PVI Industries 1000P125A-TPGO Specification Sheet

TURBOPOWER
Recovery gph
Model
Number
40°- 120°F 40°- 140°F
750 P 125A-TPGO 750
1000 P 125A-TPGO 1000
Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
"J" dimension is for the burner housing only. Gas train may exceed this dimension.
Standard gas train.
*
The information presented is for Natural gas 0.6 S.G.— For operation with propane (LP gas), consult factory.
Dimensions are in inches unless otherwise specified.
Burner control panel requires 18" clearance for door swing.
For standard and optional equipment, see form PV 6047.
*
GAS PRESSURE REQUIREMENTS
SEE TABLE FOR MINIMUM PRESSURE BY MODEL NUMBER.
MAXIMUM STATIC INLET PRESSURE: 14" W.C.
FOR PRESSURES OTHER THAN LISTED, CONSULT FACTORY.
Pressure shown is for standard UL gas train. Additional controls
may increase pressure requirements.
VENTING REQUIREMENTS
-.02" TO -.06" W.C. (NEGATIVE PRESSURE)
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED
UPON THE VENT CONNECTION DIAMETER EXCLUSIVELY.
FOR PROPER SIZING, CONSULT
THE NATIONAL FUEL GAS CODE UNDER "FAN-ASSISTED."
PV 5615 02/04
® GAS/OIL
®
POLYSHIELD POLYMER-LINED STORAGE TANK
TANK SERIES 125 GALLONS
Min. Inlet Flow
Input
Gas Pressure
Btu/h
"W.C.
600 600,000 4.5
800 800,000 6.0
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
(800) 784-8326 (817) 335-9531
PACKAGED WATER HEATER
Dimensions (inches)
#2 Oil
gph
A B C
4.3 57 6 1
5.7 57 8 1
*
REAR ACCESS MODULE
MODEL PREFIX
750-1500 23"
STANDARD ELECTRICAL REQUIREMENTS
CONTROL VOLTAGE: 120V, 1Ø, 60 HZ., 2 AMPS.
MOTOR VOLTAGE:
208V, 230V, AND 460V MOTORS ARE AVAILABLE BUT WILL
REQUIRE A SEPARATE 120V/2 amps CONTROL CIRCUIT OR AN
OPTIONAL CONTROL CIRCUIT TRANSFORMER.
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN
www.pvi.com
Blower
Motor
Volt/Ph/
J HP
Amps
31 1/2
115/1∅/10
31 1/2
115/1∅/10
M L STD or OPTIONAL
8" OPTIONAL
AND SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
Shipping
Weight
lbs
1650
1690
