ITI 2100ARFT Installation Instructions

System Sensor Smoke
Sensor Model 2100ARFT
Document Number: 466-xxxx Rev. A PRELIMINARY
August 1998
60-838-95
INSTALLATION
INSTRUCTIONS

Product Summary

The System Sensor™ Smoke Sensor Model 2100ARFT
(smoke alarm) is a Learn Mode, wireless, photoelectric
smoke sensor with a self-contained alarm siren, a low-
battery annunciator, and a status light. The smoke
alarm is part of a security/fire alarm system and com-
municates with the system's control panel.
Figure 1 illustrates the smoke sensor's parts.

Installation Guidelines

ν
Avoid installing the unit until all contsruction is
completed. The mounting ring may be pre-
installed.
ν
Leave the orange dust cover on the unit until
sheet rocking and sanding are completed; other-
wise, dust can get into the unit and cause false
alarms.
CAUTION:
The orange dust cover must be
removed for the unit to detect
smoke.
ν
Do not mix battery brands.
ν
Not compatible with CareTaker Plus or custom
versions with software versions 3.0 or earlier.
ν
Not compatible with Commander 2000 or custom
versions with software versions 4.0 or earlier.
(The Commander 2000 announces the version
when it is powered up or reset.)
EXHIBIT G

Tools Needed

ν
Phillips screwdriver and pocket-sized slotted
screwdriver

Batteries

UL Note: Each smoke alarm uses two 3-volt lithium
batteries. For UL installations, use one of
the following: Sanyo CR123A, Panasonic
CR123A, or Duracell DL123A. Do not mix
brands.

Inserting Batteries

The batteries must be correctly installed before the
panel can learn the smoke alarm ID. [Batteries are
shipped in the unit backwards.] You must remove
them and reinstall them correctly.
To insert batteries into the smoke sensor:
1.
Gently twist the cover counterclockwise to sepa-
rate it from the mounting bracket.
2.
Remove the batteries from the battery compart-
ment.
3.
Insert the batteries into the battery compartment.
Observe proper polarity.
4.
Leave the mounting ring off and proceed to
"Learning the Smoke Sensor."

Low Batteries

When the batteries need to be replaced, the unit trans-
mits a signal to the panel. If the batteries are not
replaced within 7 days, the unit will chirp every 40
seconds until the batteries are exhausted.
Note: If you test the smoke alarm or it goes into
alarm during this 7-day period, chirp delay is
canceled and the unit begins chirping immedi-
ately.

Programming

For more detailed programming information, refer to
the specific panel's installation manual.
System Sensor Smoke Sensor
Page 1
