PVI QuickDraw Boiler Water PV 6347 Specifications

MODEL

GPM RECOVERY

NUMBER @ 200°F BOILER WATER
40 to 120°F
10 N A-IW 10
20 N A-IW 20
45 N A-IW 45
Recoveries are based on a 20°F boiler water temperature drop.
For other boiler water temperatures see form PV 6362.
Maximum electrical requirements: 120V, 1Ø, 60 Hz., 24 amps, to single point connection

Intra-tank Circulators:

10 N A-IW
20 N A-IW Pump Not Required for Temperature Control Accuracy
45 N A-IW
PV 6347 3/00
QuickDraw
®
NICKELSHIELD
INSTANTANEOUS PACKAGED WATER HEATER
SINGLE-WALL HEAT EXCHANGER

BOILER WATER PUMP MOTOR

120V, 1Ø, 60 Hz.
40 to 140°F HP
6.2 1/3
12.1 1/3
27.8 1
HP Amps
1/7 1.7
1/3 8
Dimensions are in inches unless otherwise noted.
FORT WORTH, TEXAS 76111
BOILER WATER
®
NICKEL-PLATED
COLD
INLET
AMPS NPT
8 3
8 3
16 3
Volts
120V, 1Ø, 60 Hz.
120V, 1Ø, 60 Hz.
PVI INDUSTRIES, INC.
(800) 784-8326
HOT
BOILER WATER
CONNECTION NPT
OUTLET
INLET OUTLET
NPT
2 3 1-1/4
2 3 1-1/4
3 4 2-1/2
3/4" anchoring
bolt holes
APPROX
SHIP
WEIGHT
820 #
830 #
900 #
