PVI Industries TURBOPOWER 1000 N 225A-TPO Specification Sheet

TURBOPOWER
Model
Number
40°- 120°F 40°- 140°F
250 N 225A-TPO
500 N 225A-TPO
750 N 225A-TPO
1000 N 225A-TPO
Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
"J" dimension is for the burner housing only.
Dimensions are in inches unless otherwise specified.
For standard and optional equipment, see form PV 6004.
VENTING REQUIREMENTS
-.02" TO -.06" W.C. (NEGATIVE PRESSURE)
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED
UPON THE VENT CONNECTION DIAMETER EXCLUSIVELY.
FOR PROPER SIZING, CONSULT VENTING SUPPLIER.
PV 5359 04/05
® OIL
®
NICKELSHIELD NICKEL-PLATED STORAGE TANK
TANK SERIES 225 GALLONS
Recovery gph
Input
Btu/h
250 200 199,000
500 400 399,000
750 600 600,000
1000 800 800,000
FORT WORTH, TEXAS 76111
(800) 784-8326
PACKAGED WATER HEATER
Dimensions
(inches)
Gph
#2 Oil
A B J
1.4 28 4
2.8 28 5
4.3 42 6
5.7 42 8
STANDARD ELECTRICAL REQUIREMENTS
CONTROL VOLTAGE: 120V, 1Ø, 60 HZ., 2 AMPS.
MOTOR VOLTAGE:
208V, 230V, AND 460V MOTORS ARE AVAILABLE BUT WILL
REQUIRE A SEPARATE 120V/2 amps CONTROL CIRCUIT OR
AN OPTIONAL CONTROL CIRCUIT TRANSFORMER.
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN
PVI INDUSTRIES, LLC
(817) 335-9531 www.pvi.com
Blower
Motor
HP Volt/Ph/Amps
17 1/3
115/1∅/8
17 1/2
115/1∅/10
17 1/2
115/1∅/10
17 1/2
115/1∅/10
AND SPECIFICATION WITHOUT NOTICE.
Product is patented in the U.S., Canada, and Mexico.
Shipping
Weight
lbs
1380
1400
1480
1520
