Summary of Contents for PYLE Audio car security system
- Page 2 INTRODUCTION The newest technological are integrated in our Two Way Alarm and Remote Engine Start alarm system. They are fully programmable for your customers to have personalized security and comfort. The ultimate in comfort and protection. ALARM The alarm integrated in the system is a fully programmable unit with multi zone protection such as shock sensor, starter kill output, control power locks and much more.
-
Page 3: Features And Operations
WIRING DESCRITION 10PIN CONNECTION BROWN Parking light wire (12v positive output) connect to parking light wire BROWN Parking light wire (12v positive output) connect to parking light wire PURPLE TACH wire (AC input) connect to TACH signal wire (coil or injector) YELLOW/ Starter kill wire (500mA negative output) connect to starter kill GREEN... - Page 4 FEATURES AND OPERATIONS ARMING: Arming the system will also enable the starter kill and unlock the door, if installed. PASSIVE ARMING: The system will automatically arm without door lock itself 30 seconds after the ignition has been turned OFF and the last door closed. DISARMING: Disarming the system will also disable the stater kill and unlock the door, if installed.
-
Page 5: Wire Connection Guide
WIRE CONNECTION GUIDE Blue Battery Starter Accessories Ignition Yellow Brown White Central door lock connection Blue Tach signal Brake switch(positve input) (call AC input) Orange Purple Brown Green Antenna Brown Yellow Yellow STEP1 DELETE CODE FOR CONTROL UNIT: Press learning button at control unit until the LED at control unit (near the learning button) turn off. -
Page 6: Transmitter Operation
TRANSMITTER OPERATION FUNCTION PRESSING BUTTON BUTTON ARM SILENTLY System armed and doors locked ARMING NO Press once without chirp CHIRP ANTI CAR- Press then System enter anti car-hijacking mode. HIJACKING press while driving. BUTTON ENGINE START Press once and press ENGINE START Send signal to start engine. - Page 7 PROGRAMING IMPORTANT: The installation must be complete before accessing programming mode. DOOR LOCK PULSE: Some European Vehicles such as Mercedes-Benz and Audi, require longer lock and unlock pulse to operate the vacuum pump. Start the engine, press button at the same time. Parking light will turn on 0.5 second, that means 0.5 second door lock pulse selects.
-
Page 8: Troubleshooting
COMMOM BUTTON USED BY 3508 TRANSMITTER ARM & LOCK THE DOORS DISARM & UNLOCK THE DOORS ARM & LOCK THE DOOR SIRENTLY ENGINE START VIBRATION ON/OFF TRANSMITTER OPERATION ADJUST REALTIME CLOCK: Keep press button 8 seconds until the display show the hour flashing. Use adjust hour and use button to adjust minute. - Page 9 TWO WAY LCD TRANSMITTER OPERATION 1. R transmit / Receive 2. Silent mode 3. Vibration mode 4. AM 5. PM 6. Lock 7. Impact detector alarm 8. Unlock 9. Parking light 10. Door open 11. Time display 12. Successful learning indicator 13.
- Page 10 INTRODUCTION The newest technological are integrated in our Two Way Alarm and Remote Engine Start 10PIN CONNECTION alarm system. They are fully programmable for your customers to have personalized BROWN security and comfort. The ultimate in comfort and protection. BROWN ALARM PURPLE The alarm integrated in the system is a fully programmable unit with multi zone protection...
