PVI Industries 140P175A-E Specifications

DURAWATT
MODEL
NUMBER
45 P 175A-E
90 P 175A-E
140 P 175A-E
180 P 175A-E
230 P 175A-E
270 P 175A-E
320 P 175A-E
370 P 175A-E
410 P 175A-E
460 P 175A-E
510 P 175A-E
550 P 175A-E
650 P 175A-E
740 P 175A-E

ASHRAE 90.1 compliant.

For standard and optional equipment, see form #PV 6010.

Dimensions in inches, unless otherwise noted.

Inputs higher than 144kW are available. Contact PVI representative.
CONTROL CIRCUIT TRANSFORMER SUPPLIED ON 480V ONLY. TAPPED CONTROL CIRCUIT INTERNALLY WIRED FOR 208V AND 240V.
208V AND 240V MODELS REQUIRE AC NEUTRAL CONDUCTOR FOR GROUNDING OF CONTROL CIRCUIT.
ALTERNATE VOLTAGES:
PV 5627 07/07
® ELECTRIC • PACKAGED WATER HEATER
®
POLYSHIELD POLYMER-LINED STORAGE TANK
TANK SERIES 175 GALLONS

RECOVERY RATE

GPH
40°-120°F 40°-140°F
45 37
90 70
140 111
180 150
230 184
270 220
320 256
370 300
410 330
460 370
510 400
550 440
650 515
740 590

STANDARD ELECTRICAL REQUIREMENTS:

FOR 230/460V, MULTIPLY kW AND RECOVERY BY .92. MULTIPLY AMPS BY .96.
FOR 220/440V, MULTIPLY kW AND RECOVERY BY .84. MULTIPLY AMPS BY .92.
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
(800) 784-8326 · www.pvi.com

ELEMENT AMPS

INPUT
kW
240V, 1Ø 208V, 3Ø
9 38 25
18 75 50
27 113 75
36 150 100
45 188 125
54 225 150
63 263 175
72 300 200
81 338 225
90 375 250
99 413 275
108 450 300
126 525 350
144 600 400
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN AND
SHIPPING
WEIGHT
lbs
240V, 3Ø 480V, 3Ø
22 11 1130
44 22 1130
65 33 1130
87 44 1130
109 55 1140
130 65 1140
152 76 1140
174 87 1140
195 98 1150
217 109 1150
239 120 1170
260 130 1170
304 152 1180
347 174 1200
SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
