN button, the front panel will slide down. Open 2. When the front panel slides down, press the bottom button of the front panel upward and pull it out from the panel bracket. -
Page 6: Wiring Connection
WIRING CONNECTION For 4 x 40W System ANTENNA SOCKET FUSE IGNITION SWITCH (B+) YELLOW MEMORY BACK-UP BLACK GROUND (B–) BLUE POWER ANTENNA WHITE FRONT Lch SPEAKER WHITE/BLACK GREEN REAR Lch SPEAKER GREEN/BLACK MAIN UNIT AUX IN REAR RCA CABLE GREY GREY/BLACK VIOLET VIOLET/BLACK... -
Page 7: Operation
OPERATION GENERAL OPERATION • ON/OFF Switch on the unit by pressing PWR button (9). When system is on, press PWR button (9) again to turn off the unit. Press PWR button (9) for more than 2 seconds, the button is operated to initial volume control button. - Page 8 OPERATION display. If you select beep sound on, whenever press any button, beep sound output. • LOUDNESS Press LOUD (DIM) button (15) shortly to reinforce the bass output and display will show “LOUD”. Press it again to release this function. •...
-
Page 9: Radio Operation
OPERATION RADIO OPERATION • BAND SELECTION At tuner mode, press BAND button (18) shortly to select the desired band. The reception band will change in the following order: AM2/MW2 • STATION SELECTION Press button (16) or shortly to activate automatic seek function. -
Page 10: Cd Operation
OPERATION CD OPERATION • SELECT TRACKS Press button (16) or move to the previous track or the following track. Track number shows on display. Hold press button (16) or (17) to fast reverse or fast forward. Disc play starts from when you release the button. -
Page 11: Cd Changer Operation
OPERATION CD CHANGER OPERATION • SELECT TRACKS Press button (16) or move to the previous track or the following track. Track number shows on display. Hold press button (16) or (17) to fast reverse or fast forward. Disc play starts from when you release the button. -
Page 12: Specification
SPECIFICATION GENERAL Power Supply Requirements Chassis Dimensions Tone Controls - Bass (at 100 Hz) - Treble (at 10 KHz) Maximum Output Power Current Drain CD PLAYER Signal to Noise Ratio Channel Separation Frequency Response RADIO Frequency Coverage Sensitivity (S/N = 30 dB) Stereo Separation Frequency Coverage Sensitivity (S/N = 20 dB) -
Page 13: Trouble Shooting
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power. The car ignition switch is not on. The fuse is blown. Disc cannot be Presence of CD disc inside loaded or ejected. - Page 14 www.pyleaudio.com 88-C1802-xx...
