Trademarks DMX-50, the DMX-50 logo, ReVu, the ReVu logo, PURE, the PURE logo, PURE Digital, the PURE Digital logo, Imagination Technologies, and the Imagination Technologies logo are trademarks or registered trademarks of Imagination Technologies Limited. All other product names are trademarks of their respective companies.
Contents Getting started ... 2 Overview diagrams ... 2 Connecting speakers ... 4 Switch on and off ... 4 Changing the volume ... 4 Navigating menus ... 4 Listening to DAB radio ... 5 Selecting a station ... 5 Changing the information displayed ... 5 ReVu™...
Getting started Overview diagrams These diagrams show the function of controls, the connectors on the rear panel, the remote control and screen icons. Front panel Infrared receiver Receives signal from remote control LCD screen Backlit LCD screen with variable contrast and brightness RECORD Starts and stops record...
Select ReVu Enters ReVu mode for DAB pause and ReVu rewind Mute CD/SD controls Also used for FM tuning and ReVu DMX-50 FM screen Stereo Indicates stereo reception Signal strength Shows signal strength Station for current DAB station Frequency or...
Before switching on for the first time - ensure the aerial is uncoiled and mounted as high as possible. When you first plug in your DMX-50 it switches to DAB mode and asks you if you want to perform a UK (UK Band III only) or Full autotune (full Band III) to find all DAB stations available in your area.
ReVu™ - Pausing and rewinding radio ReVu mode lets you pause and rewind live DAB digital radio. DMX-50 constantly stores audio and text from the station you are tuned to in its memory. The amount stored depends on how long you have been listening to that station and the data rate of the broadcast.
To recall a preset - Press the shortcut button next to the preset you want to listen to or press the number buttons on the remote. Changing DAB options To customise the way your DMX-50 works in DAB mode press the Menu button, select DAB and choose from the following: Autotune UK Scans all UK frequencies for DAB stations and adds any new ones to the station list.
Page 9
Station order Change the order of stations on your station list using this option. The current order is shown at the top of the screen. Choose from the following: Alphanumeric Displays all stations in alphanumeric order. Favourite Displays your eight most listened to stations at the top of the station list and the others below.
) and place your CD label side up in the CD tray. Press the eject button again to load the CD. DMX-50 checks the CD type and loads a track list. If you insert a CD with MP3 files on it DMX-50 enters MP3 mode, see page 10.
Page 11
Set playlist Create a playlist containing the order in which to play up to 20 tracks from the current CD. To create a playlist: Turn the TUNE/SELECT dial and push to set the first track on your playlist. Repeat until you have completed your playlist and select OK or press the bottom right shortcut button (OK) to set your playlist and exit.
Press the CD/SD button or the Mode button on the remote until you see CD in the top left of the screen to listen to a CD with MP3 files stored on it. DMX-50 automatically detects if a CD has MP3 files on it and changes to MP3 mode.
FM in the top left of the screen. The first time you enter FM mode DMX-50 asks you to select the FM tuning mode you want. Use the shortcut buttons or TUNE/SELECT dial to select one of the following:...
To recall a preset - Press the shortcut button next to the preset you want to listen to or press the number buttons on the remote. Changing FM options To customise the way your DMX-50 works in FM mode press the MENU button, select FM and choose from the following: Tune...
Using an SD memory card You can use an SD card in your DMX-50 for recording* and playing back DAB digital radio or playing MP2/MP3 files recorded elsewhere. SD cards are readily available from PURE and other electronics retailers. As a rough guide –...
You see a list of the files ( )and folders ( ) on the SD card. DMX-50 records MP2 files to a TRACKS folder when you record from DAB radio. DAB recordings will show recording date and time and show the station name and multiplex when played, MP3s will show track title and additional file information where available.
Page 17
Enables access to an SD card inserted in your DMX-50 using a USB connection to your PC. This enables you to manage files on your SD card using Windows Explorer on your PC e.g.
DMX-50 to control the volume through your speakers/headphones. If you find that you need to turn your DMX-50 up quite loud you can alter the gain (amplification) applied to the auxiliary inputs using the AUX1 or AUX2 setup options.
Turn the Tuning dial or use the +/- shortcut keys to set a time after which you want your DMX-50 to switch off. Choose between 15, 30, 45, 1hr, 1hr 15 and 1hr 30 minutes. To switch a sleep timer off use the Clear shortcut button or set the time to zero.
Unavailable stations have a ‘?’ before their name on the station list. If you select a station which has this symbol, DMX-50 tries to tune to the station again and returns to the last station you were listening to if unsuccessful.
Technical specifications Amplifier 40W RMS per channel power output (into 8 Ohms @10% THD+N, A-weighted) 10 Hz to 40 kHz (-3dB) frequency response Bass and treble tone control CD player CD-R and CD-RW playback compatible Support for CD Text and 20 track audio CD playlist Multiple playback modes (repeat, shuffle, etc.) MP3 playback, including support for ID3v2 tags and M3U playlists PURE ReVu™...
Page 22
www.pure.com PURE Digital, Imagination Technologies Ltd., Imagination House, Home Park Estate, Kings Langley, Herts, WD4 8LZ, UK +44 (0) 1923 277477 support +44 (0) 1923 277488 sales 12M22 +44 (0) 1923 270188 support@pure.com sales@pure.com...
