Sunex Tools SX243 Operating Instructions

Heavy duty long barrel air hammer with quick change chisel retainer

Hide thumbs Also See for SX243:

Download this manual

Operating Instructions • Warning Information • Parts Break down

ALWAYS READ INSTRUCTIONS BEFORE

USING POWER TOOLS

ALWAYS WEAR SAFETY GOGGLES

WEAR HEARING PROTECTION

AVOID PROLONGED EXPOSURE TO VIBRATION

SPECIFICATIONS

Collet Opening ...........0.401" (10.19mm)

Blows per Minute .................2,200 BPM

Bore Diameter.....................3/4" (19mm)

Piston Stroke ............. 3-3/4" (95.25mm)

Weight ........................ 4.6 Lbs. (2.09 kg)

Length ........................8.88" (225.55mm)

SX243: Parts Breakdown & Operating Manual

WARNING

Average Air

Consumption .............. 4 CFM (91 l/min)

Air Inlet .....................................1/4" NPT

Minimum

Hose Size .....................3/8" I.D. (10mm)

Sound Level ..............................110 dBA

duty long

barrel air

SX243

Heavy

Hammer

witH quick

cHange cHiSel

retainer

Rev. 09/20/11

Need help?

Do you have a question about the SX243 and is the answer not in the manual?

Page 1 Bore Diameter.....3/4" (19mm) Minimum Piston Stroke ..... 3-3/4" (95.25mm) witH quick Hose Size .....3/8" I.D. (10mm) Weight ......4.6 Lbs. (2.09 kg) cHange cHiSel Sound Level ......110 dBA Length ......8.88" (225.55mm) retainer SX243: Parts Breakdown & Operating Manual Rev. 09/20/11...
Page 2 If tool appears to malfunction, remove from service immediately and arrange for repair. Never use tool if there is any chance of coming into contact with line electricity. SAFETY INSTRUCTIONS - DO NOT DISCARD - GIVE TO USER SX243: Parts Breakdown & Operating Manual Rev. 09/20/11...
Page 3 RS248022B Comfort Grip RS848009 O-Ring (3.8 x 1.9mm) RS87301 Retainer Spring (optional) RS848010 O-Ring (3.5 x 1.5mm) RS848023 Exhaust Deflector RS848011 Valve Bushing RS248025 Quick Change Chuck RS848012 O-Ring (12 x 2mm) SX243: Parts Breakdown & Operating Manual Rev. 09/20/11...
Page 4: Air Supply
Grit or gum SX243: Parts Breakdown & Operating Manual Rev. 09/20/11 Shop for other air tools & compressors on our website.
