PVI NickelShield PV 6382 07 Specifications

LOW NOx MAXIM ▪ PACKAGED GAS WATER HEATER

STANDARD FEATURES AND EQUIPMENT

•
82% thermal efficiency
•
SCAQMD compliant
•
NOx emissions certified at <55 ppm at 3% 0
• NOx emissions certified at <30 ppm at 3% 0
®
•
NICKELSHIELD nickel-plated tank with 10-year warranty, three-year scale failure warranty and one-year cost-free service policy
•
Nonferrous, removable fittings at all tank connections
•
Nickel-plated, copper-clad steel firetubes
®
• SCALEGUARD tubesheet protection
•
Upper and lower immersion operating thermostats
•
Immersion temperature limiting device (high limit control)
•
ASME-rated temperature and pressure relief valve
• Drain valve
•
Handhole tank cleanout
•
Power combustion burner
•
Spark ignition
• Electronic combustion sequencer and flame safeguard with pre-purge
•
Combustion sequence indicating lights (> 399,000 Btu/h)
•
Differential pressure air flow switch
• Second main gas valve (> 399,000 Btu/h)
• Compliant with ASHRAE 90.1 for thermal efficiency and standby loss
•
Fiberglass insulated tank
•
Draft regulator (barometric damper)
• Steel jacket panels with industrial-grade finish
• Factory-authorized start up
•
ASME stamped—150 psi MAWP
•
National Board Registered for 150 psi working pressure
•
UL listed to safety standard UL 795 "Commercial-Industrial Gas Heating Equipment"
• FM compliant

OPTIONAL FEATURES AND EQUIPMENT

Long-life service policy
AGA-rated temperature and pressure relief valve(s)
2,500,000 Btu/h FM controls package. Adds electronic low-water cutoff, manual-reset high limit, single-try firing control and high-low
gas pressure switch. (not required for FM compliance below 2,500,000 Btu/h) (available only on 540,000 and 650,000 Btu/h)
CSD-1 / IRI compliant components include manual reset electronic low water cut off, manual reset temperature limiting device and
Hi-Lo gas pressure switch (as required)
Electronic combustion sequencer and flame safeguard with pre– and post-purge
Electronic low-water cutoff
Manual-reset, temperature limiting device
DUO-SET™ controls for dual-temperature applications
Dial temperature and pressure gauges
Tridicator
Alarm bell with silencing switch
Seven-day time clock
Digital seven-day time clock with battery backup
Air intake assembly for remote combustion air (requires field connection to ductwork supplied by others)
Consult factory for other codes
See complete warranty and/or service policy for details
PV 6382 11/07
®
NICKELSHIELD NICKEL-PLATED STORAGE TANK
and/or less than 40 nanograms per joule (199 to 399 MBtu/h)
2
(above 399 MBtu/h)
2
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
(800) 784-8326 ▪ (817) 335-9531 ▪ www.pvi.com
PVI reserves the right to change
the design and specification
without notice.
