PVI Industries 250N600A-TPO Specifications

TURBOPOWER
Recovery gph
Model
Number
40°- 120°F 40°- 140°F
250 P 600A-TPO 250
500 P 600A-TPO 500
750 P 600A-TPO 750
1000 P 600A-TPO 1000
1250 P 600A-TPO 1250
1500 P 600A-TPO 1500
2000 P 600A-TPO 2000
2500 P 600A-TPO 2500
3000 P 600A-TPO 3000
3500 P 600A-TPO 3500
4000 P 600A-TPO 4000
Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
"J" dimension is for the burner housing only.
Dimensions are in inches unless otherwise specified.
For standard and optional equipment, see form PV 6006.
VENTING REQUIREMENTS
-.02" TO -.06" W.C. (NEGATIVE PRESSURE)
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED
UPON THE VENT CONNECTION DIAMETER EXCLUSIVELY.
FOR PROPER SIZING, CONSULT VENTING SUPPLIER.
* REAR ACCESS MODULE
MODEL PREFIX M
250-1500 23"
2000-2500 23"
3000-4000 30"
PV 5440 04/05
® OIL
®
POLYSHIELD POLYMER-LINED STORAGE TANK
TANK SERIES 600 GALLONS
Input Gph
Btu/h #2 Oil
200 199,000 1.4
400 399,000 2.8
600 600,000 4.3
800 800,000 5.7
1000 1,000,000 7.2
1200 1,200,000 8.6
1600 1,600,000 11.4
2000 2,000,000 14.3
2400 2,400,000 17.1
2800 2,800,000 20.0
3200 3,200,000 22.8
L STD or OPTIONAL
8" OPTIONAL
16" STANDARD
18" STANDARD
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
(800) 784-8326
PACKAGED WATER HEATER
Dimensions (inches)
A B J
28 4 17
28 5 17
31 6 17
31 8 17
39 8 17
39 8 17
51 10 25
51 10 25
53 12 25
53 12 25
53 12 25
STANDARD ELECTRICAL REQUIREMENTS
CONTROL VOLTAGE: 120V, 1Ø, 60 HZ., 2 AMPS.
MOTOR VOLTAGE:
208V, 230V, AND 460V MOTORS ARE AVAILABLE BUT WILL
REQUIRE A SEPARATE 120V/2 amps CONTROL CIRCUIT OR AN
OPTIONAL CONTROL CIRCUIT TRANSFORMER.
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN
(817) 335-9531 www.pvi.com
Blower
Motor
Volt/Ph/
K HP
Amps
41 1/3
115/1∅/8
41 1/2
115/1∅/10
41 1/2
115/1∅/10
41 1/2
115/1∅/10
41 1/2
115/1∅/10
41 1/2
115/1∅/10
41 1-1/2
115/1∅/20
41 1-1/2
115/1∅/20
51 1-1/2
115/1∅/20
51 5
230/3∅/16
51 5
230/3∅/16
AND SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
Shipping
Weight
lbs
2270
2290
2370
2410
2650
2660
3100
3120
3130
3160
3210
