PVI Industries 1000PHE125A-TPO Specification Sheet

Packaged water heater

Advertisement

Quick Links

TURBOPOWER
Model
Number
40°- 120°F 40°- 140°F
250 PHE 125A-TPO
500 PHE 125A-TPO
750 PHE 125A-TPO
1000 PHE 125A-TPO
1250 PHE 125A-TPO
1500 PHE 125A-TPO
Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
"J" dimension is for the burner housing only.
Dimensions are in inches unless otherwise specified.
For standard and optional equipment, see form PV 6006.
VENTING REQUIREMENTS
-.02" TO -.06" W.C. (NEGATIVE PRESSURE)
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED
UPON THE VENT CONNECTION DIAMETER EXCLUSIVELY.
FOR PROPER SIZING, CONSULT VENTING SUPPLIER.
PV 5458 04/05
®
OIL
®
POLYSHIELD
POLYMER-LINED STORAGE TANK
TANK SERIES 125 GALLONS HORIZONTAL
Recovery gph
Input
Btu/h
250
200
199,000
500
400
399,000
750
600
600,000
1000
800
800,000
1250
1000
1,000,000
1500
1200
1,200,000
FORT WORTH, TEXAS 76111
(800) 784-8326
PACKAGED WATER HEATER
Dimensions
(inches)
Gph
#2 Oil
A
B
1.4
24
4
2.8
24
5
4.3
27
6
5.7
27
8
7.2
27
8
8.6
27
8
STANDARD ELECTRICAL REQUIREMENTS
CONTROL VOLTAGE: 120V, 1Ø, 60 HZ., 2 AMPS.
MOTOR VOLTAGE:
208V, 230V, AND 460V MOTORS ARE AVAILABLE BUT WILL
REQUIRE A SEPARATE 120V/2 amps CONTROL CIRCUIT OR
AN OPTIONAL CONTROL CIRCUIT TRANSFORMER.
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN
PVI INDUSTRIES, LLC
(817) 335-9531
www.pvi.com
Blower
Motor
J
HP
Volt/Ph/Amps
17
1/3
115/1∅/8
17
1/2
115/1∅/10
17
1/2
115/1∅/10
17
1/2
115/1∅/10
17
1/2
115/1∅/10
17
1/2
115/1∅/10
AND SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
Shipping
Weight
lbs
970
990
1070
1110
1350
1360
