PVI TurboPower 100N125A-TPL Specification

LOW NO
Recovery gph
MODEL
NUMBER
40° - 120°F 40° - 140°F
1000 N 125A-TPL 1000
Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
With standard gas train
* The information presented is for natural gas 0.6 S.G.
Dimensions are in inches unless otherwise specified.
For standard and optional equipment, see form #PV 6452.
STANDARD GAS PRESSURE REQUIREMENTS:
SEE TABLE FOR MINIMUM PRESSURE BY MODEL.
MAXIMUM STATIC INLET GAS PRESSURE IS 10.5" W.C.
FOR GAS PRESSURES OUTSIDE OF THIS RANGE,
CONTACT YOUR PVI REPRESENTATIVE.
VENTING REQUIREMENTS:
-.02" TO -.06" W.C. (NEGATIVE PRESSURE).
TYPE B VENTING.
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED UPON
THE VENT CONNECTION DIAMETER EXCLUSIVELY. CHECK
NATIONAL FUEL GAS CODE UNDER "FAN ASSISTED."
PV 6523 02/25/04
TURBOPOWER
x
®
NICKELSHIELD NICKEL-PLATED STORAGE TANK
TANK SERIES 125 GALLONS VERTICAL
Min. Inlet
INPUT
Flow Gas
Btu/h
Pressure
" W.C.
800 800,000
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
(800) 784-8326 • www.pvi.com
• PACKAGED WATER HEATER
®
SCAQMD Energy
Model No.
4.5 8TPL 800 MBtu/h
STANDARD ELECTRICAL REQUIREMENTS:
VOLTAGE: 120V, 1Ø, 60 HZ., 20 AMPS.
OTHER VOLTAGES REQUIRE AN EXTERNAL
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN AND
Dimensions Blower
(inches) Motor
A B C HP Amps
33 8 1 1/2
STEPDOWN TRANSFORMER.
SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
Shipping
Weight
#
7 1445
