TURBOPOWER
Recovery gph
Model
Number
40°- 120°F 40°- 140°F
750 N 600A-TPGO
750
1000 N 600A-TPGO
1000
1250 N 600A-TPGO
1250
1500 N 600A-TPGO
1500
2000 N 600A-TPGO
2000
2500 N 600A-TPGO
2500
Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
"J" dimension is for the burner housing only. Gas train may exceed this dimension.
Standard gas train.
*
The information presented is for Natural gas 0.6 S.G.— For operation with propane (LP gas), consult factory.
Dimensions are in inches unless otherwise specified.
Higher inputs available. Consult the factory.
For standard and optional equipment, see form PV 6046.
*
GAS PRESSURE REQUIREMENTS
SEE TABLE FOR MINIMUM PRESSURE BY MODEL NUMBER.
MAXIMUM STATIC INLET PRESSURE: 14" W.C.
FOR PRESSURES OTHER THAN LISTED, CONSULT FACTORY.
Pressure shown is for standard UL gas train. Additional controls
may increase pressure requirements.
VENTING REQUIREMENTS
-.02" TO -.06" W.C. (NEGATIVE PRESSURE)
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED
UPON THE VENT CONNECTION DIAMETER EXCLUSIVELY.
FOR PROPER SIZING, CONSULT
THE NATIONAL FUEL GAS CODE UNDER "FAN-ASSISTED."
PV 5460 03/04
®
GAS/OIL
®
NICKELSHIELD
NICKEL-PLATED STORAGE TANK
TANK SERIES 600 GALLONS
Min. Inlet Flow
Input
Gas Pressure
Btu/h
"W.C.
600
600,000
4.5
800
800,000
6.0
1000
1,000,000
7.5
1200
1,200,000
7.5
1600
1,600,000
6.5
2000
2,000,000
8.0
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
(800) 784-8326
PACKAGED WATER HEATER
Dimensions (inches)
#2 Oil
gph
A
B
4.3
46
6
5.7
46
8
7.2
54
8
8.6
54
8
11.4
63
10
14.3
65
10
*
REAR ACCESS MODULE
MODEL PREFIX
750-1500
2000-2500
STANDARD ELECTRICAL REQUIREMENTS
CONTROL VOLTAGE: 120V, 1Ø, 60 HZ., 2 AMPS.
MOTOR VOLTAGE:
208V, 230V, AND 460V MOTORS ARE AVAILABLE BUT WILL
REQUIRE A SEPARATE 120V/2 amps CONTROL CIRCUIT OR AN
OPTIONAL CONTROL CIRCUIT TRANSFORMER.
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN
(817) 335-9531
www.pvi.com
Blower
Motor
Volt/Ph/
C
J
HP
Amps
1
31
1/2
115/1∅/10
1
31
1/2
115/1∅/10
1
31
3/4
115/1∅/14
1-1/4
31
1
115/1∅/16
2
36
2
115/1/∅24
2
36
2
115/1∅/24
M
L
STD or OPTIONAL
23"
8"
23"
16"
STANDARD
AND SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
Shipping
Weight
lbs
2720
2760
2850
2930
3140
3260
OPTIONAL
